1175Z Dial Indicator Groove Gage

1175Z Dial Indicator Groove Gage

$2,921.00
(No reviews yet) Write a Review
SKU:
1175Z
UPC:
049659531732
Category:
Precision Measuring Tools > Precision Hand Tools > Indicators & Gages > Groove Gages
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Country of Origin :
United States
Dial Reading:
+30 / -30 .060" Range
EAN:
0049659531732
EDP:
53173
Feature 01:
The reference jaw can be mounted in two positions on the range adjusting bar
Feature 02:
The bar itself is also adjustable for greater or lesser range
Feature 03:
A fine adjustment screw and a lock are also provided
Feature 04:
Supplied with two sets of jaws, both readily interchangeable
Feature 05:
Three sets of contacts are furnished (Styles 1-10, 2-10, 2-20) that can be attached to the ends of the jaws without replacing the entire jaw.
Feature 06:
Contacts have flush ends so that grooves at the bottom of blind holes can be gaged
Feature 07:
The contacts are hardened steel with a hard chrome finish for long life
Feature 08:
Gage can be set with gage blocks or other methods such as micrometers, vernier calipers and ring gages
Feature 09:
Furnished with storage case
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada
Description:
DIAL INDICATOR GROOVE GAGE, .375-6"
Flat Stock Inventory:
0
Item Class:
Stand-Alone
Max. Range (in):
6
Min. Range (in):
0.375
Mt Airy Inventory :
0
Parent SKU As a Regular Field:
1175
Product Group Sort:
icc110507_groove_gages
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=1175Z
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
DIAL INDICATOR GROOVE GAGE, .375-6"
Graduations (in):
.0005"
Item Segmentation:
Catalog
Long Description:
Each
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/1175ZcUSp1.tif
Manufacturer's code:
049659
NAFTA Producer:
Yes
Name:
DIAL INDICATOR GROOVE GAGE, .375-6"
Item ID:
1175Z
POA Flag:
N
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/1175ZcUSp1.tif
Product Photo 02:
https://s3-us-west-2.amazonaws.com/catsy.833/1175ZcUSp2.tif
Product Title:
1175Z Dial Indicator Groove Gage
Range (in):
.375 - 6"
SDS Indicator:
N
Series Title:
1175,1175M - Dial Indicator Groove Gages
Shelf Pack Item Qty:
1
Shelf Pack Pricing Quantity:
1
Short Description:
Dial Indicator Groove Gage, .375-6", .0005", +30/-30 .060"
Special Function Dial Gage Type:
Groove Gage
Status:
Active
A0006160MSDSINDICATOR:
N
A002040UCC12UPCA:
049659531732
A002050EANUCC13EAN13:
0049659531732
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (in):
3.6
Unit Pack Height (mm):
96.52
Unit Pack Item Qty:
1
Unit Pack Length (in):
10.6
Unit Pack Length (mm):
274.32
Unit Pack Weight (kg):
1.6782904
Unit Pack Weight (lbs):
4.25
Unit Pack Width (in):
10.6
Unit Pack Width (mm):
274.32
UOM:
Each
UPC:
049659531732
Use Placeholder Photo:
N
User Manual URL-US-EN:
https://www.starrett.com/um-1175
US List Price:
$2921.00
US Next List Price:
$2921.00
US Web Price:
$2921.00
Web Catalog-US-EN:
Y
Web Price:
$2921.00
Web Priority-US-EN:
26400005
Electronic or Mechanical:
Mechanical
Indicator Dial Reading:
±30
Indicator Range:
.060"
Dial Indicator Graduations (In):
.0005"
Category L1:
Indicators & Gages
Category L2:
Groove Gages
01 Attribute :
Range (in)
01 Spec:
.375 - 6"
02 Attribute:
Graduations (in)
02 Spec:
.0005"
03 Attribute:
Dial Reading
03 Spec:
+30 / -30 .060" Range
Discontinued:
false
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Current Catalog Page:
192
Catalog Section Page:
60
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-05-Dial-and-Electronic-Indicators-and-Gages.pdf
Western Link Inventory:
0
This lightweight gage is used for in-process or bench inspection of oil grooves, snap ring retainer grooves, O ring seat retainer grooves and similar internal recesses. It is also useful for checking bore dimensions and testing for taper, bell-mouth and out-of-roundness. The movable, sensitive gaging contact has a 1/2" (12.7mm) retractable range and transfers the measurement through a linear, friction-free transfer mechanism to the dial indicator. The lower reference jaw is fixed and supports the entire weight of the gage and the operator's hands, thus preventing incorrect gaging pressure and false readings. The reference jaw can be mounted in two positions on the range adjusting bar. The bar itself is also adjustable for greater or lesser range. A fine adjustment screw and a lock are also provided. .375-6" Range with 81-136-622J Indicator in Case A fine adjustment screw and a lock are also provided.
