The Starrett 3808 precise, high quality test indicator offers a full complement of standard features. Indicator includes two contact points, two dovetail clamps, swivel post holder, tool post holder, contact wrench and case.
3808AC Dial Test Indicator with Dovetail Mount
$316.00
- SKU:
- 3808AC
- UPC:
- 049659123036
- Category:
- Precision Measuring Tools > Precision Hand Tools > Indicators & Gages > Test Indicators
- Cal Prop 65 Warning:
- N
- Contact Ball Material:
- Steel
- Contact Point Ball Diameter (in):
- .078" (2mm)
- Contact Point Ball Diameter (mm):
- 2mm (.078")
- Contact Point Length (in):
- 5/32"
- Contact Point Length (mm):
- 4mm
- Country of Origin :
- China
- Dial Color:
- White
- Dial Reading:
- 0-4-0
- EAN:
- 0049659123036
- EDP:
- 12303
- Feature 01:
- Three dovetail positioning mounts work with most existing test indicator accessories
- Feature 02:
- Precision gear-driven design with smooth, jeweled movement
- Feature 03:
- Contact point reverses automatically, always maintaining clockwise hand rotation
- Feature 04:
- Contacts are frictionally adjustable and replaceable
- Feature 05:
- Meets or exceeds ANSI/ASME accuracy specifications
- Feature 06:
- High contrast, easy-to-read dials with a white background on inch reading and a yellow background on millimeter reading indicators
- Feature 07:
- Narrow body for in reach ability
- Feature 08:
- Satin chrome finish for durability
- Assembled in US:
- N
- Athol Inventory:
- 65
- Attachments:
- .078" & .156" contact points, 3/8" & 5/32" dovetail clamps, .156" swivel post holder, tool post holder, contact wrench & case
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Description:
- DIAL TEST INDICATOR SET, 0-4-0, 1-1/4" DIAM.
- Flat Stock Inventory:
- 0
- Item Class:
- Stand-Alone
- Max. Range (in):
- 0.008
- Min. Range (in):
- 0
- Mt Airy Inventory :
- 0
- Parent SKU As a Regular Field:
- 3800, 3900
- Product Group Sort:
- icc110501
- Webber Inventory:
- 0
- Website-URL:
- https://www.starrett.com/details?cat-no=3808AC
- Rocky Mountain Inventory:
- 0
- Show in Web Nav?:
- Yes
- To Delete:
- false
- To Remove:
- false
- Total Inventory:
- 65
- US Web Temp Hold:
- Off
- Global Product Classification:
- DIAL TEST INDICATOR SET, 0-4-0, 1-1/4" DIAM.
- Graduations (in):
- .0001"
- Item Segmentation:
- Catalog
- Long Description:
- Each
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/3808AcUSp1.tif
- Manufacturer's code:
- 049659
- NAFTA Producer:
- No
- Name:
- DIAL TEST INDICATOR SET, 0-4-0, 1-1/4" DIAM.
- Item ID:
- 3808AC
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/3808AcUSp1.tif
- Product Photo 02:
- https://s3-us-west-2.amazonaws.com/catsy.833/3808ACcUSp1.tif
- Product Title:
- 3808AC Dial Test Indicator with Dovetail Mount
- Range (in):
- .008"
- Series Title:
- 3808, 3809, 3908, 3909 Dial Test Indicators with Dovetail Mounts
- Short Description:
- Dial Test Indicator with Dovetail, .008" Range, 0-4-0 1-1/4" Dial Face, .0001" Graduations, with Accessories, Case
- Status:
- Active
- Orderable Online Today (US Only):
- Yes
- A002040UCC12UPCA:
- 049659123036
- A002050EANUCC13EAN13:
- 0049659123036
- Style:
- Dovetail Mount (Imported)
- Tariff Code for entry into Mexico:
- No
- Top 354:
- N
- Unit Pack Height (in):
- 1.75
- Unit Pack Invoiced:
- N
- Unit Pack Item Qty:
- 1
- Unit Pack Length (in):
- 6
- Unit Pack Shippable:
- N
- Unit Pack Weight (lbs):
- 0.7
- Unit Pack Width (in):
- 4
- UOM:
- Each
- UPC:
- 049659123036
- Use Placeholder Photo:
- N
- US List Price:
- $316.00
- US Next List Price:
- $316.00
- US Web Price:
- $316.00
- Web Catalog-US-EN:
- Y
- Web Price:
- $316.00
- Web Priority-US-EN:
- 21600535
- Electronic or Mechanical:
- Mechanical
- Starrett Model No.:
- 3808
- Dial Diameter (In):
- 1-1/4"
- Category L1:
- Indicators & Gages
- Category L2:
- Test Indicators
- 01 Attribute :
- Range (in)
- 01 Spec:
- .008"
- 02 Attribute:
- Graduations (in)
- 02 Spec:
- .0001"
- 03 Attribute:
- Dial Reading
- 03 Spec:
- 0-4-0
- 04 Attribute:
- Attachments
- 04 Spec:
- .078" & .156" contact points, 3/8" & 5/32" dovetail clamps, .156" swivel post holder, tool post holder, contact wrench & case
- 05 Attribute:
- Contact Ball Material
- 05 Spec:
- Steel
- 06 Attribute:
- Contact Point Ball Diameter (in)
- 06 Spec:
- .078" (2mm)
- 07 Attribute:
- Contact Point Ball Diameter (mm)
- 07 Spec:
- 2mm (.078")
- 08 Attribute:
- Contact Point Length (in)
- 08 Spec:
- 5/32"
- 09 Attribute:
- Contact Point Length (mm)
- 09 Spec:
- 4mm
- 10 Attribute:
- Style
- 10 Spec:
- Dovetail Mount (Imported)
- 11 Attribute:
- Dial Color
- 11 Spec:
- White
- 12 Attribute:
- Dial Diameter (In)
- 12 Spec:
- 1-1/4"
- Discontinued:
- false
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- Current Catalog Page:
- 140
- Catalog Section Page:
- 8
- Catalog:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- Catalog Section:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-05-Dial-and-Electronic-Indicators-and-Gages.pdf
- SLC Certification:
- Optional Add-On
- Western Link Inventory:
- 0
