260Z Groove Micrometer

260Z Groove Micrometer

$542.00
(No reviews yet) Write a Review
SKU:
260Z
UPC:
049659679878
Category:
Precision Measuring Tools > Precision Hand Tools > Micrometers > Groove Micrometers
Cal Prop 65 Chemical:
Lead
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Flat Stock Inventory:
0
Item Class:
Stand-Alone
Product Group Sort:
groove_micrometers
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=260Z
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
GROOVE MICROMETER, .001" GRADS
Item Segmentation:
Catalog
Long Description:
Each
Made in America:
Yes
Manufacturer's code:
049659
NAFTA Producer:
Yes
Item ID:
260Z
POA Flag:
N
A002040UCC12UPCA:
049659679878
A002050EANUCC13EAN13:
0049659679878
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (mm):
35.56
Unit Pack Length (mm):
203.2
Unit Pack Weight (kg):
0.3628736
Unit Pack Width (mm):
83.82
UOM:
Each
Use Placeholder Photo:
N
US Web Price:
$542.00
Web Catalog-US-EN:
Y
Web Price:
$542.00
Starrett Model No.:
260
Discontinued:
false
Current Catalog:
33
Current Catalog Page:
49
Catalog Section Page:
31
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-01-Micrometers.pdf
Western Link Inventory:
0
Category L1:
Micrometers
Category L2:
Groove Micrometers
US Promo Price:
$0.00
01 Attribute:
Micrometer Type
Tolerances: Deviation From Nominal:
+/- .0004 In. (+/- 0.01mm)
COO Detail:
Made in the USA with US and Global Content
Schedule B Number:
9017.30.4000
Product made to order status:
MTO
Available In Region:
United States|Canada
Mt Airy Inventory:
0
Country of Origin:
United States
Maximum Bore Depth (in):
1-5/8"
01 Spec:
Groove Micrometers
02 Attribute:
Electronic or Mechanical
02 Spec:
Mechanical
03 Attribute:
Groove Width Range (in)
03 Spec:
.051"-1.050"
04 Attribute:
Groove Width Range (mm)
04 Spec:
1.29-26.6mm
05 Attribute:
Graduations (in)
05 Spec:
.001"
06 Attribute:
Accuracy (in)
06 Spec:
+/- .0004 In.
07 Attribute:
Accuracy (mm)
07 Spec:
+/- 0.01mm
08 Attribute:
Maximum Bore Depth (in)
08 Spec:
1-5/8"
09 Attribute:
Land Width Range
09 Spec:
0-1.000"
10 Attribute:
Measuring Disc Diameter (in)
10 Spec:
9/32"
11 Attribute:
Measuring Disc Diameter (mm)
11 Spec:
7mm
12 Attribute:
Measuring Disc Thickness (in)
12 Spec:
.025"
13 Attribute:
Measuring Disc Thickness (mm)
13 Spec:
0.63mm
Accuracy (in):
+/- .0004 In.
Accuracy (mm):
+/- 0.01mm
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Catalog:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
EAN:
0049659679878
EDP:
67987
Electronic or Mechanical:
Mechanical
Feature 01:
Advanced sleeve design with staggered lines and distinct figures for precise and easy readability
Feature 02:
Quick-reading figures - every thousandth numbered on inch tools
Feature 03:
Balanced design to ensure easy handling and better readability
Feature 04:
Quick and easy adjustment
Feature 05:
Starrett satin chrome finish - no glare - resists rust
Feature 06:
Each measuring disc is 9/32" (7mm) diameter and .025" (0.63mm) thick
Feature 07:
Will measure groove widths .051-1.050" (1.29-26.6mm)
Feature 08:
Will measure land widths from 0-1" and 0-25mm
Feature 09:
Extremely hard and stable one-piece spindle
Feature 10:
Hardened, ground, and lapped measuring discs
Graduations (in):
.001"
Micrometer Type:
Mechanical Groove Micrometers
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/260ZcUSp1.tif
Product Photo 02:
https://s3.us-west-2.amazonaws.com/catsy.833/260ZcUSp2.tif
Product Photo 03:
https://s3.us-west-2.amazonaws.com/catsy.833/260ZcUSa1.tif
Product Title:
260Z Groove Micrometer
Product Type:
Micrometer
Range (in):
.051"-1.050"
Range (mm):
1.29-26.6mm
Short Description:
Groove Micrometer, Speeder Thimble, Disk Anvil, .051-1.050" Range
SLC Certification:
Optional Add-On
Technical Reference 1:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-260-Groove-Micrometer-Instructions_Form-558.pdf
Unit Pack Height (in):
1.6
Unit Pack Item Qty:
1
Unit Pack Length (in):
8.1
Unit Pack Width (in):
5
US List Price:
$542.00
Web Priority-US-EN:
15800005
Unit Pack Weight (lbs):
1.1
Series Title:
260, 260M - Groove Micrometers
Status:
Active
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Cal Prop 65 Warning:
Y
Max. Range (in):
1.050"
Max. Range (mm):
26.6mm
Min. Range (in):
.051"
Min. Range (mm):
1.29mm
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/260ZcUSp1.tif
Groove Width Range:
.050"-1.050"
Land Width Range:
0-1.000"
The Starrett 260 Groove Micrometer quickly and easily measures widths of internal or external grooves and lands. .001" Graduations. Range: .051"-1.050" Groove widths, 0-1.000" Land Widths. 1-5/8" maximum hole depth. Ships with a storage case.
