S78XTDZ Bore Gage Set

S78XTDZ Bore Gage Set

$2,600.00
(No reviews yet) Write a Review
SKU:
S78XTDZ
UPC:
049659681543
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog URL:
https://www.starrett.com/dms/flipbooks/Cat-33/index.html?page=209
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Category:
Precision Measuring Tools > Precision Hand Tools > Bore Gages > Mechanical Bore Micrometers
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Country of Origin :
United Kingdom
Current Catalog Page:
209
EAN:
0049659681543
EDP:
68154
Feature 01:
Wide measurement range without changing anvils
Feature 02:
Tungsten carbide measuring faces on all 3-point heads above 1/2" (12.5mm)
Feature 03:
Ratchet stop ensures consistent measurements
Feature 04:
Self-centering contacts for true readings
Feature 05:
Blind bore measuring capability above 1/2" (12.5mm) diameter
Feature 06:
Extensions available up to 6" (150mm) for deep hole measuring
Feature 07:
Setting rings included
Feature 08:
Depth stop/collar also available for .080"-.250" (1-6mm) range
Feature 09:
Each micrometer bore gage is furnished in a case, complete with setting ring, contacts, wrenches, and instructions
Approximate Measuring Depth (in):
2-1/4 to 2-5/8"
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Max. Range (in):
0.75
Min. Range (in):
0.375
Mt Airy Inventory :
0
Parent SKU As a Regular Field:
S78XT
Product Group Sort:
icc110603
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=S78XTDZ
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Top Seller:
Yes
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
MICROMETER, INSIDE SET 3/8-3/4" RANGE
Graduations (in):
.00025
Item Segmentation:
Catalog
Long Description:
SET
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/S78XTDZcUSp1.tif
Manufacturer's code:
049659
NAFTA Producer:
No
Name:
MICROMETER, INSIDE SET 3/8-3/4" RANGE
Item ID:
S78XTDZ
Number of Heads:
3
Number of Rings:
2
Product made to order status:
MTA
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/S78XTDZcUSp1.tif
Product Title:
S78XTDZ Bore Gage Set
Range (in):
3/8" to 3/4"
Series Title:
78, 78M Micrometer Sets Extended Travel with Cases
Short Description:
Inside Bore Gage Micrometer Set, 3/8-3/4", .00025"
Status:
Active
A002040UCC12UPCA:
049659681543
A002050EANUCC13EAN13:
0049659681543
Tariff Code for entry into Mexico:
No
Top 354:
N
Unit Pack Height (in):
3.3
Unit Pack Height (mm):
83.82
Unit Pack Item Qty:
1
Unit Pack Length (in):
12.3
Unit Pack Length (mm):
312.42
Unit Pack Weight (kg):
2.4040376
Unit Pack Weight (lbs):
5.3
Unit Pack Width (in):
9.2
Unit Pack Width (mm):
233.68
UOM:
SET
UPC:
049659681543
Use Placeholder Photo:
N
US List Price:
$2600.00
US Next List Price:
$2600.00
US Web Price:
$2600.00
Web Catalog-EN-GB:
Y
Web Catalog-ES-ES:
Y
Web Catalog-US-EN:
Y
Web Price:
$2600.00
Web Priority-EN-GB:
797
Web Priority-ES-ES:
797
Web Priority-US-EN:
31200135
Electronic or Mechanical:
Mechanical
Category L1:
Bore Gages
Category L2:
Mechanical Bore Micrometers
Sales Category:
TOOLS.TOOLS (DISCOUNTABLE).
01 Attribute :
Range (in)
01 Spec:
3/8" to 3/4"
02 Attribute:
Approximate Measuring Depth (in)
02 Spec:
2-1/4 to 2-5/8"
03 Attribute:
Number of Heads
03 Spec:
3
04 Attribute:
Number of Rings
04 Spec:
2
05 Attribute:
Graduations (in)
05 Spec:
.00025
Discontinued:
false
Catalog Section Page:
7
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-06-Bore-Gages.pdf
Western Link Inventory:
0
The Starrett 78XT Series Internal Micrometer features extended travel, reducing the need to exchange anvils. The ground contact point seats the internal micrometer faster and more accurately than the spherical contacts found in other gages. The rugged and accurate internal micrometer is available individually or in economical sets from .040-12" (1-300mm). SET, 3/8-3/4" Range, w/3 Point Carbide Contact.
