3807 Ultrasonic Thickness Gage

3807 Ultrasonic Thickness Gage

$1,761.00
(No reviews yet) Write a Review
SKU:
3807
UPC:
049659729801
Conflict Minerals:
N
Contaminated if Opened:
N
Current Catalog:
33
Exists in Comport:
N
Athol Inventory:
0
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Product Group Sort:
testers
Webber Inventory:
0
Website-URL:
https://www.starrett.com/metrology/product-detail/3807
Rocky Mountain Inventory:
0
To Delete:
false
To Remove:
false
Top Seller:
Yes
Total Inventory:
0
US Web Temp Hold:
Off
Fragile:
N
French Language Included:
N
Global Product Classification:
ULTRASONIC THICKNESS GAGE
Hazmat Indicator:
N
Long Description:
Each
Manufacturer's code:
049659
Marked Recyclable:
N
Next Catalog:
34
Product made to order status:
MTO
Promo Item-US-EN:
N
Refrigerant Indicator:
N
Shelf Pack Invoiced:
N
Shelf Pack Shippable:
N
Allow Testimonial:
N
Stocked Locally(Y/N)-US-EN:
N
Subject to Environmental Change:
N
Tariff Code for entry into Mexico:
No
Temperature Sensitive:
N
Top 354:
N
Unit Pack Invoiced:
N
Unit Pack Shippable:
N
Use Placeholder Photo:
N
Variable Unit:
N
Web Price:
$1761.00
Sales Category:
TOOLS.TOOLS (ELECTRONIC & NON-DISCOUNTABLE).
Discontinued:
false
Current Catalog Page:
add
Western Link Inventory:
0
Battery Life:
Approx. 100 hours (w/backlight off)
Frequency:
5MHz
Memory:
20 Groups (100 files/group)
A0006160MSDSINDICATOR:
N
A000670ROHASCOMPLIANT:
N
A002040UCC12UPCA:
049659729801
A002050EANUCC13EAN13:
0049659729801
Accessory:
PT28287
Category:
Precision Measuring Tools > Thickness Testers > Testers
number:
3807
UOM:
Each
01 Attribute:
Type
20 Spec:
245g
Available for Purchase-US-EN:
Y
Category L1:
Handheld Testing Equip
Category L2:
Other Testers
Item Segmentation:
Catalog
NAFTA Producer:
No
Item ID:
3807
Type:
Ultrasonic
PMRA Regulated:
N
Show in Web Nav?:
Yes
US Promo Price:
$0.00
US Web Price:
$1761.00
Web Catalog-US-EN:
Y
Battery Type:
AA alkaline batteries, Qty 2 (Included)
Schedule B Number:
9017.30.8000
Available In Region:
United States|Canada
Mt Airy Inventory:
0
Country of Origin:
China
01 Spec:
Ultrasonic
02 Attribute:
Display Type
02 Spec:
4.5 digit LCD w/Back Light
03 Attribute:
Minimum display unit
03 Spec:
0.001”/0.01mm (selectable)
04 Attribute:
Measuring Range
04 Spec:
Pulse-Echo: 0.025”-23.0” in steel; Echo-Echo: 0.118” – 3.50” Steel (up to 35mil coating)
05 Attribute:
Accuracy
05 Spec:
+/- (0.5% thickness + .001”)
06 Attribute:
Sound Velocity Range
06 Spec:
3280-32805 ft/s (1000-9999m/s)
07 Attribute:
Upper/Lower Limit Preset Alarm
07 Spec:
Yes
08 Attribute:
Scanning Feature
08 Spec:
Yes, 16 measurements/second
09 Attribute:
Operating Temperature
09 Spec:
32-122 degrees F
10 Attribute:
Frequency
10 Spec:
5MHz
11 Attribute:
Update Range
11 Spec:
4Hz
12 Attribute:
Memory
12 Spec:
20 Groups (100 files/group)
13 Attribute:
Output
13 Spec:
USB via output cable
14 Attribute:
Power supply
14 Spec:
Battery
15 Attribute:
Battery Type
15 Spec:
AA alkaline batteries (2pc)
16 Attribute:
Power consumption
16 Spec:
Working current is less than 3V
17 Attribute:
Battery Life
17 Spec:
Approx. 100 hours (w/backlight off)
18 Attribute:
Dimensions LxWxT (in)
18 Spec:
5.90” x 2.91” x 1.30”
19 Attribute:
Weight (oz)
19 Spec:
8.6 oz
20 Attribute:
Weight (g)
Datasheet:
https://s3.us-west-2.amazonaws.com/catsy.833/starrett-3807-ultrasonic-thickness-tester-bulletin-2111.pdf
Dimensions LxWxT (in):
5.90” x 2.91” x 1.30”
Dimensions LxWxT (mm):
150 x 74 x 33mm
EAN:
0049659729801
EDP:
72980
Electronic or Mechanical:
Electronic
Feature 01:
Measuring Range, Pulse-Echo: 0.025" - 23.0" in steel, Echo-Echo: .118" - 3.50", Sound velocity range; 3280 - 32805 ft/s (1000-9999m/s)
Feature 02:
Can measure up to 90mm(3.5") of steel while going through 900 micron (.035") (35mils) of coating - Accuracy; +/- (0.5% thickness + .001")
Feature 03:
Display type; 4.5 -digit LCD w/Back Light, Minimum display unit; 0.001"/0.01mm (selectable), Frequency; 5MHz, Update range; 4Hz,
Feature 04:
Upper/Lower Limit Preset Alarm with Scanning Feature - 16 measurements/second
Feature 05:
Power; 2 AA batteries - Battery life of Approx. 100 hours (backlight off), Size; 5.90" x 2.91" x 1.30" x 8.6oz, Operating Temp; 32-122 degrees F
Feature 06:
Memory; 20 Groups (100 files/group), Output; USB
Measuring Range:
Pulse-Echo: 0.025”-23.0” in steel; Echo-Echo: 0.118” – 3.50” Steel (up to 35mil coating)
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/3807cUSp1.tif
Product Title:
3807 Ultrasonic Thickness Gage
Product Type:
Ultrasonic Thickness Gage
Short Description:
Ultrasonic Thickness Gage
Unit Pack Height (in):
4.1
Unit Pack Item Qty:
1
Unit Pack Length (in):
17.2
Unit Pack Width (in):
10.8
US List Price:
$1761.00
Web Priority-US-EN:
43200014
Weight (g):
245g
Unit Pack Weight (lbs):
3.5
User Manual URL-US-EN:
https://www.starrett.com/um-3807
RoHS (EU):
N
SDS Indicator:
N
Series Title:
3807 Ultrasonic Thickness Gage
Status:
Active
Data Sheet URL-US-EN:
https://www.starrett.com/vdoc/Starrett 3807 Ultrasonic Thickness Tester (Bulletin 2111)
Cal Prop 65 Warning:
N
Display Type:
4.5 digit LCD w/Back Light
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/3807cUSp1.tif
Operating Temperature:
32-122 degrees F
Accuracy:
+/- (0.5% thickness + .001”)
Weight (oz):
8.6 oz
State of the art, digital ultrasonic thickness Gage is packed with features typically found on high end models only. The 3807 Ultrasonic Thickness Gage offers everything from basic measurement, Thru Coating capabilities, Scanning Capabilities, Adjustable Sound Velocity, extended memory and USB output capabilities. This dynamic ultrasonic thickness gauge is designed to measure the thickness of metallic and non-metallic materials such as steel, aluminum, titanium, plastics, ceramics, glass and other ultrasonic wave conductors with parallel top and bottom surfaces. Accurately displays readings in either inch or millimeter after a simple calibration to a known thickness or sound velocity.
