AG 16. R croblox® Angle Gage Block Set

AG 16. R croblox® Angle Gage Block Set

$24,261.00
(No reviews yet) Write a Review
SKU:
AG 16. R
Category:
Gage Blocks and Calibration Solutions > Angle Gage Blocks and Sets
Cal Prop 65 Warning:
N
Description / Accuracy Grade:
Reference Grade ±1.0 Second
EDP:
93921
Member of Set:
AG 5. SR|AG 5. MR|AG 5. DR|AG 45. DR|AG 30. SR|AG 30. MR|AG 30. DR|AG 3. SR|AG 3. MR|AG 3. DR|AG 20. SR|AG 20. MR|AG 15. DR|AG 1. SR|AG 1. MR|AG 1. DR
Feature 01:
Furnished in a wooden case for protecction
Available for Purchase-US-EN:
Y
Blocks Included In Sets:
6 Blocks: 1°, 3°, 5°, 15°, 30°, 45° 5 Blocks: 1', 3', 5', 20', 30' 5 Blocks: 1", 3", 5", 20", 30"
Blocks Per Set:
16
Item Class:
Stand-Alone
Product Group Sort:
angle_blocks_and_sets
Website-URL:
https://www.starrett.com/details?cat-no=AG 16. R
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Item Segmentation:
Catalog
Long Description:
93921 CRO ANGLE BLK SET
Made in America:
Yes
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/AG16.RecUSp1.tif
Measuring Range:
0-99° in 1" Steps
Item ID:
AG 16. R
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/AG16.RecUSp1.tif
Product Title:
AG 16. R croblox® Angle Gage Block Set
Series Title:
Angle Gage Block Sets
Shape:
Angle
Short Description:
16 Piece croblox® Chromium Carbide Angle Block Set, Grade R
Status:
Active
Accuracy Grade:
Reference
Top 354:
N
Unit Of Measure:
Each
Unit Pack Invoiced:
N
Unit Pack Shippable:
N
Unit Pack Weight (lbs):
1
UOM:
Each
Use Placeholder Photo:
N
US List Price:
$24261.00
Web Catalog-US-EN:
Y
Web Priority-US-EN:
49605062
01 Spec:
Angle Block Set
02 Attribute:
Material Type
02 Spec:
croblox® Chromium Carbide
03 Attribute:
Accuracy Grade
03 Spec:
Reference
04 Attribute:
Accuracy Level
04 Spec:
±1.0 Second
Discontinued:
false
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Current Catalog:
33
Current Catalog Page:
399
Catalog Section Page:
25
Catalog:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog Section:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-19-Starrett-Webber-Gage-Blocks.pdf
Category L1:
Gage Blocks
Category L2:
Angle
01 Attribute:
Block Type
Unit Pack Item Qty:
1
Product Type:
Angle Block Set
Product made to order status:
MTO
Available In Region:
United States|Canada
Country of Origin:
United States
Minimum Order Quantity:
0
05 Attribute:
Blocks Per Set
05 Spec:
16
06 Attribute:
Measuring Range
06 Spec:
0-99° in 1" Steps
07 Attribute:
Blocks Included In Sets
07 Spec:
6 Blocks: 1°, 3°, 5°, 15°, 30°, 45° 5 Blocks: 1', 3', 5', 20', 30' 5 Blocks: 1", 3", 5", 20", 30"
08 Attribute:
Tolerances: Deviation From Nominal
08 Spec:
±1.0 second
09 Attribute:
Flatness of Gaging Surfaces
09 Spec:
6μin. (0.15μm)
10 Attribute:
Flatness & Parallelism of Sides
10 Spec:
8μin. (0.20μm)
11 Attribute:
Squareness of Sides to Gaging Surfaces
11 Spec:
6 seconds
12 Attribute:
Area of Gaging Surfaces
12 Spec:
1 x 2" (25 x 50mm)
13 Attribute:
Surface Finish (Gage Surfaces Only)
13 Spec:
0.4μin. AA (.01μm AA)
14 Attribute:
Estimated Uncertainty of Measurement (k=2)
14 Spec:
0.6 seconds
Estimated Uncertainty of Measurement (k=2):
0.6 seconds
Flatness of Gaging Surfaces:
6μin. (0.15μm)
material:
croblox® Chromium Carbide
Material Type:
croblox® Chromium Carbide
Type:
Angle Block Set
Tolerances: Deviation From Nominal:
±1.0 second
Area of Gaging Surfaces:
1 x 2" (25 x 50mm)
Flatness & Parallelism of Sides:
8μin. (0.20μm)
Material of Construction:
croblox® Chromium Carbide
Squareness of Sides to Gaging Surfaces:
6 seconds
Surface Finish (Gage Surfaces Only):
0.4μin. AA (.01μm AA)
Application Grade:
Reference
Block Type:
Angle Block Set
Blades per Pack (pcs):
1
Measuring Range: 0-99º in 1" Steps Blocks Included In Set: 6 Blocks: 1°, 3°, 5°, 15°, 30°, 45° 5 Blocks: 1', 3', 5', 20', 30' 5 Blocks: 1", 3", 5", 20", 30"
