696Z Crankshaft Distortion Dial/Strain Gage

696Z Crankshaft Distortion Dial/Strain Gage

$875.00
(No reviews yet) Write a Review
SKU:
696Z
UPC:
049659529012
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog URL:
https://www.starrett.com/dms/flipbooks/Cat-33/index.html?page=195
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Category:
Precision Measuring Tools > Precision Hand Tools > Indicators & Gages > Strain Gages
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Country of Origin :
United States
Current Catalog Page:
195
Dial Reading:
0-20-0 / .040" Rev.
EAN:
0049659529012
EDP:
52901
Feature 01:
The dial indicator movement is approximately 5/32" (4mm) and with rods and extension, provides a range from 2 3/8-18" or 61-458mm
Feature 02:
There are 10 rods and one extension furnished
Feature 03:
Rods are marked to designate the approximate overall length of the gage
Feature 04:
Indicator has a movable bezel to adjust the dial in relation to the hand and a non-breakable crystal
Feature 05:
Gage is used by inspectors to check the distortion of engine shafts and frames
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada
Description:
Ideal gage for checking bearing alignment or shaft deflection without dismantling the engine. Also
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Max. Range (in):
18
Min. Range (in):
2.375
Mt Airy Inventory :
0
ORS Part Numbers :
681-52901
Parent SKU As a Regular Field:
696
Product Group Sort:
icc110507_strain_gages
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=696Z
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Top Seller:
Yes
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
STRAIN GAGE WITH 696B BALANCING ATTACHMENT
Graduations (in):
.001"
Item Segmentation:
Catalog
Long Description:
Each
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/696ZcUSp1.tif
Manufacturer's code:
049659
NAFTA Producer:
Yes
Name:
STRAIN GAGE WITH 696B BALANCING ATTACHMENT
Item ID:
696Z
POA Flag:
N
Product made to order status:
MTA
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/696ZcUSp1.tif
Product Title:
696Z Crankshaft Distortion Dial/Strain Gage
Range (in):
2-3/8" to 18"
SDS Indicator:
N
Series Title:
696,696M Crankshaft Distortion Dial/Strain Gages
Shelf Pack Item Qty:
1
Shelf Pack Pricing Quantity:
1
Short Description:
Crankshaft Distortion Dial/Strain Gage with Balancing Attachment, 2-3/8" to 18" Range, .001" Grads, 0-20-0 Dial Face
Special Function Dial Gage Type:
Strain Gage
Status:
Active
A0006160MSDSINDICATOR:
N
A002040UCC12UPCA:
049659529012
A002050EANUCC13EAN13:
0049659529012
Tariff Code for entry into Mexico:
Yes
Top 354:
Y
Unit Pack Height (in):
2.5
Unit Pack Height (mm):
63.5
Unit Pack Item Qty:
1
Unit Pack Length (in):
15.6
Unit Pack Length (mm):
393.7
Unit Pack Weight (kg):
1.2246984
Unit Pack Weight (lbs):
2.85
Unit Pack Width (in):
5.5
Unit Pack Width (mm):
137.16
UOM:
Each
UPC:
049659529012
Use Placeholder Photo:
N
US List Price:
$875.00
US Next List Price:
$875.00
US Web Price:
$875.00
Web Catalog-EN-GB:
Y
Web Catalog-ES-ES:
Y
Web Catalog-US-EN:
Y
Web Price:
$875.00
Web Priority-EN-GB:
14
Web Priority-ES-ES:
14
Web Priority-US-EN:
25600010
Electronic or Mechanical:
Mechanical
Category L1:
Indicators & Gages
Category L2:
Strain Gages
Sales Category:
TOOLS.HARDWARE TOOLS (DISCOUNTABLE).
01 Attribute :
Range (in)
01 Spec:
2-3/8" to 18"
02 Attribute:
Graduations (in)
02 Spec:
.001"
03 Attribute:
Dial Reading
03 Spec:
0-20-0 / .040" Rev.
Discontinued:
false
Catalog Section Page:
63
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-05-Dial-and-Electronic-Indicators-and-Gages.pdf
Western Link Inventory:
0
Ideal gage for checking bearing alignment or shaft deflection without dismantling the engine. Also useful as a strain gage on engine frames. This inside measuring gage checks the distortion of crankshaft webs and bears a direct relation to existing misalignment or excessive bearing wear. Used on all diesel engine shafts and center crankshafts on any type of engine or compressor, the gage can also be applied as a strain gage on engine frames while the engine is operating. A comparison of readings taken at top and bottom positions indicates any misalignment of cylinder and frame which results in local over-stress and eventual cracking of the frame neck. Gage with Balancing Attachment, 2 3/8-18" Range neck.
