769.1AXFL Electronic Tube Micrometer

769.1AXFL Electronic Tube Micrometer

$773.00
(No reviews yet) Write a Review
SKU:
769.1AXFL
UPC:
049659728170
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Conflict Minerals:
N
Contaminated if Opened:
N
Exists in Comport:
N
Assembled in US:
N
Athol Inventory:
0
Brochure URL-US-EN:
https://www.starrett.com/vdoc/Starrett Electronic Precision Hand Tools (Bulletin 590)
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Max. Range (in):
1
Max. Range (mm):
25
Min. Range (in):
0
Min. Range (mm):
0
Parent SKU As a Regular Field:
769.1
Product Group Sort:
tube
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=769.1AXFL
Rocky Mountain Inventory:
0
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Fragile:
N
French Language Included:
N
Global Product Classification:
OUTSIDE MICROMETER - ELECTRONIC 0 - 1"
Hazmat Indicator:
N
Long Description:
Each
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/769.1AXFLe72817cUSp1.tif
Manufacturer's code:
049659
Marked Recyclable:
N
Other Document 1 URL-US-EN:
https://www.starrett.com/vdoc/Starrett DataSure 4.0 (Bulletin 591)
Other Document 2 URL-US-EN:
https://www.starrett.com/vdoc/DataSure 4.0 Whitepaper
Other Document 3 URL-US-EN:
https://www.starrett.com/vdoc/DS 4.0 at Roush Yates Engines
Product made to order status:
MTO
Refrigerant Indicator:
N
RoHS (EU):
N
SDS Indicator:
N
Series Title:
769.1 Electronic Digital Tube Outside Micrometers
Shelf Pack Invoiced:
N
Shelf Pack Shippable:
N
Spindle Type:
Flat
Status:
Active
Anvil/Spindle Material:
Carbide
Subject to Environmental Change:
N
Temperature Sensitive:
N
Top 354:
N
Unit Pack Invoiced:
N
Unit Pack Shippable:
N
Unit Pack Weight (lbs):
0.85
Use Placeholder Photo:
N
User Manual URL-US-EN:
https://www.starrett.com/um-733.1
Variable Unit:
N
Web Price:
$773.00
Sales Category:
TOOLS.HARDWARE TOOLS (NON-DISCOUNTABLE).
Dimensional Drawing PDF:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-769.1AXFL-Dimensional-Drawing.pdf
Dimensional Drawing (IMG):
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-769.1AXFL-Dimensional-Drawing.tif
Discontinued:
false
Current Catalog:
33
Current Catalog Page:
add
Western Link Inventory:
0
01 Attribute:
Micrometer Type
Whitepaper 1:
https://s3-us-west-2.amazonaws.com/catsy.833/Data-Collection-in-Manufacturing.pdf
01 Spec:
Electronic Tube Micrometer (with output)
02 Attribute:
Electronic or Mechanical
02 Spec:
Electronic
03 Attribute:
Range (in)
03 Spec:
0-1"
04 Attribute:
Range (mm)
04 Spec:
0-25mm
05 Attribute:
Resolution (in)
05 Spec:
.00005"
06 Attribute:
Resolution (mm)
06 Spec:
0.001mm
07 Attribute:
Accuracy (in)
07 Spec:
+/- .0001"
08 Attribute:
Accuracy (mm)
08 Spec:
+/- .002mm
09 Attribute:
Lock Nut Type
09 Spec:
Knurled Ring Type
10 Attribute:
Output
10 Spec:
Cabled Only
11 Attribute:
Thimble Graduations
11 Spec:
English
12 Attribute:
Thimble Type
12 Spec:
Friction
13 Attribute:
Anvil/Spindle Material
13 Spec:
Carbide
14 Attribute:
Anvil Type
14 Spec:
3/16" Round
15 Attribute:
Spindle Type
15 Spec:
Flat
16 Attribute:
Product Type
16 Spec:
Micrometer - Tube
A0006160MSDSINDICATOR:
N
A000670ROHASCOMPLIANT:
N
A002040UCC12UPCA:
049659728170
A002050EANUCC13EAN13:
0049659728170
Accuracy (in):
+/- .0001"
Accuracy (mm):
+/-.002mm
Anvil Type:
3/16" Round
Available for Purchase-US-EN:
Y
Brochure 1:
https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Case Study:
https://s3-us-west-2.amazonaws.com/catsy.833/Data-Collection-at-Roush-Yates.pdf
Category:
Precision Measuring Tools > Precision Hand Tools > Micrometers > Tube
Category L1:
Micrometers
Category L2:
Tube Micrometers
EAN:
0049659728170
EDP:
72817
Electronic or Mechanical:
Electronic
Feature 01:
Starrett no-glare satin chrome finish on thimble and sleeve
Feature 02:
Large, easy-to-read .275 (7mm) high contrast LCD digital readout
Feature 03:
Extremely hard and stable one-piece spindle
Feature 04:
Auto Off after 20 minutes of nonuse
Feature 05:
Inch/millimeter conversion on English versions
Feature 06:
Smooth friction thimble for uniform pressure
Feature 07:
Measurement HOLD button
Feature 08:
Zero at any position
Feature 09:
Retain and return to true zero reading
Feature 10:
Spindle lock
Feature 11:
Data Output
Feature 12:
Resolution: .00005" (0.001mm)
Feature 13:
Accuracy +/-.0001 (+/-.002mm)
Feature 14:
PRESET button to install any reading at any position
Feature 15:
Ability to install minimum and maximum limits
Item Segmentation:
Catalog
Lock Nut Type:
Knurled Ring Type
Micrometer Type:
Electronic Tube Micrometer (with output)
Item ID:
769.1AXFL
Type:
Micrometer - Tube
PMRA Regulated:
N
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/769.1AXFLe72817cUSp1.tif
Product Photo 02:
https://s3-us-west-2.amazonaws.com/catsy.833/769.1AXFLe72817cUSa1.tif
Product Title:
769.1AXFL Electronic Tube Micrometer
Range (in):
0-1"
Range (mm):
0-25mm
Resolution (in):
.00005"
Resolution (mm):
0.001mm
SDS Sheet:
https://s3-us-west-2.amazonaws.com/catsy.833/SDS-Renata-CR2032-ASDS.pdf
Short Description:
Digital Tube Outside Micrometer, Friction Thimble, Carbide and 3/16" Round, SPC Output, .00005", 0-1" Range
Show in Web Nav?:
Yes
Starrett Model No.:
769.1
Thimble Graduations:
English
Thimble Type:
Friction
Unit Pack Height (in):
1
Unit Pack Item Qty:
1
Unit Pack Length (in):
8.3
Unit Pack Width (in):
2.3
UOM:
Each
US List Price:
$773.00
US Promo Price:
$0.00
US Web Price:
$773.00
Web Catalog-US-EN:
Y
Web Priority-US-EN:
19000015
COO Detail:
Made in the USA with US and Global Content
Schedule B Number:
9017.30.4000
Output:
Cabled Only
Available In Region:
United States|Canada
Mt Airy Inventory:
0
Product Type:
Micrometer
Country of Origin:
United States
The Starrett 769.1 Series Electronic Tube Micrometer is used for measuring the wall thickness of tubing and other materials that have cylindrical walls. This tool is also used for measuring from hole-to-edge. Built with customary Starrett quality and workmanship, the 769 series includes a large, easy-to-read, high-contrast LCD digital readout for clear readings. Its no-glare satin chrome finish minimizes annoying surface glare under bright lights indoors or filters out UV light. This model features 0.00005"in and 0.001mm resolution and 0-1"in and 0-25mm measuring range. Starrett electronic micrometers guarantee a precise measurement at every position each and every time. 0-1" (0-25mm) Range with Output, Carbide Spindle.
