Tungsten carbide tipped with positive rake teeth for high alloy and stainless steels, nonferrous metals and reinforced fabrics. Complete assembly with arbor and pilot drills. Recommended for use on sheet metal up to 1/8" (3mm) thick.
SM100 Sheet Metal Carbide Tipped Hole Saw
$177.92
- SKU:
- SM100
- UPC:
- 049659119015
- Category:
- PTA and Hand Tools > Hole Saws, Jigs, Recips > Hole Saws > Sheet Metal - Carbide Tipped Hole Saws
- Cal Prop 65 Chemical:
- Cobalt
- Current Catalog:
- 72
- Current Catalog Page:
- 16
- Assembled in US:
- N
- Athol Inventory:
- 0
- Available for Purchase-US-EN:
- Y
- Power Tool:
- Drill|Drill Press
- Flat Stock Inventory:
- 0
- In Sugar Catalog:
- Yes
- Item Class:
- Stand-Alone
- Parent SKU As a Regular Field:
- SM
- Product Group Sort:
- sheet_metal_carbide_tipped_hole_saws
- Webber Inventory:
- 0
- Website-URL:
- https://www.starrett.com/details?cat-no=SM100
- Rocky Mountain Inventory:
- 0
- Show in Web Nav?:
- Yes
- To Delete:
- false
- To Remove:
- false
- Total Inventory:
- 18
- US Web Temp Hold:
- Off
- Global Product Classification:
- HO/S 3 15/16" TCT SHEETMETAL
- Item Segmentation:
- Catalog
- Long Description:
- Each
- Manufacturer's code:
- 049659
- Next Catalog:
- 34
- Item ID:
- SM100
- Product made to order status:
- MTO
- A002040UCC12UPCA:
- 049659119015
- A002050EANUCC13EAN13:
- 0049659119015
- Allow Testimonial:
- Y
- Top 354:
- N
- Unit Pack Pricing Unit of Measure:
- Each
- Unit Pack Unit Package:
- BOX
- UOM:
- Each
- Use Placeholder Photo:
- N
- US Web Price:
- $177.92
- Web Catalog-US-EN:
- Y
- Web Price:
- $177.92
- Discontinued:
- false
- Western Link Inventory:
- 0
- Category L1:
- Hole Saws
- Category L2:
- Sheet Metal - Carbide Tipped
- US Promo Price:
- $0.00
- 01 Attribute:
- Diameter (in)
- Schedule B Number:
- 8202.99.0000
- Available In Region:
- United States|Canada|New Zealand
- Mt Airy Inventory:
- 18
- Country of Origin:
- China
- 01 Spec:
- 3-15/16"
- 02 Attribute:
- Diameter (mm)
- 02 Spec:
- 100
- 03 Attribute:
- Cutting Depth (in)
- 03 Spec:
- 1/2"
- 04 Attribute:
- Cutting Depth (mm)
- 04 Spec:
- 13mm
- 05 Attribute:
- Teeth per Inch (25mm)
- 05 Spec:
- 18
- 06 Attribute:
- Color
- 06 Spec:
- Grey
- 07 Attribute:
- Body Material
- 07 Spec:
- Steel
- 08 Attribute:
- Teeth Type
- 08 Spec:
- Carbide
- 09 Attribute:
- Arbor Type
- 09 Spec:
- Fitted
- 10 Attribute:
- Application Material
- 10 Spec:
- Metal, Stainless, non-ferrous sheet / plate up to 1/2" (13mm)
- Arbor Type:
- Fitted
- Cal Prop 65 Statement:
- WARNING: This product contains cobalt, a chemical known to the State of California to cause cancer. For more information go to: www.P65Warnings.ca.gov
- Catalog:
- https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Power-Tool-Accessories-and-Hand-Tools-Catalog-72.pdf
- Color:
- Grey
- Diameter (in):
- 3-15/16"
- Diameter (mm):
- 100
- EAN:
- 0049659119015
- EDP:
- 11901
- Feature 01:
- Ideal for cutting stainless and high alloy steels, non-ferrous light metals and reinforced fabrics at a much faster speed than bi-metal holesaws
- Feature 02:
- Tough Tungsten Carbide Tipped teeth have a positive cutting angle which provide fast and efficient removal of chips and swarf
- Feature 03:
- Ideal for production cutting and particularly suitable for use in drills with limited speed control
- Feature 04:
- Tungsten Carbide Tipped teeth provide superb product life and cutting performance
- Feature 05:
- Safety stop at the base of the hole saw prevents drilling beyond the maximum cutting depth of 13mm (1/2" )
- Feature 06:
- Complete assembly - there is no requirement to purchase a separate drive arbor and pilot drill (Replacement pilot drills available)
- Orderable Online Today (US Only):
- Yes
- Product Photo 01:
- https://s3.us-west-2.amazonaws.com/catsy.833/SM100e11901cUSp1.tif
- Product Photo 02:
- https://s3.us-west-2.amazonaws.com/catsy.833/SMcUSa1.tif
- Product Title:
- SM100 Sheet Metal Carbide Tipped Hole Saw
- Product Type:
- Hole Saw
- Short Description:
- 3-15/16'' (100mm) Carbide Tipped Sheet Metal Hole Saw
- SLC Certification:
- Not Applicable
- Technical Reference 1:
- https://s3.us-west-2.amazonaws.com/catsy.833/Hole+Saw+Speed+Card+Bulletin+194.pdf
- Teeth per Inch (25mm):
- 18
- Unit Pack Height (in):
- 4.5
- Unit Pack Item Qty:
- 1
- Unit Pack Length (in):
- 6.1
- Unit Pack Width (in):
- 4.6
- US List Price:
- $237.23
- Web Priority-US-EN:
- 64400195
- YouTube Video Code 01-US-EN:
- WCQ6Wlo-fw4
- Unit Pack Weight (lbs):
- 1.19
- User Manual URL-US-EN:
- https://www.starrett.com/UM-Hole-Saw
- Series Title:
- TCT Tungsten Carbide Tipped Sheet Metal Hole Saw Assemblies
- Status:
- Active
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Power+Tool+Accessories+and+Hand+Tools+-+Catalog+72.pdf
- Data Sheet URL-US-EN:
- https://www.starrett.com/vdoc/Hole Saw Speed Card (Bulletin 194)
- Body Material:
- Steel
- Cal Prop 65 Warning:
- Y
- Cutting Depth (in):
- 1/2"
- Cutting Depth (mm):
- 13mm
- Main Image:
- https://s3.us-west-2.amazonaws.com/catsy.833/SM100e11901cUSp1.tif
- Application Description:
- Hole drilling
- Application Material:
- Metal, Stainless, non-ferrous sheet / plate up to 1/2" (13mm)
- Teeth Type:
- Carbide
