The Starrett 124 Solid -Rod Inside Micrometer Sets are the most popular inside micrometers because of their lightness, ease of use, and range. They are very useful for measuring inside diameters of cylinders and rings and measuring parallel surfaces. The desired range is obtained by assembling rods and spacing collars to the micrometer head. Measuring rods are provided with a shoulder that is set accurately in the micrometer head and locked in position. When assembling rods to the A and B heads, the reading line on the micrometer head should be lined up with the marking on each rod (except for the 2-3" and the 50-75mm rods). Rod diameters are approximately 1/4" (6mm) on the A and B sizes, and approximately 11/32" (8.5mm) on the C size. Each rod has individual length adjustment for the anvil by means of special wrenches furnished. 2-32" Range, .001" Grad, 124A/124C Rods with Case.
124DZ Solid -Rod Inside Micrometer
$1,210.00
- SKU:
- 124DZ
- UPC:
- 049659505542
- Case Type:
- Padded Case
- Cal Prop 65 Chemical:
- Lead
- Cal Prop 65 Warning:
- Y
- Athol Inventory:
- 0
- Flat Stock Inventory:
- 0
- Item Class:
- Stand-Alone
- Max. Range (in):
- 32
- Min. Range (in):
- 8
- Parent SKU As a Regular Field:
- 124
- Product Group Sort:
- icc110104
- Webber Inventory:
- 0
- Website-URL:
- https://www.starrett.com/details?cat-no=124DZ
- Rocky Mountain Inventory:
- 0
- To Delete:
- false
- To Remove:
- false
- Total Inventory:
- 0
- US Web Temp Hold:
- Off
- Global Product Classification:
- INSIDE MICROMETER SET, 2-32" RANGE, .001"
- Long Description:
- Each
- Made in America:
- Yes
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/124DZcUSp1.tif
- Manufacturer's code:
- 049659
- POA Flag:
- N
- SDS Indicator:
- N
- Series Title:
- 124, 124M Solid-Rod Inside Micrometers
- Shelf Pack Item Qty:
- 1
- Shelf Pack Pricing Quantity:
- 1
- Status:
- Active
- Tariff Code for entry into Mexico:
- Yes
- Top 354:
- N
- Unit Pack Height (mm):
- 38.1
- Unit Pack Length (mm):
- 655.32
- Unit Pack Weight (kg):
- 2.3586784
- Unit Pack Weight (lbs):
- 5.1
- Unit Pack Width (mm):
- 139.7
- Use Placeholder Photo:
- N
- Web Price:
- $1210.00
- Discontinued:
- false
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- Current Catalog:
- 33
- Current Catalog Page:
- 79
- Western Link Inventory:
- 0
- categoryl1:
- Micrometers
- categoryl2:
- Inside Micrometers
- number:
- 124DZ
- A0006160MSDSINDICATOR:
- N
- A002040UCC12UPCA:
- 049659505542
- A002050EANUCC13EAN13:
- 0049659505542
- Catalog:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- Category:
- Precision Measuring Tools > Precision Hand Tools > Micrometers > Inside Micrometers
- EAN:
- 0049659505542
- EDP:
- 50554
- UOM:
- Each
- 01 Attribute:
- Micrometer Type
- 01 Spec:
- Mechanical Inside Micrometer Set
- 02 Attribute:
- Electronic or Mechanical
- 02 Spec:
- Mechanical
- 03 Attribute:
- Range (in)
- 03 Spec:
- 2-32"
- 04 Attribute:
- Accuracy (in)
- 04 Spec:
- Lead accuracy +/- .0001" per inch
- 05 Attribute:
- Graduations (in)
- 05 Spec:
- .001"
- 06 Attribute:
- Case Type
- 06 Spec:
- Padded Case
- Accuracy (in):
- Lead accuracy +/- .0001" per inch
- Available for Purchase-US-EN:
- Y
- Cal Prop 65 Statement:
- WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
- Catalog Section:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-01-Micrometers.pdf
- Catalog Section Page:
- 61
- Category L1:
- Micrometers
- Category L2:
- Inside Micrometers
- Electronic or Mechanical:
- Mechanical
- Feature 01:
- Insulated rods marked with length
- Feature 02:
- Adjustable for length
- Feature 03:
- Measuring rods are solid
- Feature 04:
- Hardened and ground anvils
- Feature 05:
- Quick-reading figures
- Feature 06:
- 6-1/2" (165mm) long handle is available (124H)
- Graduations (in):
- .001"
- Item Segmentation:
- Catalog
- Member of Set:
- PT01579|PT01526|PT19177|PT01546A|PT99195|PT99194|PT99196|PT99193|PT99192|124DZZ|H124A/B|H124C|PT99201|PT05711|PT07389|PT07390|PT07618|PT99191|PT99204|PT99202|PT99203
- Micrometer Type:
- Mechanical Inside Micrometer Set
- NAFTA Producer:
- Yes
- Item ID:
- 124DZ
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/124DZcUSp1.tif
- Product Title:
- 124DZ Solid -Rod Inside Micrometer
- Range (in):
- 2-32"
- Short Description:
- Solid -Rod Inside Micrometer Set with Case, 2-32" Range, .001"
- Show in Web Nav?:
- Yes
- Starrett Model No.:
- 124
- Unit Pack Height (in):
- 2
- Unit Pack Item Qty:
- 1
- Unit Pack Length (in):
- 26.8
- Unit Pack Width (in):
- 6.4
- US List Price:
- $1210.00
- US Promo Price:
- $0.00
- US Web Price:
- $1210.00
- Web Catalog-US-EN:
- Y
- Web Priority-US-EN:
- 13000020
- COO Detail:
- Made in the USA with US and Global Content
- Schedule B Number:
- 9017.30.4000
- Product made to order status:
- MTO
- Available In Region:
- United States|Canada
- Mt Airy Inventory:
- 0
- Product Type:
- Micrometer Set
- Country of Origin:
- United States
