786P-4 Electronic Blade-Type Micrometer

786P-4 Electronic Blade-Type Micrometer

$1,896.00
(No reviews yet) Write a Review
SKU:
786P-4
UPC:
049659652284
Discontinued:
false
A002040UCC12UPCA:
049659652284
A002050EANUCC13EAN13:
0049659652284
Available for Purchase-US-EN:
N
Category:
Discontinued
Item Segmentation:
Catalog
NAFTA Producer:
Yes
Item ID:
786P-4
Show in Web Nav?:
Yes
Superseded By:
786.1P-4
UOM:
Each
US Promo Price:
$0.00
US Web Price:
$1896.00
Web Catalog-US-EN:
Y
COO Detail:
Made in the USA with US and Global Content
Global Product Classification:
ELECTRONIC BLADE MICROMETER, 3-4"
Manufacturer's code:
049659
Athol Inventory:
0
Available In Region:
United States|Canada
Cal Prop 65 Chemical:
Lead
Flat Stock Inventory:
0
Item Class:
Stand-Alone
Mt Airy Inventory:
0
Product Group Sort:
discontinued
Rocky Mountain Inventory:
0
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Webber Inventory:
0
Western Link Inventory:
0
Long Description:
786P-4 DISCONTINUED PER ECO# 18218 7-7-20 REPLACED BY 786.1P-4
Made in America:
Yes
POA Flag:
N
Schedule B Number:
9017.30.4000
Shelf Pack Item Qty:
1
Shelf Pack Pricing Quantity:
1
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (mm):
35.56
Unit Pack Length (mm):
312.42
Unit Pack Weight (kg):
0.8618248
Unit Pack Width (mm):
157.48
Use Placeholder Photo:
N
Web Price:
$1896.00
Country of Origin:
United States
Accuracy (in):
+/-.0001"
Accuracy (mm):
+/-.002mm
Anvil Type:
0.030" Blade
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
EAN:
0049659652284
EDP:
65228
Feature 01:
Balanced frame and thimble design ensure easy handling and better readability
Feature 02:
Output capability for data transmission
Feature 03:
Advanced sleeve design with staggered lines and distinct figures for precise and easy readability
Feature 04:
Conventional inch or millimeter graduations standard
Feature 05:
Quick and easy adjustment
Feature 06:
Large, easy-to-read, high-contrast LCD digital readout
Feature 07:
Starrett No-glare satin chrome finish on thimble and sleeve minimizes annoying surface glare under bright lights indoors or filters out UV light
Feature 08:
No-glare black wrinkle finish on frame
Feature 09:
Hard and stable one-piece friction thimble permits one-hand operation of micrometer and uniform contact pressure
Feature 10:
Rigid steel frame ribbed for strength and stability
Feature 11:
Ability to zero tool at any position as well as retain and return to the true zero reading of the micrometer
Feature 12:
One 3-volt battery included for extended usage
Feature 13:
Automatic OFF
Feature 14:
Measurement HOLD button
Feature 15:
RS232 data output port
Feature 16:
Inch/millimeter metric conversion provides simple, universal, standardized unit of measurement at any position
Feature 17:
PRESET button to install any reading at any position
Feature 18:
Ability to install minimum and maximum limits
Feature 19:
Speeder for quicker adjustment on all sizes
Feature 20:
Speeder for quicker adjustment on all sizes
Graduations (in):
.001"
Micrometer Type:
Electronic Blade-Type Micrometers
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/786P-4e65228cUSp1.tif
Product Title:
786P-4 Electronic Blade-Type Micrometer
Range (in):
3-4"
Range (mm):
76-101mm
Short Description:
Digital Blade Type Micrometer, Speeder Thimble, 0.030" Blade Anvil, SPC Output, .00005", 3-4" Range
SLC Certification:
Optional Add-On
Thimble Graduations:
English
Thimble Type:
Speeder
Unit Pack Height (in):
1.8
Unit Pack Item Qty:
1
Unit Pack Length (in):
12.4
Unit Pack Width (in):
6.3
US List Price:
$1896.00
Web Priority-US-EN:
99999999
Unit Pack Weight (lbs):
1.75
Series Title:
786, 786M Electronic Digital Blade Type Micrometers with Non-Rotating Spindle (with Output)
Status:
GOING DISC
Cal Prop 65 Warning:
Y
Max. Range (in):
4
Max. Range (mm):
101
Min. Range (in):
3
Min. Range (mm):
76
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/786P-4e65228cUSp1.tif
Spindle Type:
0.030" Blade
Anvil/Spindle Material:
Steel
The Starrett 786 Electronic Blade-Type Micrometer with Non-Rotating Spindle With Output is a full-featured precision measuring tool built with customary Starrett quality and workmanship. The 786 series includes a large, easy-to-read, high-contrast LCD digital readout for clear readings and a speeder for quicker adjustment on all sizes. The non-rotating spindle prevents blade from turning in narrow slots or rolling off shoulder. Its no-glare satin chrome finish minimizes annoying surface glare under bright lights indoors or filters out UV light. This product features output capability for data transmission. Starrett electronic micrometers guarantee a precise measurement at every position each and every time. 3-4" Range, .00005" Resolution time.
