786.1P-1 Electronic Blade-Type Micrometer

786.1P-1 Electronic Blade-Type Micrometer

$1,056.00
(No reviews yet) Write a Review
SKU:
786.1P-1
UPC:
049659728323
Category:
Precision Measuring Tools > Precision Hand Tools > Micrometers > Blade Micrometers
Cal Prop 65 Chemical:
Lead
Conflict Minerals:
N
Contaminated if Opened:
N
Exists in Comport:
N
Accessory:
3206
Assembled in US:
N
Athol Inventory:
1
Available for Purchase-US-EN:
Y
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Parent SKU As a Regular Field:
786.1
Product Group Sort:
blade_micrometers
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=786.1P-1
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
1
US Web Temp Hold:
Off
Fragile:
N
French Language Included:
N
Global Product Classification:
MICROMETER, ELECTRONIC
Hazmat Indicator:
N
Item Segmentation:
Catalog
Long Description:
Each
Made in America:
Yes
Manufacturer's code:
049659
Marked Recyclable:
N
Next Catalog:
34
Item ID:
786.1P-1
Type:
Micrometer - Blade
PMRA Regulated:
N
Product made to order status:
MTO
Refrigerant Indicator:
N
Resolution (in):
.00005"
Resolution (mm):
0.001mm
Shelf Pack Invoiced:
N
Shelf Pack Shippable:
N
A0006160MSDSINDICATOR:
N
A000670ROHASCOMPLIANT:
N
A002040UCC12UPCA:
049659728323
A002050EANUCC13EAN13:
0049659728323
Subject to Environmental Change:
N
Temperature Sensitive:
N
Top 354:
N
Unit Pack Invoiced:
N
Unit Pack Shippable:
N
UOM:
Each
Use Placeholder Photo:
N
US Web Price:
$1056.00
Variable Unit:
N
Web Catalog-US-EN:
Y
Web Price:
$1056.00
Starrett Model No.:
786.1
Sales Category:
TOOLS.HARDWARE TOOLS (NON-DISCOUNTABLE).
Discontinued:
false
Current Catalog:
33
Current Catalog Page:
Add
Western Link Inventory:
0
Category L1:
Micrometers
Category L2:
Blade Micrometers
US Promo Price:
$0.00
01 Attribute:
Micrometer Type
Whitepaper 1:
https://s3-us-west-2.amazonaws.com/catsy.833/Data-Collection-in-Manufacturing.pdf
COO Detail:
Made in the USA with US and Global Content
Schedule B Number:
9017.30.4000
Output:
Cabled Only
Available In Region:
United States|Canada
Mt Airy Inventory:
0
ORS Part Numbers:
681-72832
Country of Origin:
United States
Dimensional Drawing PDF:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-786.1P-1-Dimensional-Drawing.pdf
Dimensional Drawing (IMG):
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-786.1P-1-Dimensional-Drawing.tif
01 Spec:
Electronic Blade-Type Micrometers
02 Attribute:
Electronic or Mechanical
02 Spec:
Electronic
03 Attribute:
Range (in)
03 Spec:
0-1"
04 Attribute:
Range (mm)
04 Spec:
0-25.4mm
05 Attribute:
Resolution (in)
05 Spec:
.00005"
06 Attribute:
Resolution (mm)
06 Spec:
0.001mm
07 Attribute:
Accuracy (in)
07 Spec:
+/- .0001"
08 Attribute:
Accuracy (mm)
08 Spec:
+/- .002mm
09 Attribute:
Graduations (in)
09 Spec:
.001"
10 Attribute:
Lock Nut Type
10 Spec:
Lever
11 Attribute:
Output
11 Spec:
Cabled Only
12 Attribute:
Thimble Graduations
12 Spec:
English
13 Attribute:
Thimble Type
13 Spec:
Speeder
14 Attribute:
Anvil/Spindle Material
14 Spec:
Steel
15 Attribute:
Anvil Type
15 Spec:
0.030" Blade
16 Attribute:
Spindle Type
16 Spec:
0.030" Blade
17 Attribute:
Product Type
17 Spec:
Micrometer - Blade
18 Attribute:
Spindle Rotation
18 Spec:
No
Accuracy (in):
+/- .0001"
Accuracy (mm):
+/-.002mm
Anvil Type:
0.030" Blade
Brochure 1:
https://s3.us-west-2.amazonaws.com/catsy.833/starrett-datasure-4-0-bulletin-591.pdf
Brochure 3:
https://s3.us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Case Study:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Datasure-4-Whitepaper-RYE.pdf
EAN:
0049659728323
EDP:
72832
Electronic or Mechanical:
Electronic
Feature 01:
Starrett no-glare satin chrome finish on thimble and sleeve
Feature 02:
Large, easy-to-read .275 (7mm) high contrast LCD digital readout
Feature 03:
Attractive no glare black wrinkle finish on the frame
Feature 04:
Auto Off after 20 minutes of nonuse
Feature 05:
Inch/millimeter conversion on English versions
Feature 06:
Speeder for quick adjustments and uniform pressure
Feature 07:
Measurement HOLD button
Feature 08:
Zero at any position
Feature 09:
Retain and return to true zero reading
Feature 10:
.030 Blade Thickness
Feature 11:
Data Output
Feature 12:
Resolution: .00005" (0.001mm)
Feature 13:
Accuracy +/-.0001 (+/-.002mm)
Feature 14:
PRESET button to install any reading at any position
Feature 15:
Ability to install minimum and maximum limits
Graduations (in):
.001"
Lock Nut Type:
Lever
Micrometer Type:
Electronic Blade-Type Micrometers
Orderable Online Today (US Only):
Yes
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/786.1P-1e72832cUSp1.tif
Product Photo 02:
https://s3.us-west-2.amazonaws.com/catsy.833/786.1P-1e72832cUSa1.tif
Product Title:
786.1P-1 Electronic Blade-Type Micrometer
Product Type:
Micrometer
Range (in):
0-1"
Range (mm):
0-25.4mm
SDS Sheet:
https://s3.us-west-2.amazonaws.com/catsy.833/SDS-Renata-CR2032-ASDS.pdf
Short Description:
Digital Blade Type Micrometer, Speeder Thimble, 0.030" Blade Anvil, SPC Output, .00005", 0-1" Range
Spindle Rotation:
No
Thimble Graduations:
English
Thimble Type:
Speeder
Unit Pack Height (in):
1.3
Unit Pack Length (in):
9.8
Unit Pack Width (in):
3.3
US List Price:
$1056.00
Web Priority-US-EN:
15000065
Unit Pack Weight (lbs):
1.1
User Manual URL-US-EN:
https://www.starrett.com/um-733.1
RoHS (EU):
N
SDS Indicator:
N
Series Title:
786.1 Electronic Digital Blade Type Micrometers
Status:
Active
Brochure URL-US-EN:
https://www.starrett.com/vdoc/Starrett Electronic Precision Hand Tools (Bulletin 590)
Cal Prop 65 Warning:
Y
Max. Range (in):
1
Max. Range (mm):
25.4
Min. Range (in):
0
Min. Range (mm):
0
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/786.1P-1e72832cUSp1.tif
Spindle Type:
0.030" Blade
Anvil/Spindle Material:
Steel
Minimum Bore Diameter (in):
Jaw Thickness (in)
Adding to cart… The item has been added
The Starrett 786.1 Electronic Blade-Type Micrometer with Non-Rotating Spindle With Output is a full-featured precision measuring tool built with customary Starrett quality and workmanship. The 786 series includes a large, easy-to-read, high-contrast LCD digital readout for clear readings and a speeder for quicker adjustment on all sizes. The non-rotating spindle prevents blade from turning in narrow slots or rolling off shoulder. Its no-glare satin chrome finish minimizes annoying surface glare under bright lights indoors or filters out UV light. This product features output capability for data transmission. Starrett electronic micrometers guarantee a precise measurement at every position each and every time. 0-1" Range, .00005" Resolution.
