82BZ Dial Bore Gages

82BZ Dial Bore Gages

$1,874.00
(No reviews yet) Write a Review
SKU:
82BZ
UPC:
049659557923
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog URL:
https://www.starrett.com/dms/flipbooks/Cat-33/index.html?page=214
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Category:
Precision Measuring Tools > Precision Hand Tools > Bore Gages > Dial Bore Gages
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Country of Origin :
United States
Current Catalog Page:
214
EAN:
0049659557923
EDP:
55792
Accessory:
3089-RS36B
Feature 01:
These gages are also available with electronic indicators by special order
Feature 02:
Useful for controlling approach to tolerance without removing the workpiece from a machine
Feature 03:
Sets furnished in attractive, protective case
Feature 04:
Each set consists of a dial indicator, a body and actuating rod, two adjusting wrenches and the probes
Feature 05:
The split-ball contact is self-centering, the two-point contact detects hole geometry problems like taper, bell-mouth and out-of- roundness
Feature 06:
Interchangeable probes are hard chrome plated and polished
Feature 07:
All probes come complete with actuating rod
Feature 08:
Reads to .0001"
Approximate Measuring Depth (in):
1-1/2" and 1-3/4"
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada
Description:
Starrett 82 Dial bore gages are available in convenient sets or with individual probes and dial
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Max. Range (in):
0.594
Min. Range (in):
0.217
Mt Airy Inventory :
0
ORS Part Numbers :
681-55792
Parent SKU As a Regular Field:
82
Product Group Sort:
icc110604
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=82BZ
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Top Seller:
Yes
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
BORE GAGE, DIAL, .217"-.594", .0001" GRADS
Graduations (in):
.0001"
Item Segmentation:
Catalog
Long Description:
Each
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/82BZcUSp1.tif
Manufacturer's code:
049659
NAFTA Producer:
Yes
Name:
BORE GAGE, DIAL, .217"-.594", .0001" GRADS
Item ID:
82BZ
POA Flag:
N
Product made to order status:
MTO
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/82BZcUSp1.tif
Product Photo 02:
https://s3-us-west-2.amazonaws.com/catsy.833/82BZcUSp2.tif
Product Title:
82BZ Dial Bore Gages
Range (in):
.217 - .594"
SDS Indicator:
N
Series Title:
82, 82M Dial Bore Gages
Shelf Pack Item Qty:
1
Shelf Pack Pricing Quantity:
1
Short Description:
Dial Bore Gage with Split Ball Contacts, .217-.594" Range, .0001" Graduations, Vinyl - Steel Case
Status:
Active
A0006160MSDSINDICATOR:
N
A002040UCC12UPCA:
049659557923
A002050EANUCC13EAN13:
0049659557923
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (in):
2.4
Unit Pack Height (mm):
60.96
Unit Pack Item Qty:
1
Unit Pack Length (in):
8.1
Unit Pack Length (mm):
203.2
Unit Pack Weight (kg):
0.8164656
Unit Pack Weight (lbs):
1.7
Unit Pack Width (in):
5.3
Unit Pack Width (mm):
134.62
UOM:
Each
UPC:
049659557923
Use Placeholder Photo:
N
US List Price:
$1874.00
US Next List Price:
$1874.00
US Web Price:
$1874.00
Web Catalog-US-EN:
Y
Web Price:
$1874.00
Web Priority-US-EN:
31600030
Electronic or Mechanical:
Mechanical
Category L1:
Bore Gages
Category L2:
Dial Bore Gages
Sales Category:
TOOLS.HARDWARE TOOLS (DISCOUNTABLE).
01 Attribute :
Range (in)
01 Spec:
.217 - .594"
02 Attribute:
Approximate Measuring Depth (in)
02 Spec:
1-1/2" and 1-3/4"
Maximum Bore Depth (in):
1-3/4
Discontinued:
false
Catalog Section Page:
12
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-06-Bore-Gages.pdf
Western Link Inventory:
0
Starrett 82 Dial bore gages are available in convenient sets or with individual probes and dial indicators. Each set consists of a dial indicator, a body and actuating rod, two adjusting wrenches and the probes as specified below. The head may be ordered separately (includes dial indicator, body, and two adjusting wrenches). Individual probes can also be ordered as listed. All probes are furnished with an actuating rod. These gages are also available with electronic indicators by special order. Measurements are taken by comparison so some type of set master should be used as a reference standard. We recommend setting as close to the hole being measured as possible, and this can be easily done with gage blocks or with a micrometer Complete Set, .217"-.594" Range .0001" Grad with Case with a micrometer.
