673XZ Direct-Reading Bench Micrometer

673XZ Direct-Reading Bench Micrometer

$5,111.00
(No reviews yet) Write a Review
SKU:
673XZ
UPC:
049659671919
Category:
Precision Measuring Tools > Precision Hand Tools > Micrometers > Bench
Cal Prop 65 Chemical:
Lead, Beryllium
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
EAN:
0049659671919
EDP:
67191
Feature 01:
Quick reading graduations
Feature 02:
High accuracy
Feature 03:
Adjustable work table centered beneath the anvil and spindle
Feature 04:
No glare Starrett satin chrome finish
Feature 05:
Base is a heavy, rigid casting, incorporating at the left end a movable anvil
Feature 06:
Friction-free motion transfer mechanism between the anvil and the indicator
Feature 07:
Furnished with a speeder
Feature 08:
Ring-type knurled lock nut for quick and sure locking
Feature 09:
Spindle and anvil are carbide faced
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada
Flat Stock Inventory:
0
Item Class:
Stand-Alone
Mt Airy Inventory :
0
Product Group Sort:
bench
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=673XZ
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
BENCH MICROMETER, 0-2", .0001" GRADS
Item Segmentation:
Catalog
Long Description:
Each
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/673XZ.tif
Manufacturer's code:
049659
Micrometer Type:
Direct-Reading Bench Micrometer
NAFTA Producer:
Yes
Item ID:
673XZ
POA Flag:
N
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/673XZ.tif
Product Photo 02:
https://s3-us-west-2.amazonaws.com/catsy.833/673XZe67191cUSa1.tif
Product Title:
673XZ Direct-Reading Bench Micrometer
Range (in):
0-2"
Series Title:
673X, 673MX Direct-Reading Bench Micrometers
Short Description:
Direct-Reading Bench Micrometer, Speeder Thimble, Carbide Anvil, 0-2" Range
Status:
Active
A002040UCC12UPCA:
049659671919
A002050EANUCC13EAN13:
0049659671919
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (in):
10.6
Unit Pack Height (mm):
269.24
Unit Pack Item Qty:
1
Unit Pack Length (in):
25
Unit Pack Length (mm):
635
Unit Pack Pricing Unit of Measure:
EA
Unit Pack Weight (kg):
14.8324584
Unit Pack Weight (lbs):
32.7
Unit Pack Width (in):
10.3
Unit Pack Width (mm):
261.62
UOM:
Each
Use Placeholder Photo:
N
US List Price:
$5111.00
US Web Price:
$5111.00
Web Catalog-US-EN:
Y
Web Price:
$5111.00
Web Priority-US-EN:
19400015
Electronic or Mechanical:
Mechanical
Starrett Model No.:
673
01 Spec:
Direct-Reading Bench Micrometer
02 Attribute:
Electronic or Mechanical
02 Spec:
Mechanical
03 Attribute:
Range (in)
03 Spec:
0-2"
04 Attribute:
Micrometer Head Range (in)
04 Spec:
0-2"
05 Attribute:
Dial Indicator Range (in)
05 Spec:
.006" (0-3-0)
06 Attribute:
Micrometer Head Graduations (in)
06 Spec:
.0001"
07 Attribute:
Work Table
07 Spec:
2-1/4" dia. and 7/8" vertical adjustment
Work Table:
2-1/4" dia. and 7/8" vertical adjustment
Micrometer Head Graduations (in):
.0001"
Dial Indicator Range (in):
.006" (0-3-0)
Micrometer Head Range (in):
0-2"
Discontinued:
false
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Current Catalog:
33
Current Catalog Page:
75
Catalog Section Page:
57
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-01-Micrometers.pdf
Western Link Inventory:
0
Category L1:
Micrometers
Category L2:
Bench Micrometers
US Promo Price:
$0.00
01 Attribute:
Micrometer Type
The Starrett 673 Bench Micrometer is a high precision instrument, ideal for bench use either in a shop environment or inspection laboratory. It can be used as a comparator measuring to fifty-millionths of an inch (.000050") or two-thousandths of a mm (0.002mm) or for direct measuring to .0001" or 0.002mm. Work lengths up to 2" or 50mm can be measured. Head: 0-2" Range, .0001" Grad with Case, Carbide Face.
