443Z-6RL Micrometer Depth Gage with Half Base

443Z-6RL Micrometer Depth Gage with Half Base

$450.00
(No reviews yet) Write a Review
SKU:
443Z-6RL
UPC:
049659521733
Case Type:
Padded Case
Category:
Precision Measuring Tools > Precision Hand Tools > Micrometers > Depth Micrometers
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Depth Micrometer Type:
Mechanical
EAN:
0049659521733
EDP:
52173
Accessory:
PT99341|PT99342|PT99343|PT99344|PT99345|PT99346|PT99347|PT99348|PT99349|PT99358|PT99359|PT99360
Feature 01:
The depths of holes, slots, shoulders and projections can be measured with these fine tools
Feature 02:
2" (50mm) half base permits measuring depths of holes and slots close to shoulders and between obstructions
Feature 03:
Combination ratchet and speeder for uniform pressure and quicker adjustment
Feature 04:
Rods have individual length adjustment and are 5/32" (4mm) in diameter
Feature 05:
Ring-type knurled lock nut for quick and sure locking
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Base Length (in):
2" - Half Base
Flat Stock Inventory:
0
Item Class:
Stand-Alone
Max. Range (in):
6
Min. Range (in):
0
Parent SKU As a Regular Field:
443
Product Group Sort:
icc110105
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=443Z-6RL
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
MICROMETER DEPTH GAGE 0-6", WITH HALF BASE
Graduations (in):
.001"
Item Segmentation:
Catalog
Lock Nut Type:
Ring Type Knurled
Long Description:
Each
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/443Z-6RLcUSp1.tif
Manufacturer's code:
049659
Measuring Rods (qty):
6
Micrometer Type:
Depth
NAFTA Producer:
Yes
Item ID:
443Z-6RL
POA Flag:
N
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/443Z-6RLcUSp1.tif
Product Title:
443Z-6RL Micrometer Depth Gage with Half Base
Range (in):
0-6"
Rod Diameter (in):
5/32"
SDS Indicator:
N
Series Title:
443 Micrometer Depth Gages with Half Base
Shelf Pack Item Qty:
1
Shelf Pack Pricing Quantity:
1
Short Description:
Micrometer Depth Gage with Half Base, Ratchet Thimble, 0-6" Range, .001"
Status:
Active
A0006160MSDSINDICATOR:
N
A002040UCC12UPCA:
049659521733
A002050EANUCC13EAN13:
0049659521733
Accuracy (in):
Mic head +/- .0001"; Rods +/- .0002"
Tariff Code for entry into Mexico:
Yes
Thimble Type:
Ratchet
Top 354:
N
Unit Pack Height (in):
1.5
Unit Pack Height (mm):
35.56
Unit Pack Item Qty:
1
Unit Pack Length (in):
11.4
Unit Pack Length (mm):
287.02
Unit Pack Weight (kg):
0.907184
Unit Pack Weight (lbs):
1.95
Unit Pack Width (in):
5.4
Unit Pack Width (mm):
134.62
UOM:
Each
Use Placeholder Photo:
N
US List Price:
$450.00
Web Catalog-US-EN:
Y
Web Price:
$450.00
Web Priority-US-EN:
13800140
Electronic or Mechanical:
Mechanical
Starrett Model No.:
443
01 Spec:
Depth
02 Attribute:
Electronic or Mechanical
02 Spec:
Mechanical
03 Attribute:
Range (in)
03 Spec:
0-6"
04 Attribute:
Accuracy (in)
04 Spec:
Mic head +/- .0001"; Rods +/- .0002"
05 Attribute:
Graduations (in)
05 Spec:
.001"
06 Attribute:
Lock Nut Type
06 Spec:
Ring Type Knurled
07 Attribute:
Base Length (in)
07 Spec:
2" - Half Base
08 Attribute:
Measuring Rods (qty)
08 Spec:
6
09 Attribute:
Rod Diameter (in)
09 Spec:
5/32"
10 Attribute:
Thimble Type
10 Spec:
Ratchet
11 Attribute:
Case Type
11 Spec:
Padded Case
Dimensional Drawing PDF:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-443Z-6RL-Dimensional-Drawing.pdf
Dimensional Drawing (IMG):
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-443Z-6RL-Dimensional-Drawing.tif
Discontinued:
false
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Current Catalog:
33
Current Catalog Page:
87
Catalog Section Page:
69
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-01-Micrometers.pdf
Western Link Inventory:
0
Category L1:
Micrometers
Category L2:
Depth Micrometers
US Web Price:
$450.00
US Promo Price:
$0.00
01 Attribute:
Micrometer Type
COO Detail:
Made in the USA with US and Global Content
Schedule B Number:
9017.30.8000
Product made to order status:
MTO
Available In Region:
United States|Canada
Mt Airy Inventory:
0
Product Type:
Depth Micrometer
Country of Origin:
United States
The Starrett Micrometer Depth Gage with half base features a combination ratchet and speeder, ring-type locknut, ratchet stop and locknut. 0-6" Range, .001" Grad, 6 Rods, Ratchet Stop, Lock Nut, Case.
