The Starrett 3732 Electronic Micrometer is a full-featured precision measuring tool built with customary Starrett quality and workmanship. The 3732 series includes a large, easy-to-read, high-contrast LCD digital readout for clear readings. With its automatic OFF functionality, smooth friction thimble for uniform pressure, and balanced frame design, Starrett products provide comfortable and accurate measuring Its no-glare satin chrome finish minimizes annoying surface glare under bright lights indoors. 0-25mm (0-.984 Approx Inch), 0.001mm (0.00005") Resolution.
3732MEXFL-25 Inch/Metric Electronic Micrometer without Output
$225.00
- SKU:
- 3732MEXFL-25
- UPC:
- 049659122749
- Product made to order status:
- MTA
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/3732MEXFL-25cUSp1.tif
- Product Title:
- 3732MEXFL-25 Inch/Metric Electronic Micrometer without Output
- Published Locations:
- Catalog 33
- Range (in):
- 0-.984"
- Range (mm):
- 0-25mm
- Resolution (in):
- .00005"
- Resolution (mm):
- 0.001mm
- Series Title:
- 3732 Electronic Micrometers Without Output
- Short Description:
- LCD Outside Micrometer, Friction Thimble, Carbide Anvil, 0.001mm Res., 0-25mm Range
- SPC Output:
- No
- Spindle Type:
- Flat
- Status:
- Active
- Accuracy (in):
- +/-.0001"
- Accuracy (mm):
- +/-.002mm
- Anvil Type:
- Flat
- Anvil/Spindle Material:
- Carbide
- Thimble Graduations:
- Metric
- Thimble Type:
- Friction
- Top 354:
- N
- Unit Pack Height (in):
- 1.9
- Unit Pack Item Qty:
- 1
- Unit Pack Length (in):
- 6.9
- Unit Pack Weight (lbs):
- 1.3
- Unit Pack Width (in):
- 5.3
- UOM:
- Each
- UPC:
- 049659122749
- Use Placeholder Photo:
- N
- US List Price:
- $225.00
- US Web Price:
- $225.00
- Web Catalog-EN-GB:
- Y
- Web Catalog-ES-ES:
- Y
- Web Catalog-US-EN:
- Y
- Web Priority-EN-GB:
- 984
- Web Priority-ES-ES:
- 850
- Web Priority-US-EN:
- 12200035
- Wireless:
- No
- A002040UCC12UPCA:
- 049659122749
- A002050EANUCC13EAN13:
- 0049659122749
- Catalog:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Catalog+33+Precision+Hand+Tools.pdf
- Catalog URL:
- https://www.starrett.com/dms/flipbooks/Cat-33/index.html?page=25
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Band+Saw+Blades+Catalog+60.pdf
- Category:
- Precision Measuring Tools > Precision Hand Tools > Micrometers > Electronic Outside Micrometers
- Cal Prop 65 Chemical:
- Lead
- Cal Prop 65 Warning:
- Y
- Cal Prop 65 Statement:
- WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
- Country of Origin :
- China
- Current Catalog:
- 33
- Current Catalog Page:
- 25
- Datasheet:
- https://s3-us-west-2.amazonaws.com/catsy.833/3732-electronic-micrometers-bulletin-392.pdf
- Data Sheet URL-EN-GB:
- http://www.starrett.com/docs/data-sheets/3732-electronic-micrometers---bulletin-392.pdf?Status=Master
- Data Sheet URL-US-EN:
- https://www.starrett.com/vdoc/3732 Electronic Micrometers (Bulletin 392)
- Display Type:
- LCD
- EAN:
- 0049659122749
- EDP:
- 12274
- Effective List Date:
- 2022-12-31
- Effective Web Date:
- 2022-07-01
- Accessory:
- 3206
- Feature 01:
- Balanced frame design for comfortable and accurate measuring
- Feature 02:
- Large, easy-to-read, high-contrast LCD digital readout
- Feature 03:
- Starrett No-glare satin chrome finish on thimble and sleeve minimizes annoying surface glare under bright lights indoors or filters out UV light
- Feature 04:
- No-glare black wrinkle finish on frame
- Feature 05:
- Hard and stable one-piece friction thimble permits one-hand operation of micrometer and uniform contact pressure
- Feature 06:
- Ability to zero tool at any position as well as retain and return to the true zero reading of the micrometer
- Feature 07:
- Ring-type knurled lock nut for quick and sure locking
- Feature 08:
- Micro-lapped carbide measuring faces
- Feature 09:
- One 3-volt battery included for extended usage
- Feature 10:
- Automatic OFF
- Feature 11:
- Measurement HOLD button
- Feature 12:
- Inch/millimeter metric conversion provides simple, universal, standardized unit of measurement at any position
- Feature 13:
- PRESET button to install any reading at any position
- Feature 14:
- Metric/English (ME) models include inch and millimeter graduations on shell and thimble
- Athol Inventory:
- 0
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Brochure:
- https://s3-us-west-2.amazonaws.com/catsy.833/Catalog-33-Section-01-Micrometers.pdf
- Brochure 2:
- https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
- Brochure URL-US-EN:
- https://www.starrett.com/vdoc/Catalog 33 - Section 1 - Micrometers
- CAN List Price:
- CA$285.00
- CAN Price List Name:
- 133W - 2021
- CAN Web Price:
- CA$236.07
- Combined Dollar Sales:
- 9098.92
- Combined Unit Sales :
- 71
- Description:
- The Starrett 3732 Electronic Micrometer is a full-featured precision measuring tool built with
- In Sugar Catalog:
- Yes
- Item Class:
- Stand-Alone
- Max. Range (in):
- 0.984
- Max. Range (mm):
- 25
- Min. Range (in):
- 0
- Min. Range (mm):
- 0
- Parent SKU As a Regular Field:
- 3732
- Product Group Sort:
- pim_icc_num_110102
- Website-URL:
- https://www.starrett.com/details?cat-no=3732MEXFL-25
- Show in Web Nav?:
- Yes
- Top Seller:
- Yes
- Total Inventory:
- 0
- Unit Sales 2020:
- 23
- Unit Sales 2021:
- 26
- Unit Sales 2022:
- 22
- US Price List Name:
- 133W - 2021
- US Web Temp Hold:
- Off
- Web Price:
- $225.00
- Starrett Model No.:
- 3732
- ICC:
- 110102 Electronic Outside Micr
- Item Discount Code:
- A
- Item Segmentation:
- Catalog
- Lock Nut Type:
- Knurled Ring Type
- Long Description:
- ELECTRONIC MICROMETER, W/O OUTPUT 0-25mm
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/3732MEXFL-25cUSp1.tif
- Manufacturer's code:
- 049659
- Micrometer Type:
- Outside
- NAFTA Producer:
- No
- Name:
- ELECTRONIC MICROMETER, W/O OUTPUT 0-25mm
- Item ID:
- 3732MEXFL-25
- Electronic or Mechanical:
- Electronic
- Category L1:
- Micrometers
- Category L2:
- Electronic Outside Micrometers
- Sales Category:
- TOOLS.HARDWARE TOOLS (DISCOUNTABLE).
- Flat Stock Inventory:
- 0
- Mt Airy Inventory :
- 0
- Rocky Mountain Inventory:
- 0
- US Next List Price:
- $225.00
- IBC Category 1:
- Testing, Measuring and Inspection
- IBC Category 2:
- Dimensional Measurement Tools
- IBC Category 3:
- Micrometers
- To Delete:
- false
- To Remove:
- false
- Dollar Sales 2023:
- $3468.86
- Unit Sales 2023:
- 23
- Webber Inventory:
- 0
- Minimum Order Quantity:
- 0
- SDS Sheet:
- https://s3-us-west-2.amazonaws.com/catsy.833/SDS-Renata-CR2032-ASDS.pdf
- Discontinued:
- false
- Case Type:
- Not included
- 01 Attribute :
- Micrometer Type
- 01 Spec:
- Outside
- 02 Attribute:
- Range (mm)
- 02 Spec:
- 127-152mm
- 03 Attribute:
- Resolution (mm)
- 03 Spec:
- 0.001mm
- 04 Attribute:
- Accuracy (mm)
- 04 Spec:
- +/-.004mm
- 05 Attribute:
- SPC Output
- 05 Spec:
- No
- 06 Attribute:
- Wireless
- 06 Spec:
- No
- 07 Attribute:
- Anvil Type
- 07 Spec:
- Flat
- 08 Attribute:
- Spindle Type
- 08 Spec:
- Flat
- 09 Attribute:
- Anvil/Spindle Material
- 09 Spec:
- Carbide
- 10 Attribute:
- Lock Nut Type
- 10 Spec:
- Knurled Ring Type
- 11 Attribute:
- Thimble Type
- 11 Spec:
- Friction
- 12 Attribute:
- Thimble Graduations
- 12 Spec:
- English
- 13 Attribute:
- Display Type
- 13 Spec:
- LCD
- 14 Attribute:
- Case Type
- 14 Spec:
- Not included
