G-80702 36" x 36" x 6" Surface Plate

G-80702 36" x 36" x 6" Surface Plate

$3,327.00
(No reviews yet) Write a Review
SKU:
G-80702
UPC:
049659807028
Discontinued:
false
A002040UCC12UPCA:
049659807028
A002050EANUCC13EAN13:
0049659807028
Available for Purchase-US-EN:
N
Category:
Discontinued
EAN:
0049659807028
EDP:
80702
Feature 01:
Meets or exceeds U.S. Federal Specification GGG-P-463c and ASME B89.3.7 2013 for flatness.
Feature 02:
Great surface hardness and wear resistance €“ the highest percentage of quartz crystals of any granite plate.
Feature 03:
Smooth, jewel-like quartz bearing points protect accuracy and finish of both the surface and the tools used on it.
Feature 04:
Quality and economy combined.
Feature 05:
Comparable to black granite plates while outwearing them as much as 5 to 1.
Feature 06:
Meets or exceeds 50 lb per square foot (24kg per 1,000 sq. cm) load bearing specifications. Available in 100 lb (45kg) test series.
Feature 07:
Standard-size plates are mounted on resilient support pads, providing isolation from normal vibration and a non-distorting 3-point suspension.
Feature 08:
Packed one per crate with skids for forklift handling.
Grade (U.S.):
AA Laboratory
Item Segmentation:
Catalog
Ledges:
2
material:
Crystal Pink
NAFTA Producer:
Yes
Item ID:
G-80702
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/2-ledge+granite_ecUSp1.tif
Product Title:
G-80702 36" x 36" x 6" Surface Plate
Short Description:
36" x 36" x 6" Crystal Pink® Granite Surface Plate - Grade AA, 2 Ledges
Show in Web Nav?:
Yes
Size LxW (in):
36 x 36
Size LxW (mm):
900 x 900
Size LxWxT (in):
36 x 36 x 6
Size LxWxT (mm):
900 x 900 x 150
Superseded By:
G-80711
Thickness (in):
6
Thickness (mm):
150
Unit Pack Height (in):
14
Unit Pack Item Qty:
1
Unit Pack Length (in):
44
Unit Pack Width (in):
44
UOM:
Each
US List Price:
$0.00
US Promo Price:
$0.00
US Web Price:
$3327.00
Web Catalog-US-EN:
Y
Web Priority-US-EN:
44800740
Unit Pack Weight (lbs):
775
Series Title:
Crystal Pink® Granite Surface Plate
Status:
Active
Global Product Classification:
SURFACE PLATE CR PINK 36X36X6 AA 2L
Manufacturer's code:
049659
Athol Inventory:
0
Available In Region:
United States|Canada
Current Catalog:
33
Current Catalog Page:
415
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Mt Airy Inventory:
0
Parent SKU As a Regular Field:
GSP-CP
Product Group Sort:
discontinued
Rocky Mountain Inventory:
0
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Webber Inventory:
0
Website-URL:
https://www.starrett.com/metrology/product-detail/G-80702
Western Link Inventory:
0
Long Description:
G-80702
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/2-ledge+granite_ecUSp1.tif
Placeholder Photo:
https://s3-us-west-2.amazonaws.com/catsy.833/2-ledge+granite_ecUSp1.tif
POA Flag:
N
Schedule B Number:
6802.93.0000
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (mm):
355.6
Unit Pack Length (mm):
1117.6
Unit Pack Weight (kg):
351.5338
Unit Pack Width (mm):
1117.6
Use Placeholder Photo:
Y
Web Price:
$3327.00
Country of Origin:
United States
36" x 36" (900mm x 900mm) Crystal Pink® Granite Surface Plate with a 6" (150mm) thickness. Crystal Pink® Granite has the highest percentage of quartz of any granite for superb wear resistance. Grade AA (Laboratory Grade) for precision operations in constant temperature gaging rooms and metrology departments. .000150" (0.0038mm) Flatness unilateral tolerance. Produced with 2 ledges. [Discontinued 05/2022]
