84AZ-111-6J Dial Bore Gage (5 - 8" Range)

84AZ-111-6J Dial Bore Gage (5 - 8" Range)

$1,646.00
(No reviews yet) Write a Review
SKU:
84AZ-111-6J
UPC:
049659000283
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog URL:
https://www.starrett.com/dms/flipbooks/Cat-33/index.html?page=215
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Category:
Precision Measuring Tools > Precision Hand Tools > Bore Gages > Dial Bore Gages
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Country of Origin :
United States
Current Catalog Page:
215
EAN:
0049659000283
EDP:
00028
Feature 01:
Can be easily held to inspect bores and hole sizes without removing the workpiece
Feature 02:
An adjustable range screw and two centralizing plungers provide accurate, three-point contact for tool alignment in larger bores
Feature 03:
All contacts and centralized plungers are of hardened tool steel for wear and spring-loaded for sensitivity
Feature 04:
The housing and knurled handle are aluminum for light weight and good balance
Feature 05:
Dial indicators have jewel bearings for sensitivity
Feature 06:
Furnished in finished wood case
Feature 07:
Bore depths are also available up to 12" (300mm) in 1" (25mm) increments on special order
Feature 08:
Also available with carbide contacts or electronic indicators with output capability on special order
Approximate Measuring Depth (in):
6"
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada
Description:
Starrett 84 Dial Bore Gage allows for bore measurements beyond size range of our 82 Series.
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Max. Range (in):
8
Min. Range (in):
5
Mt Airy Inventory :
0
Parent SKU As a Regular Field:
84
Product Group Sort:
icc110604
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=84AZ-111-6J
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Top Seller:
Yes
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
BORE GAGE, DIAL 5"- 8" RANGE, .0001"
Graduations (in):
.0001"
Item Segmentation:
Catalog
Long Description:
Each
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/84AZ-111-6JcUSp1.tif
Manufacturer's code:
049659
NAFTA Producer:
Yes
Name:
BORE GAGE, DIAL 5"- 8" RANGE, .0001"
Item ID:
84AZ-111-6J
Product made to order status:
MTO
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/84AZ-111-6JcUSp1.tif
Product Photo 02:
https://s3-us-west-2.amazonaws.com/catsy.833/84AZ-111-6JcUSp2.tif
Product Photo 03:
https://s3-us-west-2.amazonaws.com/catsy.833/84AZ-111-6JcUSp3.tif
Product Title:
84AZ-111-6J Dial Bore Gage (5 - 8" Range)
Range (in):
5 to 8"
Series Title:
84, 84M Dial Bore Gages with Cases
Short Description:
Dial Bore Gage, 5 - 8-1/8" Range, .0001" Graduations, Wooden Case
Status:
Active
A002040UCC12UPCA:
049659000283
A002050EANUCC13EAN13:
0049659000283
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (in):
6.1
Unit Pack Height (mm):
160.02
Unit Pack Item Qty:
1
Unit Pack Length (in):
15.6
Unit Pack Length (mm):
393.7
Unit Pack Weight (kg):
3.175144
Unit Pack Weight (lbs):
6.8
Unit Pack Width (in):
5.5
Unit Pack Width (mm):
137.16
UOM:
Each
UPC:
049659000283
Use Placeholder Photo:
N
US List Price:
$1646.00
US Next List Price:
$1646.00
US Web Price:
$1646.00
Web Catalog-US-EN:
Y
Web Price:
$1646.00
Web Priority-US-EN:
31600015
Electronic or Mechanical:
Mechanical
Category L1:
Bore Gages
Category L2:
Dial Bore Gages
Sales Category:
TOOLS.TOOLS (DISCOUNTABLE).
01 Attribute :
Range (in)
01 Spec:
5 to 8"
02 Attribute:
Approximate Measuring Depth (in)
02 Spec:
6"
Dimensional Drawing PDF:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-84AZ-111-6J-Dimensional-Drawing.pdf
Dimensional Drawing (IMG):
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-84AZ-111-6J-Dimensional-Drawing.tif
Maximum Bore Depth (in):
6
Discontinued:
false
Catalog Section Page:
13
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-06-Bore-Gages.pdf
Western Link Inventory:
0
Starrett 84 Dial Bore Gage allows for bore measurements beyond size range of our 82 Series. It is a comparison gage and should be set with a master ring gage, gage blocks with parallel jaws, outside micrometer or vernier caliper. Ring gage is available by request, quoted by application. Good practice is to set the gage to zero, as near to the desired dimension as possible. 5"- 8" Range .0001" Grad
