3812 Ultrasonic Thickness Gage

3812 Ultrasonic Thickness Gage

$1,654.20
(No reviews yet) Write a Review
SKU:
3812
UPC:
049659676686
Category:
Precision Measuring Tools > Thickness Testers > Testers
Country of Origin :
China
Datasheet:
https://s3-us-west-2.amazonaws.com/catsy.833/3812-ultrasonic-thickness-tester-bulletin-579.pdf
Data Sheet URL-EN-GB:
http://www.starrett.com/docs/data-sheets/3812-Ultrasonic-Thickness-Tester---Bulletin-579.pdf?Status=Master
Data Sheet URL-US-EN:
https://www.starrett.com/vdoc/3812 Ultrasonic Thickness Tester (Bulletin 579)
EAN:
0049659676686
EDP:
67668
Feature 01:
Accuracy: +/- (0.5% thickness + .001")
Feature 02:
Power supply: Two 3V AA alkaline batteries with approximately 100hours of life (with the backlight off)
Feature 03:
32-122 DegF operating temperature
Feature 04:
20 memory groups (100 files/group)
Athol Inventory:
56
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada|New Zealand
Description:
Ultrasonic Thickness Gage is a menu driven, multifunctional tester with basic measurement
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Mt Airy Inventory :
0
ORS Part Numbers :
681-67668
Product Group Sort:
testers
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=3812
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Top Seller:
Yes
Total Inventory:
56
US Web Temp Hold:
Off
Global Product Classification:
ULTRASONIC THICKNESS GAGE
Item Segmentation:
Catalog
Long Description:
Each
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/3812e67668cUSp1.tif
Manufacturer's code:
049659
NAFTA Producer:
No
Name:
ULTRASONIC THICKNESS GAGE
Item ID:
3812
Other Tester Type:
Ultrasonic Thickness Tester
Product made to order status:
MTA
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/3812e67668cUSp1.tif
Product Photo 02:
https://s3-us-west-2.amazonaws.com/catsy.833/3812cUSp2.tif
Product Title:
3812 Ultrasonic Thickness Gage
Promo Item-EN-GB:
N
Promo Item-US-EN:
N
Range:
0.040-12.0" measuring range (in steel with standard probe)
Resolution:
0.001" (0.01mm) selectable
Series Title:
3812 Ultrasonic Thickness Gage
Short Description:
Ultrasonic Thickness Gage, .040-12", 0.001"/0.01mm, 0.5% thickness + .001", 32-122 Deg F
Status:
Active
A002040UCC12UPCA:
049659676686
A002050EANUCC13EAN13:
0049659676686
Tariff Code for entry into Mexico:
No
Top 354:
Y
Unit Pack Height (in):
4.1
Unit Pack Height (mm):
93.98
Unit Pack Invoiced:
N
Unit Pack Item Qty:
1
Unit Pack Length (in):
17.2
Unit Pack Length (mm):
259.08
Unit Pack Shippable:
N
Unit Pack Weight (kg):
1.2246984
Unit Pack Weight (lbs):
3.5
Unit Pack Width (in):
10.8
Unit Pack Width (mm):
330.2
UOM:
Each
UPC:
049659676686
Use Placeholder Photo:
N
User Manual URL-US-EN:
https://www.starrett.com/um-3812
US List Price:
$1838.00
US Next List Price:
$1838.00
US Web Price:
$1654.20
Web Catalog-EN-GB:
Y
Web Catalog-ES-ES:
Y
Web Catalog-US-EN:
Y
Web Price:
$1838.00
Web Priority-EN-GB:
1124
Web Priority-ES-ES:
1124
Web Priority-US-EN:
43200015
Electronic or Mechanical:
Electronic
Category L1:
Handheld Testing Equip
Category L2:
Other Testers
Sales Category:
TOOLS.TOOLS (ELECTRONIC & NON-DISCOUNTABLE).
01 Attribute :
Type
01 Spec:
Ultrasonic
02 Attribute:
Display Type
02 Spec:
4.5 digits LCD with EL backlight
Discontinued:
false
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Current Catalog:
33
Current Catalog Page:
248
Catalog Section Page:
18
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-09-Gage-Amps-Hardness-and-Surface-Testers.pdf
Brochure 1:
https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
SLC Certification:
Not Applicable
Western Link Inventory:
0
Dimensions LxWxT (in):
6 " x 3" x 1-1/2"
Dimensions LxWxT (mm):
150 x 74 x 32mm
Display Type:
4.5 digits LCD with EL backlight
Battery Life:
100 hours typical operating time (backlight off).
Measuring Range:
0.030” – 12.0” (0.75～300mm) (in Steel)
Memory:
Stores up to 20 files (up to 99 values for each file) of stored values.
Operating Temperature:
0-50°c Humidity < 80%
Type:
Ultrasonic
Accuracy:
(± 0.5%Thickness+0.001”) depends on materials and conditions
Weight (g):
245g
Weight (oz):
8.6 oz
03 Attribute:
Measuring Range
03 Spec:
0.030” – 12.0” (0.75～300mm) (in Steel)
04 Attribute:
Resolution
04 Spec:
0.001" (0.01mm) selectable
05 Attribute:
Accuracy
05 Spec:
(± 0.5%Thickness+0.001”) depends on materials and conditions
06 Attribute:
Pulse Rate
06 Spec:
Four measurement readings per second for single point measurement, and ten per second for Scan Mode.
07 Attribute:
Sound Velocity Range
07 Spec:
3280-32805 ft/s (1000~9999 m/s)
08 Attribute:
Operating Temperature
08 Spec:
0-50°c Humidity < 80%
09 Attribute:
Memory
09 Spec:
Stores up to 20 files (up to 99 values for each file) of stored values.
10 Attribute:
Output
10 Spec:
USB via output cable
11 Attribute:
Power supply
11 Spec:
Two “AA” size, 1.5 Volt alkaline batteries.
12 Attribute:
Battery Life
12 Spec:
100 hours typical operating time (backlight off).
13 Attribute:
Dimensions LxWxT (in)
13 Spec:
6 " x 3" x 1-1/2"
14 Attribute:
Dimensions LxWxT (mm)
14 Spec:
150 x 74 x 32mm
15 Attribute:
Weight (oz)
15 Spec:
8.6 oz
16 Attribute:
Weight (g)
16 Spec:
245g
Adding to cart… The item has been added
Ultrasonic Thickness Gage is a menu driven, multifunctional tester with basic measurement capabilities. This gage is designed to measure the thickness of metallic and non-metallic materials such as aluminum, titanium, plastics, ceramics, glass and any other good ultrasonic wave conductor, as long as it has parallel top and bottom surfaces. The 3812 will accurately display readings in either inch or millimeter after a simple calibration to a known thickness or sound velocity.
