The Starrett 756.1 Series Electronic Disc-Type Micrometer with Rotating Spindle with Output is a full-featured precision measuring tool built with customary Starrett quality and workmanship. These tools are used to measure the thickness of work sections such as ribs, lands, fins, cutting edges on form tools, and chordal thickness of gear teeth. Because of their large anvil and spindle faces, the 1" and 25mm sizes are also useful for measuring the thickness of sheet materials like paper, cardboard, rubber, and plastics. Its no-glare satin chrome finish minimizes annoying surface glare under bright lights indoors or filters out UV light. With an accuracy of 0.00015"in measuring over the whole surface, Starrett electronic micrometers guarantee a precise measurement at every position each and every time. 25-50mm (1-2") Range without Case.
756.1MEFL-50 Electronic Disc-Type Micrometer
$721.00
- SKU:
- 756.1MEFL-50
- UPC:
- 049659728699
- Case Study:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Datasure-4-Whitepaper-RYE.pdf
- Category:
- Precision Measuring Tools > Precision Hand Tools > Micrometers > Disc Micrometers
- Cal Prop 65 Chemical:
- Lead
- Cal Prop 65 Warning:
- Y
- Cal Prop 65 Statement:
- WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
- Conflict Minerals:
- N
- Contaminated if Opened:
- N
- Country of Origin :
- United States
- EAN:
- 0049659728699
- EDP:
- 72869
- Exists in Comport:
- N
- Accessory:
- 3206
- Feature 01:
- IP67 protection against coolants, water, chips, dust and dirt
- Feature 02:
- Starrett no-glare satin chrome finish on thimble and sleeve
- Feature 03:
- Large, easy-to-read .275 (7mm) high contrast LCD digital readout
- Feature 04:
- Extremely hard and stable one-piece spindle
- Feature 05:
- Auto Off after 20 minutes of nonuse
- Feature 06:
- Inch/millimeter conversion on English versions
- Feature 07:
- Smooth friction thimble for uniform pressure
- Feature 08:
- Measurement HOLD button
- Feature 09:
- Zero at any position
- Feature 10:
- Retain and return to true zero reading
- Feature 11:
- Spindle lock
- Feature 12:
- Data Output
- Feature 13:
- Resolution: .00005" (0.001mm)
- Feature 14:
- Accuracy +/-.0001 (+/-.002mm)
- Feature 15:
- PRESET button to install any reading at any position
- Feature 16:
- Ability to install minimum and maximum limits
- Athol Inventory:
- 1
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Brochure URL-US-EN:
- https://www.starrett.com/vdoc/Starrett Electronic Precision Hand Tools (Bulletin 590)
- Description:
- The Starrett 756.1 Series Electronic Disc-Type Micrometer with Rotating Spindle with Output is a
- Flat Stock Inventory:
- 0
- In Sugar Catalog:
- Yes
- Item Class:
- Stand-Alone
- Max. Range (in):
- 2
- Max. Range (mm):
- 50
- Min. Range (in):
- 1
- Min. Range (mm):
- 25
- Mt Airy Inventory :
- 0
- Parent SKU As a Regular Field:
- 756.1
- Product Group Sort:
- disc_micrometers
- Webber Inventory:
- 0
- Website-URL:
- https://www.starrett.com/details?cat-no=756.1MEFL-50
- Rocky Mountain Inventory:
- 0
- Show in Web Nav?:
- Yes
- To Delete:
- false
- To Remove:
- false
- Total Inventory:
- 1
- US Web Temp Hold:
- Off
- Fragile:
- N
- French Language Included:
- N
- Global Product Classification:
- MICROMETER - DISK TYPE 50MM
- Hazmat Indicator:
- N
- Item Segmentation:
- Catalog
- Lock Nut Type:
- Lever
- Long Description:
- Each
- Made in America:
- Yes
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/Missing-Image-Sign.tif
- Manufacturer's code:
- 049659
- Marked Recyclable:
- N
- Micrometer Type:
- Electronic Disc-Type Micrometer with rotating spindle (with output)
- Name:
- MICROMETER - DISK TYPE 50MM
- Next Catalog:
- 34
- Item ID:
- 756.1MEFL-50
- Other Document 1 URL-US-EN:
- https://www.starrett.com/vdoc/Starrett DataSure 4.0 (Bulletin 591)
- Other Document 2 URL-US-EN:
- https://www.starrett.com/vdoc/DataSure 4.0 Whitepaper
- Other Document 3 URL-US-EN:
- https://www.starrett.com/vdoc/DS 4.0 at Roush Yates Engines
- Type:
- Micrometer - Disc
- Placeholder Photo:
- https://s3-us-west-2.amazonaws.com/catsy.833/756.1FL-1e72808cUSp1.tif
- PMRA Regulated:
- N
- Product made to order status:
- MTO
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/Missing-Image-Sign.tif
- Product Photo 02:
- https://s3-us-west-2.amazonaws.com/catsy.833/756.1FL-1e72808cUSp1.jpg
- Product Title:
- 756.1MEFL-50 Electronic Disc-Type Micrometer
- Range (in):
- 1-2"
- Range (mm):
- 25-50mm
- Refrigerant Indicator:
- N
- Resolution (in):
- .00005"
- Resolution (mm):
- 0.001mm
- RoHS (EU):
- N
- SDS Indicator:
- N
- Series Title:
- 756.1 Electronic Digital Disc Type Micrometers
- Shelf Pack Invoiced:
- N
- Shelf Pack Shippable:
- N
- Short Description:
- Digital Disc Type Micrometer, Friction Thimble, SPC Output, 0.001mm, 25-50mm Range
- SPC Output:
- Yes
- Spindle Type:
- Flat Disk
- Status:
- Active
- A0006160MSDSINDICATOR:
- N
- A000670ROHASCOMPLIANT:
- N
- A002040UCC12UPCA:
- 049659728699
- A002050EANUCC13EAN13:
- 0049659728699
- Accuracy (in):
- +/-.0001"
- Accuracy (mm):
- +/-.002mm
- Anvil Type:
- Flat Disk
- Anvil/Spindle Material:
- Steel
- Subject to Environmental Change:
- N
- Temperature Sensitive:
- N
- Thimble Graduations:
- Metric
- Thimble Type:
- Friction
- Top 354:
- N
- Unit Pack Height (in):
- 1.3
- Unit Pack Invoiced:
- N
- Unit Pack Length (in):
- 7
- Unit Pack Shippable:
- N
- Unit Pack Weight (lbs):
- 0.86
- Unit Pack Width (in):
- 3.3
- UOM:
- Each
- UPC:
- 049659728699
- Use Placeholder Photo:
- Y
- User Manual URL-US-EN:
- https://www.starrett.com/um-733.1
- US List Price:
- $721.00
- US Next List Price:
- $721.00
- US Web Price:
- $721.00
- Variable Unit:
- N
- Web Catalog-US-EN:
- Y
- Web Price:
- $721.00
- Web Priority-US-EN:
- 14600030
- Whitepaper 1 :
- https://s3-us-west-2.amazonaws.com/catsy.833/DataSure-4-Whitepaper-Measurement-Data-QC-Integration.pdf
- Electronic or Mechanical:
- Electronic
- Spindle Rotation:
- Yes
- Starrett Model No.:
- 756.1
- Category L1:
- Micrometers
- Category L2:
- Disc Micrometers
- Sales Category:
- TOOLS.HARDWARE TOOLS (NON-DISCOUNTABLE).
- 01 Attribute :
- Micrometer Type
- 01 Spec:
- Electronic Disc-Type Micrometer with rotating spindle (with output)
- 02 Attribute:
- Electronic or Mechanical
- 02 Spec:
- Electronic
- 03 Attribute:
- Range (in)
- 03 Spec:
- 1-2"
- 04 Attribute:
- Range (mm)
- 04 Spec:
- 25-50mm
- 05 Attribute:
- Resolution (in)
- 05 Spec:
- .00005"
- 06 Attribute:
- Resolution (mm)
- 06 Spec:
- 0.001mm
- 07 Attribute:
- Accuracy (in)
- 07 Spec:
- +/- .00015" (whole surface), +/- .0002" (edges),
- 08 Attribute:
- Accuracy (mm)
- 08 Spec:
- +/-.002mm
- 09 Attribute:
- Lock Nut Type
- 09 Spec:
- Lever
- 10 Attribute:
- SPC Output
- 10 Spec:
- Yes
- 11 Attribute:
- Thimble Graduations
- 11 Spec:
- Metric
- 12 Attribute:
- Thimble Type
- 12 Spec:
- Friction
- 13 Attribute:
- Anvil/Spindle Material
- 13 Spec:
- Steel
- 14 Attribute:
- Anvil Type
- 14 Spec:
- Flat Disk
- 15 Attribute:
- Spindle Type
- 15 Spec:
- Flat Disk
- 16 Attribute:
- Product Type
- 16 Spec:
- Micrometer - Disc
- 17 Attribute:
- Spindle Rotation
- 17 Spec:
- Yes
- Discontinued:
- false
- Current Catalog:
- 33
- Current Catalog Page:
- Add
- Brochure 1:
- https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
- Western Link Inventory:
- 0
- Unit Pack Item Qty:
- 1
