The Starrett AccuBore is a high-quality, trigger-activated, three-point contact bore gaging system with extended range and Bluetooth Data Output. Its convenient single-hand operation provides speed and control. It features a large, easy-to-read digital display, and a mechanically-driven parallel anvil, establishing a more true alignment to the axis of the bore that provides consistent pressure, resulting in more accurate readings than models with spring-driven contacts. Speed and convenience are further enhanced by the repositionable AccuBore indicator, which may be swiveled and rotated for left, right hand or even vertical viewing. The gage also features a display with integrated LEDs tolerances that quickly indicate whether a bore measurement is within a preset tolerance window. SET, Pistol Grip, 6 - 8" (150-200mm) Range window.
S781BXTLZ AccuBore Electronic Bore Gage Set
$6,662.00
- SKU:
- S781BXTLZ
- UPC:
- 049659729894
- Category:
- Precision Measuring Tools > Precision Hand Tools > Bore Gages > Electronic Pistol Grip Bore Gages
- Cal Prop 65 Chemical:
- Lead
- Cal Prop 65 Warning:
- Y
- Cal Prop 65 Statement:
- WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
- Country of Origin :
- United Kingdom
- EAN:
- 0049659729894
- EDP:
- 72989
- Feature 01:
- Single-hand operation with right- and left-hand viewing flexibility
- Feature 02:
- Large, easy-to-read digital display with integrated LEDs tolerances
- Feature 03:
- Enhanced wear life with carbide-faced contacts - available from 5/16" to 8"
- Feature 04:
- True alignment with mechanically-driven parallel anvils
- Feature 05:
- Push button inch/metric conversion
- Feature 06:
- Preset and preset recall
- Feature 07:
- Hold, max/min and zeroing capabilities
- Feature 08:
- Blind bore measurement is standard from .50" (12.7mm) and above
- Feature 09:
- Bluetooth output capability for Statistical Process Control (SPC) analysis
- Approximate Measuring Depth (in):
- 4"
- Approximate Measuring Depth (mm):
- 100mm
- Assembled in US:
- N
- Athol Inventory:
- 2
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Description:
- ELECT BT PISTOL BORE GAGE SET 6.000-8.000" RANGE
- Flat Stock Inventory:
- 0
- Item Class:
- Stand-Alone
- Max. Range (in):
- 8
- Max. Range (mm):
- 200
- Min. Range (in):
- 6
- Min. Range (mm):
- 150
- Mt Airy Inventory :
- 0
- Parent SKU As a Regular Field:
- 781BXT
- Product Group Sort:
- icc110601
- Webber Inventory:
- 0
- Website-URL:
- https://www.starrett.com/details?cat-no=S781BXTLZ
- Rocky Mountain Inventory:
- 0
- Show in Web Nav?:
- Yes
- To Delete:
- false
- To Remove:
- false
- Total Inventory:
- 2
- US Web Temp Hold:
- Off
- Global Product Classification:
- ELECT BT PISTOL BORE GAGE SET 6.000-8.000" RANGE
- Item Segmentation:
- Catalog
- Long Description:
- Each
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/S781BXTLZcUSp1.tif
- Manufacturer's code:
- 049659
- Name:
- ELECT BT PISTOL BORE GAGE SET 6.000-8.000" RANGE
- Item ID:
- S781BXTLZ
- Number of Heads:
- 2
- Number of Rings:
- 1
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/S781BXTLZcUSp1.tif
- Product Title:
- S781BXTLZ AccuBore Electronic Bore Gage Set
- Range (in):
- 6 - 8"
- Range (mm):
- 150-200mm
- Resolution (in):
- .00005"
- Resolution (mm):
- 0.001mm
- Series Title:
- 781BXT AccuBore Electronic Bore Gages
- Short Description:
- AccuBore Electronic Bore Gage Set, 3-Point Contact (6-8" (150-200mm) Range) and built-in Bluetooth
- SPC Output:
- Yes
- Status:
- Active
- Orderable Online Today (US Only):
- Yes
- A002040UCC12UPCA:
- 049659729894
- A002050EANUCC13EAN13:
- 0049659729894
- Top 354:
- N
- Unit Pack Height (in):
- 11
- Unit Pack Invoiced:
- N
- Unit Pack Length (in):
- 27
- Unit Pack Shippable:
- N
- Unit Pack Weight (lbs):
- 54
- Unit Pack Width (in):
- 15
- UOM:
- Each
- UPC:
- 049659729894
- Use Placeholder Photo:
- N
- User Manual URL-US-EN:
- https://www.starrett.com/um-781
- US List Price:
- $6662.00
- US Next List Price:
- $6662.00
- US Web Price:
- $6662.00
- Web Catalog-US-EN:
- Y
- Web Price:
- $6662.00
- Web Priority-US-EN:
- 30400150
- Electronic or Mechanical:
- Electronic
- Category L1:
- Bore Gages
- Category L2:
- Electronic Pistol Grip Bore Gages
- 01 Attribute :
- Range (in)
- 01 Spec:
- 6 - 8"
- 02 Attribute:
- Range (mm)
- 02 Spec:
- 150-200mm
- 03 Attribute:
- Resolution (in)
- 03 Spec:
- .00005"
- 04 Attribute:
- Resolution (mm)
- 04 Spec:
- 0.001mm
- 05 Attribute:
- SPC Output
- 05 Spec:
- Yes
- 06 Attribute:
- Approximate Measuring Depth (in)
- 06 Spec:
- 4"
- 08 Attribute:
- Number of Heads
- 08 Spec:
- 2
- 09 Attribute:
- Number of Rings
- 09 Spec:
- 1
- Discontinued:
- false
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- Current Catalog Page:
- 206
- Catalog Section Page:
- 4
- Catalog:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- Catalog Section:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-06-Bore-Gages.pdf
- Brochure 1:
- https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
- Western Link Inventory:
- 0
- Unit Pack Item Qty:
- 1
