3813 Coating Thickness Gage

3813 Coating Thickness Gage

$877.00
(No reviews yet) Write a Review
SKU:
3813
UPC:
049659698831
Athol Inventory:
3
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Product Group Sort:
testers
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=3813
Rocky Mountain Inventory:
0
To Delete:
false
To Remove:
false
Top Seller:
Yes
Total Inventory:
3
US Web Temp Hold:
Off
Global Product Classification:
COATING THICKNESS GAUGE
Long Description:
Each
Manufacturer's code:
049659
Product made to order status:
MTO
Promo Item-US-EN:
N
Tariff Code for entry into Mexico:
No
Top 354:
N
Use Placeholder Photo:
N
Web Price:
$877.00
Sales Category:
TOOLS.TOOLS (ELECTRONIC & NON-DISCOUNTABLE).
Discontinued:
false
Current Catalog:
33
Current Catalog Page:
249
Western Link Inventory:
0
brochure:
https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
categoryl1:
Handheld Testing Equip
categoryl2:
Other Testers
number:
3813
A002040UCC12UPCA:
049659698831
A002050EANUCC13EAN13:
0049659698831
Category:
Precision Measuring Tools > Thickness Testers > Testers
UOM:
Each
01 Attribute:
Type
Available for Purchase-US-EN:
Y
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-09-Gage-Amps-Hardness-and-Surface-Testers.pdf
Catalog Section Page:
19
Category L1:
Handheld Testing Equip
Category L2:
Other Testers
Item Segmentation:
Catalog
NAFTA Producer:
No
Item ID:
3813
Type:
Digital
Show in Web Nav?:
Yes
US Promo Price:
$0.00
US Web Price:
$877.00
Web Catalog-US-EN:
Y
Battery Type:
AAA alkaline batteries, Qty 2 (Included)
Schedule B Number:
9017.30.8000
Available In Region:
United States|Canada
Mt Airy Inventory:
0
ORS Part Numbers:
681-3813
Country of Origin:
China
01 Spec:
Digital
02 Attribute:
Display Type
02 Spec:
4 digits, 10mm LCD
03 Attribute:
Measuring Range
03 Spec:
0-1000μm / 0-40 mil
04 Attribute:
Resolution
04 Spec:
0.1μm/0.1mils (0-99μm) or 1μm (over 100μm)
05 Attribute:
Accuracy
05 Spec:
+/- 1-3%n or 2μm (whichever is greater)
06 Attribute:
Dimensions LxWxT (in)
06 Spec:
6.3” x 2.7” x 1.2”
07 Attribute:
Dimensions LxWxT (mm)
07 Spec:
161 x 69 x 32mm
08 Attribute:
Weight (oz)
08 Spec:
9 oz
09 Attribute:
Weight (g)
09 Spec:
260g
10 Attribute:
Power supply
10 Spec:
Battery
11 Attribute:
Battery Type
11 Spec:
AAA alkaline batteries, Qty 2 (Included)
Brochure 1:
https://s3.us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
Catalog:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Datasheet:
https://s3.us-west-2.amazonaws.com/catsy.833/3813-coating-thickness-gage-brochure-581.pdf
Dimensions LxWxT (in):
6.3” x 2.7” x 1.2”
Dimensions LxWxT (mm):
161 x 69 x 32mm
EAN:
0049659698831
EDP:
69883
Electronic or Mechanical:
Electronic
Feature 01:
Guaranteed tolerance: After one-point calibration: +/- 1-3%n or 2 um (whichever is greater)
Feature 02:
Min. measuring area: 0.2" x 0.2" (5mm x 5mm)
Feature 03:
Minimum radius of curvature: Convex: 0.12" (3mm), Concave: 1.2" (30mm)
Feature 04:
Minimum substrate thickness: Ferrous: 20 mils (0.5mm), Non-ferrous: 2 mils (50)
Feature 05:
Maximum surface temperature of test object: 302 F (maximum contact time 2 seconds)
Measuring Range:
0-1000μm / 0-40 mil
Orderable Online Today (US Only):
Yes
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/3813cUSp1.tif
Product Photo 02:
https://s3.us-west-2.amazonaws.com/catsy.833/3813cUSp2.tif
Product Title:
3813 Coating Thickness Gage
Product Type:
Coating Thickness Gage
Short Description:
Coating Thickness Gage, 0-40mils/0-1000 um, +/- 1-3%n or 2 um, 302 F
Unit Pack Height (in):
2.3
Unit Pack Item Qty:
1
Unit Pack Length (in):
13.4
Unit Pack Width (in):
8.4
US List Price:
$877.00
Web Priority-US-EN:
43200020
Weight (g):
260g
Unit Pack Weight (lbs):
1.95
User Manual URL-US-EN:
https://www.starrett.com/UM-3813
Series Title:
3813 Coating Thickness Gage
Status:
Active
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Data Sheet URL-US-EN:
https://www.starrett.com/vdoc/3813 Coating Thickness Gage (Brochure 581)
Display Type:
4 digits, 10mm LCD
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/3813cUSp1.tif
Other Tester Type:
Coating Thickness Gage
Range:
0-40mils (0-1000μm) max.
Resolution:
0.1μm/0.1mils (0-99μm) or 1μm (over 100μm)
Accuracy:
+/- 1-3%n or 2μm (whichever is greater)
Weight (oz):
9 oz
Adding to cart… The item has been added
Coating Thickness Gage is state-of-the-art thickness gage that utilizes the characteristics of both eddy current and magnetic induction to perform two types of thickness calculation. The gage uses an integrated probe to automatically determine whether the substrate is ferrous or non-ferrous, then it either detects the thickness of non-magnetic coating on a magnetic substrate (ferrous) or the insulating coating on a non-magnetic conductive substrate (nonferrous). Testing performance is non-destructive and extremely accurate. Ideal for a broad range of applications in manufacturing, engineering and commercial inspection.
