770BXTZ-2 Electronic Internal Micrometer, 3-Point Contact

770BXTZ-2 Electronic Internal Micrometer, 3-Point Contact

$1,892.00
(No reviews yet) Write a Review
SKU:
770BXTZ-2
UPC:
049659725636
Category:
Precision Measuring Tools > Precision Hand Tools > Bore Gages > Electronic Bore Micrometers
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
EAN:
0049659725636
EDP:
72563
Accessory:
RING138
Feature 01:
Wide measurement range without changing anvils
Feature 02:
Carbide measuring faces on sizes above 5/16" (7.9mm) diameter
Feature 03:
Extensions available for deep holes
Feature 04:
Precision ratchet stop provides correct contact pressure for accurate readings
Feature 05:
Each micrometer bore gage with head comes with a wooden case, complete with setting ring, contacts, adjusting wrench, spare battery, and instructions
Feature 06:
IP67 level of protection against coolant, water, dirt and dust
Feature 07:
Large high-contrast LCD digital readout is easy to read and reduces error
Feature 08:
RS232 output
Feature 09:
Includes instant inch/millimeter conversion and preset + and - functions
Feature 10:
Proximity output with optional built-in Wireless
Feature 11:
Bi-directional communication
Approximate Measuring Depth (in):
3-1/16"
Approximate Measuring Depth (mm):
80mm
Assembled in US:
N
Athol Inventory:
5
Available for Purchase-US-EN:
Y
Flat Stock Inventory:
0
Item Class:
Stand-Alone
Max. Range (in):
2
Max. Range (mm):
50
Min. Range (in):
1.375
Min. Range (mm):
35
Parent SKU As a Regular Field:
770BXT
Product Group Sort:
icc110602
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=770BXTZ-2
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
5
US Web Temp Hold:
Off
Global Product Classification:
MICROMETER, XT3 DIGITAL 1 3/8-2 WITH BT
Item Segmentation:
Catalog
Long Description:
Each
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/770BXTZ-2cUSp1.tif
Manufacturer's code:
049659
NAFTA Producer:
No
Item ID:
770BXTZ-2
Number of Heads:
1
Number of Rings:
1
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/770BXTZ-2cUSp1.tif
Product Photo 02:
https://s3-us-west-2.amazonaws.com/catsy.833/770BXTZ-2cUSp2.tif
Product Title:
770BXTZ-2 Electronic Internal Micrometer, 3-Point Contact
Range (in):
1-3/8" to 2"
Range (mm):
35-50mm
Resolution (in):
.00005"
Resolution (mm):
0.001mm
Series Title:
770BXT Electronic Digital Internal Micrometers
Short Description:
Electronic Digital Internal Micrometer with Wireless, SPC Output, 1-3/8 -2" Range, .00005" Res.
Status:
Active
A002040UCC12UPCA:
049659725636
A002050EANUCC13EAN13:
0049659725636
Accessories Included:
1.375" Setting Ring
Accuracy (in):
.00015"
Accuracy (mm):
.004mm
Tariff Code for entry into Mexico:
No
Top 354:
N
Unit Pack Height (in):
2.4
Unit Pack Height (mm):
58.42
Unit Pack Invoiced:
N
Unit Pack Item Qty:
1
Unit Pack Length (in):
11.2
Unit Pack Length (mm):
220.98
Unit Pack Shippable:
N
Unit Pack Weight (kg):
1.7236496
Unit Pack Weight (lbs):
3.95
Unit Pack Width (in):
7
Unit Pack Width (mm):
170.18
UOM:
Each
Use Placeholder Photo:
N
User Manual URL-US-EN:
https://www.starrett.com/UM-770B
US List Price:
$1892.00
US Web Price:
$1892.00
Web Catalog-US-EN:
Y
Web Price:
$1892.00
Web Priority-US-EN:
30800065
Electronic or Mechanical:
Electronic
01 Spec:
1-3/8" to 2"
02 Attribute:
Range (mm)
02 Spec:
35-50mm
03 Attribute:
Resolution (in)
03 Spec:
.00005"
04 Attribute:
Resolution (mm)
04 Spec:
0.001mm
05 Attribute:
Output
05 Spec:
Cabled and Wireless
06 Attribute:
Approximate Measuring Depth (in)
06 Spec:
3-1/16"
08 Attribute:
Accuracy (mm)
08 Spec:
.004mm
09 Attribute:
Power supply
09 Spec:
USB/AC (power cable included)|Battery
10 Attribute:
Battery Type
10 Spec:
CR2032 lithium Battery (Qty 1), Included
Discontinued:
false
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Current Catalog Page:
207
Catalog Section Page:
5
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-06-Bore-Gages.pdf
Brochure 1:
https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
Western Link Inventory:
0
Category L1:
Bore Gages
Category L2:
Electronic Bore Micrometers
Current Catalog:
33
US Promo Price:
$0.00
07 Attribute:
Accuracy (in)
07 Spec:
.00015"
01 Attribute:
Range (in)
Battery Type:
CR2032 lithium Battery (Qty 2), Included
Starrett Model No.:
770
Schedule B Number:
9017.30.4000
Product made to order status:
MTO
Output:
Cabled and Wireless
11 Attribute:
Accessories Included
11 Spec:
1.375" Setting Ring
Available In Region:
United States|Canada
Mt Airy Inventory:
0
Orderable Online Today (US Only):
Yes
Product Type:
Bore Gage
Country of Origin:
United Kingdom
Adding to cart… The item has been added
The Starrett 770BXT Series Electronic Internal Micrometer, with built-in Blue tooth technology, provides IP67 level of protection against coolant, water, dirt and dust in hostile shop environments. In addition, it offers extended travel, reducing the need to exchange anvils. The ground contact points seat the internal micrometer faster and more accurately than the spherical contacts found on other gages. The rugged and accurate internal micrometer is available individually or in sets from .080" (2mm) to 12" (300mm). 1 3/8-2" (35-50mm) Range, 3-Point Carbide Contact (300mm).
