1150Z-2 Dial Indicator Snap Gage

1150Z-2 Dial Indicator Snap Gage

$2,934.00
(No reviews yet) Write a Review
SKU:
1150Z-2
UPC:
049659531688
Category:
Precision Measuring Tools > Precision Hand Tools > Indicators & Gages > Snap Gages
Cal Prop 65 Chemical:
Lead
Assembled in US:
N
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Flat Stock Inventory:
0
Item Class:
Stand-Alone
Parent SKU As a Regular Field:
1150Z
Product Group Sort:
icc110507_snap_gages
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=1150Z-2
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
DIAL INDICATOR SNAP GAGE, 0-2" RANGE
Item Segmentation:
Catalog
Long Description:
1150Z-2 DISCONTINUED 3-24-2020 PER ECO18048
Made in America:
Yes
Manufacturer's code:
049659
NAFTA Producer:
Yes
Item ID:
1150Z-2
POA Flag:
N
Shelf Pack Item Qty:
1
Shelf Pack Pricing Quantity:
1
A0006160MSDSINDICATOR:
N
A002040UCC12UPCA:
049659531688
A002050EANUCC13EAN13:
0049659531688
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (mm):
86.36
Unit Pack Invoiced:
N
Unit Pack Length (mm):
292.1
Unit Pack Shippable:
N
Unit Pack Weight (kg):
1.360776
Unit Pack Width (mm):
172.72
UOM:
Each
Use Placeholder Photo:
N
US Web Price:
$2934.00
Web Catalog-US-EN:
Y
Web Price:
$2934.00
Discontinued:
false
Current Catalog Page:
191
Catalog Section Page:
59
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-05-Dial-and-Electronic-Indicators-and-Gages.pdf
Western Link Inventory:
0
Type:
Dial Snap Gage
Category L1:
Indicators & Gages
Category L2:
Snap Gages
Current Catalog:
33
US Promo Price:
$0.00
01 Attribute:
Range (in)
COO Detail:
Made in the USA with US and Global Content
Schedule B Number:
9017.30.8000
Product made to order status:
MTO
Available In Region:
United States|Canada
Mt Airy Inventory:
0
Country of Origin:
United States
01 Spec:
0 - 2"
02 Attribute:
Graduations (in)
02 Spec:
.0001"
03 Attribute:
Dial Reading
03 Spec:
+10 / -10 .040" Range
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Catalog:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Dial Indicator Graduations (In):
.0001"
Dial Reading:
+10 / -10 .040" Range
EAN:
0049659531688
EDP:
53168
Electronic or Mechanical:
Mechanical
Feature 01:
The contacts and backstop are 5/16" diameter hardened tool steel, precision ground and lapped fl at
Feature 02:
Contacts are individually adjustable to maximum 2" range and are locked in position by tightening parallellock clamps to maintain parallelism of faces
Feature 03:
Both contacts are also keyed to maintain orientation of faces regardless of adjustment
Feature 04:
Plus andr minus are read directly. Dial face has a double row of graduations reading in opposite directions. Red "Minus" and black "plus" grads
Feature 05:
The indicator can be rotated 360 Deg and locked in position to read from any angle, and a fine-adjusting screw provides for zero setting the hand
Feature 06:
A guard protects the dial indicator when the gage is laid down
Feature 07:
A bench stand is available to convert the gage to a bench comparator
Graduations (in):
.0001"
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/1150Z-2cUSp1.tif
Product Photo 02:
https://s3.us-west-2.amazonaws.com/catsy.833/1150Z-2cUSp3.tif
Product Photo 03:
https://s3.us-west-2.amazonaws.com/catsy.833/1150Z-2cUSa2.tif
Product Title:
1150Z-2 Dial Indicator Snap Gage
Product Type:
Snap Gage
Range (in):
0 - 2"
Short Description:
Dial Indicator Snap Gage, 0-2", .0001", +10/-10 .040"
Unit Pack Height (in):
3.5
Unit Pack Item Qty:
1
Unit Pack Length (in):
11.4
Unit Pack Width (in):
6.7
US List Price:
$2934.00
Web Priority-US-EN:
26000005
Unit Pack Weight (lbs):
3.25
SDS Indicator:
N
Series Title:
1150 Dial Indicator Snap Gages
Status:
Active
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Cal Prop 65 Warning:
Y
Max. Range (in):
2
Min. Range (in):
0
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/1150Z-2cUSp1.tif
Special Function Dial Gage Type:
Snap Gage
Indicator Dial Reading:
+10 / -10
Indicator Range:
.040"
These compact gages have rigid aluminum alloy frames protected from hand heat by insulating handles. They are used to gage outside diameters to an accuracy of .0001". Dimensional variations are transmitted to the dial indicator through a linear friction-free transfer mechanism totally enclosed for protection against side thrust, foreign matter and coolants. Flat gaging contacts simplify measurement close to shoulders. The top sensitive contact may be reversed to present a spherical face to the work. An adjustable backstop simplifies centering the work. 0-2" Range, in Case.
