C251A Steel Beam Trammel

C251A Steel Beam Trammel

$256.00
(No reviews yet) Write a Review
SKU:
C251A
UPC:
049659512052
Category:
Precision Measuring Tools > Precision Hand Tools > Calipers, Dividers and Trammels > Trammels
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Country of Origin :
United States
EAN:
0049659512052
EDP:
51205
Feature 01:
Rigid, well-designed
Feature 02:
The top of the beam is flattened so that when the trams are clamped in position, they will not turn from pressure on the points
Feature 03:
The 3" (75mm) points may be adjusted for length in the spring chucks and can be easily replaced with caliper legs or other attachments listed
Feature 04:
The ball points with 3" (75mm) holder permit working from holes up to 1-1/2" (38mm) in diameter
Feature 05:
A pair of 3" (75mm) caliper points is included with each trammel
Feature 06:
One tram has a fine-adjusting screw for the points
Feature 07:
Held in place by spring friction, which prevents them from sliding when the nuts are loosened for setting
Feature 08:
Each tram has a knurled swivel grip at the top that turns freely, making it very convenient to swing the tool when scribing circles
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada
Beam Size (in):
10-1/2"
Beam Size (mm):
263mm
Description:
TRAMMEL, 9" DIVIDING RANGE
Flat Stock Inventory:
0
Item Class:
Stand-Alone
Mt Airy Inventory :
0
Parent SKU As a Regular Field:
251
Product Group Sort:
trammels
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=C251A
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
TRAMMEL, 9" DIVIDING RANGE
Item Segmentation:
Catalog
Long Description:
Each
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/C251AcUSp1.tif
Manufacturer's code:
049659
Maximum Dividing Range (in):
9"
Maximum Dividing Range (mm):
225mm
Maximum Scribing Diameter Range (in):
18"
Maximum Scribing Diameter Range (mm):
450mm
NAFTA Producer:
Yes
Name:
TRAMMEL, 9" DIVIDING RANGE
Item ID:
C251A
POA Flag:
N
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/C251AcUSp1.tif
Product Photo 02:
https://s3-us-west-2.amazonaws.com/catsy.833/C251attachcUSp1.tif
Product Photo 03:
https://s3-us-west-2.amazonaws.com/catsy.833/C251AcUSa1.tif
Product Title:
C251A Steel Beam Trammel
SDS Indicator:
N
Series Title:
251 Steel Beam Trammels and Attachments
Shelf Pack Item Qty:
1
Shelf Pack Pricing Quantity:
1
Short Description:
Steel Beam Trammel, 9"
Status:
Active
A0006160MSDSINDICATOR:
N
A002040UCC12UPCA:
049659512052
A002050EANUCC13EAN13:
0049659512052
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (in):
1.3
Unit Pack Height (mm):
30.48
Unit Pack Item Qty:
1
Unit Pack Length (in):
11.4
Unit Pack Length (mm):
279.4
Unit Pack Weight (kg):
0.4082328
Unit Pack Weight (lbs):
0.95
Unit Pack Width (in):
5.4
Unit Pack Width (mm):
129.54
UOM:
Each
UPC:
049659512052
Use Placeholder Photo:
N
US List Price:
$256.00
US Next List Price:
$256.00
US Web Price:
$256.00
Web Catalog-US-EN:
Y
Web Price:
$256.00
Web Priority-US-EN:
36600240
Electronic or Mechanical:
Mechanical
Category L1:
Calipers, Dividers & Trammels
Category L2:
Trammels
Sales Category:
TOOLS.HARDWARE TOOLS (DISCOUNTABLE).
01 Attribute :
Maximum Dividing Range (in)
01 Spec:
0
02 Attribute:
Maximum Dividing Range (mm)
02 Spec:
225mm
03 Attribute:
Maximum Scribing Diameter Range (in)
03 Spec:
18"
04 Attribute:
Maximum Scribing Diameter Range (mm)
04 Spec:
450mm
05 Attribute:
Beam Size (in)
05 Spec:
10-1/2"
06 Attribute:
Beam Size (mm)
06 Spec:
263mm
Discontinued:
false
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Current Catalog:
33
Current Catalog Page:
317
Catalog Section Page:
7
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-14-Calipers-Dividers-and-Trammels.pdf
Western Link Inventory:
0
The Starrett C251A is a rigid, well-designed trammel for layout, scribing, and measuring distances and circles. The top of the beam is flattened so that when the trams are clamped in position, they will not turn from pressure on the points. Trammel, 9" (225mm) Dividing Range points.
