The 3753B Electronic Depth Gage is a versatile, easy-to-use tool for measuring depth, slot width, small section sizes and other applications. The gage provides an IP67 level of protection against foreign matter in a hostile shop environment and has an extra-large LCD for excellent readability. It also offers RS232 output to work with Datasure Wireless Systems as well as with cable-based products.
3753B-12/300 Electronic Depth Gage
$846.00
- SKU:
- 3753B-12/300
- UPC:
- 049659126945
- PMRA Regulated:
- N
- Product made to order status:
- MTA
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/3753B-12s300cUSp1.tif
- Product Photo 02:
- https://s3-us-west-2.amazonaws.com/catsy.833/3753B-12s300metric_cUSp1.tif
- Product Photo 03:
- https://s3-us-west-2.amazonaws.com/catsy.833/3753B-12s300cUSp2.tif
- Product Title:
- 3753B-12/300 Electronic Depth Gage
- Range (in):
- 0-12"
- Range (mm):
- 0-300mm
- Refrigerant Indicator:
- N
- Resolution (in):
- .0005"
- Resolution (mm):
- 0.01mm
- RoHS (EU):
- N
- SDS Indicator:
- N
- Series Title:
- 3753B Electronic Depth Gages with Output
- Shelf Pack Invoiced:
- N
- Shelf Pack Shippable:
- N
- Short Description:
- 12" Electronic Depth Gage, .0005" Resolution, 0-12" Range, SPC Output
- SPC Output:
- Yes
- Status:
- Active
- Subject to Environmental Change:
- N
- Temperature Sensitive:
- N
- Top 354:
- N
- Unit Pack Height (in):
- 1.5
- Unit Pack Item Qty:
- 1
- Unit Pack Length (in):
- 17.2
- Unit Pack Weight (lbs):
- 2.15
- Unit Pack Width (in):
- 5.8
- UOM:
- Each
- UPC:
- 049659126945
- US List Price:
- $846.00
- US Web Price:
- $846.00
- Variable Unit:
- N
- Web Catalog-EN-GB:
- Y
- Web Catalog-ES-ES:
- Y
- Web Catalog-US-EN:
- Y
- Web Priority-EN-GB:
- 505
- Web Priority-ES-ES:
- 505
- Web Priority-US-EN:
- 32600035
- A0006160MSDSINDICATOR:
- N
- A000670ROHASCOMPLIANT:
- N
- A002040UCC12UPCA:
- 049659126945
- A002050EANUCC13EAN13:
- 0049659126945
- Catalog:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Catalog+33+Precision+Hand+Tools.pdf
- Catalog URL:
- https://www.starrett.com/dms/flipbooks/Cat-33/index.html?page=126
- Category:
- Precision Measuring Tools > Precision Hand Tools > Depth Gages > Electronic Depth Gages
- Cal Prop 65 Chemical:
- Lead
- Cal Prop 65 Warning:
- N
- Contaminated if Opened:
- N
- Country of Origin :
- China
- Current Catalog:
- 33
- Current Catalog Page:
- 126
- EAN:
- 0049659126945
- EDP:
- 12694
- Effective List Date:
- 2022-12-31
- Effective Web Date:
- 2022-07-01
- Exists in Comport:
- N
- Feature 01:
- Clear, easily-read numbers, properly sized for the tool
- Feature 02:
- Hardened stainless steel body and slide for long life
- Feature 03:
- Fine adjustment thumb roll for precision measurements
- Feature 04:
- Lock to hold the slide in position
- Feature 05:
- Hardened base is 3-15/16" (99mm) long, but optional base extensions of 7" and 12" (175 and 300mm) are available.
- Feature 06:
- Spacing between holes is 2-3/4" (70mm).
- Feature 07:
- Hook attachment, to take readings from the edge of a work piece to edges of slots, grooves, shoulders, and other I.D. length dimensioning.
- Feature 08:
- The removable hook has the screw permanently attached to prevent loss.
- Feature 09:
- One-year minimum battery life with furnished 3-volt battery, CR2032
- Feature 10:
- Inch/millimeter conversion
- Feature 11:
- Zero at any position
- Feature 12:
- Automatic shutoff after 30 minutes of non-use without loss of position upon reactivation
- Feature 13:
- Linear accuracy :+/- .001" (0.03mm)
- Feature 14:
- .0005" (0.010mm) resolution
- Athol Inventory:
- 15
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Brochure:
- https://s3-us-west-2.amazonaws.com/catsy.833/Catalog+33+Section++4+-+Depth+Gages.pdf
- Brochure 2:
- https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
- CAN List Price:
- CA$1072.00
- CAN Price List Name:
- 133W - 2021
- CAN Web Price:
- CA$890.10
- Combined Dollar Sales:
- 37377.35
- Combined Unit Sales :
- 78
- Description:
- The 3753B Electronic Depth Gage is a versatile, easy-to-use tool for measuring depth, slot width,
- In Sugar Catalog:
- Yes
- Item Class:
- Stand-Alone
- Max. Range (in):
- 12
- Max. Range (mm):
- 300
- Min. Range (in):
- 0
- Min. Range (mm):
- 0
- Parent SKU As a Regular Field:
- 3753
- Product Group Sort:
- icc110401
- Website-URL:
- https://www.starrett.com/details?cat-no=3753B-12/300
- Show in Web Nav?:
- Yes
- Top Seller:
- Yes
- Total Inventory:
- 15
- Unit Sales 2020:
- 16
- Unit Sales 2021:
- 21
- Unit Sales 2022:
- 41
- US Price List Name:
- 133W - 2021
- US Web Temp Hold:
- Off
- Web Price:
- $846.00
- Type:
- Depth Gage
- Fragile:
- N
- French Language Included:
- N
- Hazmat Indicator:
- N
- ICC:
- 110401 Electronic Depth Gages
- Item Discount Code:
- B
- Item Segmentation:
- Catalog
- Long Description:
- ELECTRONIC DEPTH GAGE W/CASE, 12", W/OUTPUT
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/3753B-12s300cUSp1.tif
- Manufacturer's code:
- 049659
- Marked Recyclable:
- N
- Marked Returnable:
- N
- Master Pack Invoiced:
- N
- Master Pack Shippable:
- N
- NAFTA Producer:
- No
- Name:
- ELECTRONIC DEPTH GAGE W/CASE, 12", W/OUTPUT
- Item ID:
- 3753B-12/300
- Electronic or Mechanical:
- Electronic
- Category L1:
- Depth Gages
- Category L2:
- Electronic Depth Gages
- Sales Category:
- TOOLS.TOOLS (ELECTRONIC & NON-DISCOUNTABLE).
- Flat Stock Inventory:
- 0
- Mt Airy Inventory :
- 0
- Rocky Mountain Inventory:
- 0
- US Next List Price:
- $846.00
- IBC Category 1:
- Testing, Measuring and Inspection
- IBC Category 2:
- Depth Measurement Equipment
- IBC Category 3:
- Electronic Depth Gages
- To Delete:
- false
- To Remove:
- false
- Dollar Sales 2023:
- $14452.28
- Unit Sales 2023:
- 25
- Webber Inventory:
- 0
- Minimum Order Quantity:
- 0
- SDS Sheet:
- https://s3-us-west-2.amazonaws.com/catsy.833/SDS-Renata-CR2032-ASDS.pdf
- Discontinued:
- false
- Orderable Online Today (US Only):
- Yes
- 01 Attribute :
- Electronic or Mechanical
- 01 Spec:
- Electronic
- 02 Attribute:
- Range (in)
- 02 Spec:
- 0-12"
- 03 Attribute:
- Range (mm)
- 03 Spec:
- 0-300mm
- 04 Attribute:
- Resolution (in)
- 04 Spec:
- .0005"
- 05 Attribute:
- Resolution (mm)
- 05 Spec:
- 0.01mm
- 06 Attribute:
- SPC Output
- 06 Spec:
- Yes
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Band+Saw+Blades+Catalog+60.pdf
