AG 6. R croblox® Angle Gage Block Set

(No reviews yet) Write a Review

Write a Review

Close ×

AG 6. R croblox® Angle Gage Block Set

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name Required

Email Required

Review Subject Required

Comments Required

SKU:

AG 6. R

UPC:

Category:

Gage Blocks and Calibration Solutions > Angle Gage Blocks and Sets

Cal Prop 65 Warning:

N

Description / Accuracy Grade:

Reference Grade ±1.0 Second

EDP:

93923

Member of Set:

AG 5. DR|AG 45. DR|AG 30. DR|AG 3. DR|AG 15. DR|AG 1. DR

Feature 01:

Furnished in a wooden case for protecction

Available for Purchase-US-EN:

Y

Blocks Included In Sets:

6 Blocks: 1°, 3°, 5°, 15°, 30°, 45°

Blocks Per Set:

6

Item Class:

Stand-Alone

Product Group Sort:

angle_blocks_and_sets

Website-URL:

https://www.starrett.com/details?cat-no=AG 6. R

Show in Web Nav?:

Yes

To Delete:

false

To Remove:

false

Total Inventory:

0

US Web Temp Hold:

Off

Item Segmentation:

Catalog

Long Description:

93923 CRO ANGLE BLK SET

Made in America:

Yes

Main Image:

https://s3.us-west-2.amazonaws.com/catsy.833/AG6.RcUSp1.tif

Measuring Range:

0-99° in 1° Steps

Item ID:

AG 6. R

Product Photo 01:

https://s3.us-west-2.amazonaws.com/catsy.833/AG6.RcUSp1.tif

Product Title:

AG 6. R croblox® Angle Gage Block Set

Series Title:

Angle Gage Block Sets

Shape:

Angle

Short Description:

6 Piece croblox® Chromium Carbide Angle Block Set, Grade R

Status:

Active

Accuracy Grade:

Reference

Top 354:

N

Unit Of Measure:

Each

Unit Pack Invoiced:

N

Unit Pack Shippable:

N

Unit Pack Weight (lbs):

1

UOM:

Each

Use Placeholder Photo:

N

US List Price:

$9990.00

Web Catalog-US-EN:

Y

Web Priority-US-EN:

49605074

01 Spec:

Angle Block Set

02 Attribute:

Material Type

02 Spec:

croblox® Chromium Carbide

03 Attribute:

Accuracy Grade

03 Spec:

Reference

04 Attribute:

Accuracy Level

04 Spec:

±1.0 Second

Discontinued:

false

Catalog URL-US-EN:

https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf

Current Catalog:

33

Current Catalog Page:

399

Catalog Section Page:

25

Catalog:

https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf

Catalog Section:

https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-19-Starrett-Webber-Gage-Blocks.pdf

Category L1:

Gage Blocks

Category L2:

Angle

01 Attribute:

Block Type

Unit Pack Item Qty:

1

Product Type:

Angle Block Set

Product made to order status:

MTO

Available In Region:

United States|Canada

Country of Origin:

United States

Minimum Order Quantity:

0

05 Attribute:

Blocks Per Set

05 Spec:

6

06 Attribute:

Measuring Range

06 Spec:

0-99° in 1° Steps

07 Attribute:

Blocks Included In Sets

07 Spec:

6 Blocks: 1°, 3°, 5°, 15°, 30°, 45°

08 Attribute:

Tolerances: Deviation From Nominal

08 Spec:

±1.0 second

09 Attribute:

Flatness of Gaging Surfaces

09 Spec:

6μin. (0.15μm)

10 Attribute:

Flatness & Parallelism of Sides

10 Spec:

8μin. (0.20μm)

11 Attribute:

Squareness of Sides to Gaging Surfaces

11 Spec:

6 seconds

12 Attribute:

Area of Gaging Surfaces

12 Spec:

1 x 2" (25 x 50mm)

13 Attribute:

Surface Finish (Gage Surfaces Only)

13 Spec:

0.4μin. AA (.01μm AA)

14 Attribute:

Estimated Uncertainty of Measurement (k=2)

14 Spec:

0.6 seconds

Estimated Uncertainty of Measurement (k=2):

0.6 seconds

Flatness of Gaging Surfaces:

6μin. (0.15μm)

material:

croblox® Chromium Carbide

Material Type:

croblox® Chromium Carbide

Type:

Angle Block Set

Tolerances: Deviation From Nominal:

±1.0 second

Area of Gaging Surfaces:

1 x 2" (25 x 50mm)

Flatness & Parallelism of Sides:

8μin. (0.20μm)

Material of Construction:

croblox® Chromium Carbide

Squareness of Sides to Gaging Surfaces:

6 seconds

Surface Finish (Gage Surfaces Only):

0.4μin. AA (.01μm AA)

Application Grade:

Reference

Block Type:

Angle Block Set

Blades per Pack (pcs):

1
