The Starrett 469, 469M Series Large, Super-Precision Micrometer Head is our most accurate micrometer head. It is also available on special order with double graduations in red and black on the sleeve and thimble, permitting readings both ways with the spindle moving in either direction. The micrometer head has a 4-1/16" (103mm) thimble diameter and is graduated to .000050", 001m, for direct reading. It also has staggered graduations for easy counting and reading of lines. Spindle is carbide faced for long life. 0-1" Range, .000050" Grad with Speeder, Carbide Face.
T469HXSP Large, Super-Precision Micrometer Head
$1,507.00
- SKU:
- T469HXSP
- UPC:
- 049659671292
- Category:
- Precision Measuring Tools > Precision Hand Tools > Micrometers > Micrometer Heads
- Cal Prop 65 Chemical:
- Lead
- Accessory:
- 247A|247B|247C|247D|247E
- Assembled in US:
- N
- Athol Inventory:
- 1
- Available for Purchase-US-EN:
- Y
- Flat Stock Inventory:
- 0
- Item Class:
- Stand-Alone
- Parent SKU As a Regular Field:
- 469
- Product Group Sort:
- icc110106
- Webber Inventory:
- 0
- Website-URL:
- https://www.starrett.com/details?cat-no=T469HXSP
- Rocky Mountain Inventory:
- 0
- Show in Web Nav?:
- Yes
- To Delete:
- false
- To Remove:
- false
- Total Inventory:
- 1
- US Web Temp Hold:
- Off
- Global Product Classification:
- MICROMETER HEAD
- Item Segmentation:
- Catalog
- Long Description:
- Each
- Made in America:
- Yes
- Manufacturer's code:
- 049659
- NAFTA Producer:
- Yes
- Item ID:
- T469HXSP
- Shelf Pack Pricing Quantity:
- 1
- A002040UCC12UPCA:
- 049659671292
- A002050EANUCC13EAN13:
- 0049659671292
- Tariff Code for entry into Mexico:
- Yes
- Top 354:
- N
- Unit Pack Height (mm):
- 127
- Unit Pack Invoiced:
- N
- Unit Pack Length (mm):
- 185.42
- Unit Pack Pricing Unit of Measure:
- EA
- Unit Pack Shippable:
- N
- Unit Pack Weight (kg):
- 0.9979024
- Unit Pack Width (mm):
- 134.62
- UOM:
- Each
- Use Placeholder Photo:
- N
- US Web Price:
- $1507.00
- Web Catalog-US-EN:
- Y
- Web Price:
- $1507.00
- Starrett Model No.:
- 469
- Discontinued:
- false
- Current Catalog:
- 33
- Current Catalog Page:
- 72
- Catalog Section Page:
- 54
- Catalog Section:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-01-Micrometers.pdf
- Western Link Inventory:
- 0
- Category L1:
- Micrometers
- Category L2:
- Micrometer Heads
- US Promo Price:
- $0.00
- 01 Attribute:
- Micrometer Type
- COO Detail:
- Made in the USA with US and Global Content
- Schedule B Number:
- 9017.30.4000
- Product made to order status:
- MTO
- Available In Region:
- United States|Canada
- Mt Airy Inventory:
- 0
- Country of Origin:
- United States
- 01 Spec:
- Mechanical Micrometer Head
- 02 Attribute:
- Electronic or Mechanical
- 02 Spec:
- Mechanical
- 03 Attribute:
- Range (in)
- 03 Spec:
- 0-1"
- 04 Attribute:
- Accuracy (in)
- 04 Spec:
- +/- .00003"
- 05 Attribute:
- Graduations (in)
- 05 Spec:
- .00005"
- 06 Attribute:
- Thimble Type
- 06 Spec:
- Plain
- 07 Attribute:
- Spindle Type
- 07 Spec:
- Flat
- 08 Attribute:
- Spindle Material
- 08 Spec:
- Carbide
- Accuracy (in):
- +/- .00003"
- Cal Prop 65 Statement:
- WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
- Catalog:
- https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- EAN:
- 0049659671292
- EDP:
- 67129
- Electronic or Mechanical:
- Mechanical
- Feature 01:
- Starrett satin chrome finish - no glare - resists rust on all reading surfaces
- Feature 02:
- Advanced sleeve design with staggered lines and distinct figures for precise and easy readability
- Feature 03:
- Quick-reading figures
- Feature 04:
- Extremely hard and stable one-piece spindle (the heart of our accuracy and long life)
- Feature 05:
- Micro-lapped measuring face for flatness and squareness
- Feature 06:
- Quick and easy adjustment
- Graduations (in):
- .00005"
- material:
- Steel
- Micrometer Type:
- Mechanical Micrometer Head
- Orderable Online Today (US Only):
- Yes
- Product Photo 01:
- https://s3.us-west-2.amazonaws.com/catsy.833/T469HXSPcUSp1.tif
- Product Title:
- T469HXSP Large, Super-Precision Micrometer Head
- Product Type:
- Micrometer Head
- Range (in):
- 0-1"
- Short Description:
- Large, Super-Precision Micrometer Head, Plain Thimble, 0-1" Range,
- Thimble Type:
- Plain
- Unit Pack Height (in):
- 5.2
- Unit Pack Item Qty:
- 1
- Unit Pack Length (in):
- 9.6
- Unit Pack Width (in):
- 6
- US List Price:
- $1507.00
- Web Priority-US-EN:
- 14200130
- Unit Pack Weight (lbs):
- 2.35
- Series Title:
- 469X, 469XM Large, Super-Precision Micrometer Heads
- Status:
- Active
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- Cal Prop 65 Warning:
- Y
- Max. Range (in):
- 1
- Min. Range (in):
- 0
- Main Image:
- https://s3.us-west-2.amazonaws.com/catsy.833/T469HXSPcUSp1.tif
- Spindle Material:
- Carbide
- Spindle Type:
- Flat
