The Starrett 469M Series Large, Super-Precision Micrometer Head is our most accurate micrometer head. It is also available on special order with double graduations in red and black on the sleeve and thimble, permitting readings both ways with the spindle moving in either direction. This micrometer head has a 103mm thimble diameter and is graduated to 0.001mm for direct reading. It also has staggered graduations for easy counting and reading of lines. Spindle is carbide faced for long life. 0-25mm Range, 0.001mm Grad with Speeder, Carbide Face.
469MHXSP Large, Super-Precision Micrometer Head
$1,507.00
- SKU:
- 469MHXSP
- UPC:
- 049659671315
- Category:
- Precision Measuring Tools > Precision Hand Tools > Micrometers > Micrometer Heads
- Cal Prop 65 Chemical:
- Lead
- Cal Prop 65 Warning:
- Y
- Cal Prop 65 Statement:
- WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
- Country of Origin :
- United States
- EAN:
- 0049659671315
- EDP:
- 67131
- Accessory:
- 247MA|247MB|247MD|247ME
- Feature 01:
- Starrett satin chrome finish - no glare - resists rust on all reading surfaces
- Feature 02:
- Advanced sleeve design with staggered lines and distinct figures for precise and easy readability
- Feature 03:
- Quick-reading figures
- Feature 04:
- Extremely hard and stable one-piece spindle (the heart of our accuracy and long life)
- Feature 05:
- Micro-lapped measuring face for flatness and squareness
- Feature 06:
- Quick and easy adjustment
- Assembled in US:
- N
- Athol Inventory:
- 0
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Description:
- MICROMETER HEAD
- Flat Stock Inventory:
- 0
- Item Class:
- Stand-Alone
- Max. Range (mm):
- 25
- Min. Range (mm):
- 0
- Mt Airy Inventory :
- 0
- Parent SKU As a Regular Field:
- 468
- Product Group Sort:
- icc110106
- Webber Inventory:
- 0
- Website-URL:
- https://www.starrett.com/details?cat-no=469MHXSP
- Rocky Mountain Inventory:
- 0
- Show in Web Nav?:
- Yes
- To Delete:
- false
- To Remove:
- false
- Total Inventory:
- 0
- US Web Temp Hold:
- Off
- Global Product Classification:
- MICROMETER HEAD
- Graduations (mm):
- 0.001mm
- Item Segmentation:
- Catalog
- Long Description:
- Each
- Made in America:
- Yes
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/469MHXSPcUSp1.tif
- Manufacturer's code:
- 049659
- Material:
- Steel
- Micrometer Type:
- Mechanical Micrometer Head
- NAFTA Producer:
- Yes
- Name:
- MICROMETER HEAD
- Item ID:
- 469MHXSP
- POA Flag:
- N
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/469MHXSPcUSp1.tif
- Product Title:
- 469MHXSP Large, Super-Precision Micrometer Head
- Range (mm):
- 0-25mm
- Series Title:
- 469X, 469XM Large, Super-Precision Micrometer Heads
- Shelf Pack Item Qty:
- 1
- Shelf Pack Pricing Quantity:
- 1
- Short Description:
- Large, Super-Precision Micrometer Head, Plain Thimble, 0-25mm Range, 0.0001mm
- Spindle Material:
- Carbide
- Spindle Type:
- Flat
- Status:
- Active
- A002040UCC12UPCA:
- 049659671315
- A002050EANUCC13EAN13:
- 0049659671315
- Accuracy (mm):
- +/-.00075mm
- Tariff Code for entry into Mexico:
- Yes
- Thimble Type:
- Plain
- Top 354:
- N
- Unit Pack Height (in):
- 5.2
- Unit Pack Height (mm):
- 127
- Unit Pack Invoiced:
- N
- Unit Pack Item Qty:
- 1
- Unit Pack Length (in):
- 9.6
- Unit Pack Length (mm):
- 185.42
- Unit Pack Pricing Unit of Measure:
- EA
- Unit Pack Shippable:
- N
- Unit Pack Weight (kg):
- 0.9979024
- Unit Pack Weight (lbs):
- 2.3
- Unit Pack Width (in):
- 5.3
- Unit Pack Width (mm):
- 134.62
- UOM:
- Each
- UPC:
- 049659671315
- Use Placeholder Photo:
- N
- US List Price:
- $1507.00
- US Next List Price:
- $1507.00
- US Web Price:
- $1507.00
- Web Catalog-US-EN:
- Y
- Web Price:
- $1507.00
- Web Priority-US-EN:
- 14200120
- Electronic or Mechanical:
- Mechanical
- Starrett Model No.:
- 469
- Category L1:
- Micrometers
- Category L2:
- Micrometer Heads
- 01 Attribute :
- Micrometer Type
- 01 Spec:
- Mechanical Micrometer Head
- 02 Attribute:
- Electronic or Mechanical
- 02 Spec:
- Mechanical
- 03 Attribute:
- Range (mm)
- 03 Spec:
- 0-25mm
- 04 Attribute:
- Accuracy (mm)
- 04 Spec:
- +/-.00075mm
- 05 Attribute:
- Graduations (mm)
- 05 Spec:
- 0.001mm
- 06 Attribute:
- Thimble Type
- 06 Spec:
- Plain
- 07 Attribute:
- Spindle Type
- 07 Spec:
- Flat
- 08 Attribute:
- Spindle Material
- 08 Spec:
- Carbide
- Discontinued:
- false
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- Current Catalog:
- 33
- Current Catalog Page:
- 72
- Catalog Section Page:
- 54
- Catalog:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- Catalog Section:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-01-Micrometers.pdf
- Western Link Inventory:
- 0
