The Starrett 3753A Electronic Depth Gage is engineered for a high level of accuracy and long service life. Yet they are light and easy to use, with clear, easily-read numbers. This unit measures depths up to 12" (300mm). Additional ranges are also available in the Starrett catalog range.
3753A-12/300 Electronic Depth Gage
$552.00
- SKU:
- 3753A-12/300
- UPC:
- 049659122602
- Product made to order status:
- MTA
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/3753A-12s300cUSp1.tif
- Product Title:
- 3753A-12/300 Electronic Depth Gage
- Range (in):
- 0-12"
- Range (mm):
- 0-300mm
- Resolution (in):
- .0005"
- Resolution (mm):
- 0.01mm
- Series Title:
- 3753A Electronic Depth Gages without Output
- Short Description:
- 12" Electronic Depth Gage, .0005" Resolution, 0-12" Range
- SPC Output:
- No
- Status:
- Active
- Top 354:
- N
- Unit Pack Height (in):
- 1.5
- Unit Pack Height (mm):
- 38.1
- Unit Pack Item Qty:
- 1
- Unit Pack Length (in):
- 17.2
- Unit Pack Length (mm):
- 434.34
- Unit Pack Weight (kg):
- 0.9525432
- Unit Pack Weight (lbs):
- 2.15
- Unit Pack Width (in):
- 5.8
- Unit Pack Width (mm):
- 147.32
- UOM:
- Each
- UPC:
- 049659122602
- Use Placeholder Photo:
- N
- US List Price:
- $552.00
- US Web Price:
- $552.00
- Web Catalog-EN-GB:
- Y
- Web Catalog-ES-ES:
- Y
- Web Catalog-US-EN:
- Y
- Web Priority-EN-GB:
- 997
- Web Priority-ES-ES:
- 997
- Web Priority-US-EN:
- 32600030
- A002040UCC12UPCA:
- 049659122602
- A002050EANUCC13EAN13:
- 0049659122602
- Catalog:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Catalog+33+Precision+Hand+Tools.pdf
- Catalog URL:
- https://www.starrett.com/dms/flipbooks/Cat-33/index.html?page=125
- Category:
- Precision Measuring Tools > Precision Hand Tools > Depth Gages > Electronic Depth Gages
- Cal Prop 65 Warning:
- N
- Country of Origin :
- China
- Current Catalog:
- 33
- Current Catalog Page:
- 125
- Datasheet:
- https://s3-us-west-2.amazonaws.com/catsy.833/3753-electronic-depth-gage-bulletin-576.pdf
- Data Sheet URL-EN-GB:
- http://www.starrett.com/docs/data-sheets/3753-electronic-depth-gages---bulletin-576.pdf?Status=Master
- Data Sheet URL-US-EN:
- https://www.starrett.com/vdoc/3753 Electronic Depth Gage (Bulletin 576)
- EAN:
- 0049659122602
- EDP:
- 12260
- Effective List Date:
- 2022-12-31
- Effective Web Date:
- 2022-07-01
- Accessory:
- PT99492|3648-320|3648-260|3648-180
- Feature 01:
- Clear, easily-read numbers, properly sized for the tool
- Feature 02:
- Hardened stainless steel body and slide for long life
- Feature 03:
- Fine adjustment thumb roll for precision measurements
- Feature 04:
- Lock to hold the slide in position
- Feature 05:
- Hardened base is 3-15/16" (99mm) long, but optional base extensions of 7" and 12" (175 and 300mm) are available.
- Feature 06:
- Spacing between holes is 2-3/4" (70mm).
- Feature 07:
- Hook attachment, to take readings from the edge of a work piece to edges of slots, grooves, shoulders, and other I.D. length dimensioning.
- Feature 08:
- The removable hook has the screw permanently attached to prevent loss.
- Feature 09:
- One-year minimum battery life with furnished 3-volt battery, CR2032
- Feature 10:
- Inch/millimeter conversion
- Feature 11:
- Zero at any position
- Feature 12:
- Manual ON/OFF plus a built in automatic OFF after 15 minutes of nonuse
- Athol Inventory:
- 7
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Brochure:
- https://s3-us-west-2.amazonaws.com/catsy.833/Catalog+33+Section++4+-+Depth+Gages.pdf
- Brochure 2:
- https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
- CAN List Price:
- CA$699.00
- CAN Price List Name:
- 133W - 2021
- CAN Web Price:
- CA$580.50
- Combined Dollar Sales:
- 127710.87
- Combined Unit Sales :
- 415
- Description:
- The Starrett 3753A Electronic Depth Gage is engineered for a high level of accuracy and long service life.
- In Sugar Catalog:
- Yes
- Item Class:
- Stand-Alone
- Max. Range (in):
- 12
- Max. Range (mm):
- 300
- Min. Range (in):
- 0
- Min. Range (mm):
- 0
- Parent SKU As a Regular Field:
- 3753
- Product Group Sort:
- icc110401
- Website-URL:
- https://www.starrett.com/details?cat-no=3753A-12/300
- Show in Web Nav?:
- Yes
- Top Seller:
- Yes
- Total Inventory:
- 7
- Unit Sales 2020:
- 98
- Unit Sales 2021:
- 139
- Unit Sales 2022:
- 178
- US Price List Name:
- 133W - 2021
- US Web Temp Hold:
- Off
- Web Price:
- $552.00
- ICC:
- 110401 Electronic Depth Gages
- Item Discount Code:
- A
- Item Segmentation:
- Catalog
- Long Description:
- DEPTH GAGE
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/3753A-12s300cUSp1.tif
- Manufacturer's code:
- 049659
- NAFTA Producer:
- No
- Name:
- DEPTH GAGE
- Item ID:
- 3753A-12/300
- Electronic or Mechanical:
- Electronic
- Category L1:
- Depth Gages
- Category L2:
- Electronic Depth Gages
- Sales Category:
- TOOLS.HARDWARE TOOLS (DISCOUNTABLE).
- Flat Stock Inventory:
- 0
- Mt Airy Inventory :
- 0
- Rocky Mountain Inventory:
- 0
- US Next List Price:
- $552.00
- IBC Category 1:
- Testing, Measuring and Inspection
- IBC Category 2:
- Depth Measurement Equipment
- IBC Category 3:
- Electronic Depth Gages
- Dimensional Drawing PDF:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-3753A-12_300-Dimensional-Drawing.pdf
- Dimensional Drawing (IMG):
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-3753A-12_300-Dimensional-Drawing.tif
- To Delete:
- false
- To Remove:
- false
- Dollar Sales 2023:
- $109757.19
- Unit Sales 2023:
- 321
- Webber Inventory:
- 0
- Minimum Order Quantity:
- 0
- Orderable Online Today (US Only):
- Yes
- Discontinued:
- false
- 01 Attribute :
- Electronic or Mechanical
- 01 Spec:
- Electronic
- 02 Attribute:
- Range (in)
- 02 Spec:
- 0-12"
- 03 Attribute:
- Range (mm)
- 03 Spec:
- 0-300mm
- 04 Attribute:
- Resolution (in)
- 04 Spec:
- .0005"
- 05 Attribute:
- Resolution (mm)
- 05 Spec:
- 0.01mm
- 06 Attribute:
- SPC Output
- 06 Spec:
- No
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Band+Saw+Blades+Catalog+60.pdf
