The 3831 Digital Rockwell Hardness Tester can be used directly to measure the most popular regular Rockwell hardness scales and it can quickly convert that hardness value into HB, HV, HLD, HK and many other scales. Loaded with many useful features such as ultra precise results, wide measuring range, scale and test force selectable, automatic main test force loading/unloading, high resolution digital display and USB data storage. The 3831 is suitable for testing hardness of carbon steel, alloy steel, cast iron, non-ferrous metals and engineering plastics.
3831 Digital Rockwell Hardness Tester
$8,159.00
- SKU:
- 3831
- UPC:
- 049659020410
- PMRA Regulated:
- N
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/3831e02041cUSp1.tif
- Product Title:
- 3831 Digital Rockwell Hardness Tester
- Promo Item-US-EN:
- N
- Refrigerant Indicator:
- N
- Results Display:
- Digital
- RoHS (EU):
- N
- SDS Indicator:
- N
- Series Title:
- 3800 Hardness Testers
- Shelf Pack Invoiced:
- N
- Shelf Pack Shippable:
- N
- Short Description:
- Digital Rockwell Hardness Tester with Touchscreen
- Status:
- Active
- Allow Testimonial:
- N
- Stocked Locally(Y/N)-US-EN:
- N
- Subject to Environmental Change:
- N
- Temperature Sensitive:
- N
- Top 354:
- N
- Unit Pack Height (in):
- 48
- Unit Pack Invoiced:
- N
- Unit Pack Length (in):
- 40
- Unit Pack Shippable:
- N
- Unit Pack Weight (lbs):
- 250
- Unit Pack Width (in):
- 40
- UOM:
- Each
- UPC:
- 049659020410
- Use Placeholder Photo:
- N
- US List Price:
- $8159.00
- US Web Price:
- $8159.00
- Variable Unit:
- N
- Web Catalog-US-EN:
- Y
- Web Priority-US-EN:
- 41800035
- A0006160MSDSINDICATOR:
- N
- A000670ROHASCOMPLIANT:
- N
- A002040UCC12UPCA:
- 049659020410
- A002050EANUCC13EAN13:
- 0049659020410
- Category:
- Precision Measuring Tools > Hardness Testers > Benchtop Hardness Testers
- Cal Prop 65 Warning:
- N
- Conflict Minerals:
- N
- Contaminated if Opened:
- N
- Country of Origin :
- China
- Datasheet:
- https://s3-us-west-2.amazonaws.com/catsy.833/3831-hardness-tester-bulletin-1832.pdf
- Data Sheet URL-US-EN:
- https://www.starrett.com/vdoc/3831 Hardness Tester (Bulletin 1832)
- EAN:
- 0049659020410
- EDP:
- 02041
- Effective List Date:
- 2022-12-31
- Effective Web Date:
- 2022-07-01
- Exists in Comport:
- N
- Feature 01:
- Dead Weight Test Force Application
- Feature 02:
- Direct digital reading
- Feature 03:
- Engineered to obtain highly sensitive and accurate readings
- Feature 04:
- Perfect for laboratories, workshops, tool rooms, inspection labs, etc.
- Feature 05:
- Measuring Range: 8-650HBW
- Feature 06:
- Includes Certified Test Blocks, HRB 75-95, HRC 25-35, HRC 40-50, HRC 55-65
- Feature 07:
- Key Performance Parameters
- Feature 08:
- Preload - 98.1N - 10kgf
- Feature 09:
- Total test force - 588.4N(60kgf) 980.7N(100kgf) 1471N(150kgf),
- Feature 10:
- Scales: HRB,HRC,HRD,HRE,HRF,HRG,HRH,HRK,HRE,HRL,HRM,HRP,HRR,HRS,HRV
- Feature 11:
- Load dwell duration - 2 - 50s
- Feature 12:
- Resolution - 0.1HR
- Feature 13:
- Display - High definition backlight LCD
- Feature 14:
- Operation - Menu selectable push buttons
- Feature 15:
- Auxiliary functions Upper/lower limits setting & alarm, Scale conversions: HV & HB
- Feature 16:
- Data output: USB memory stick
- Feature 17:
- Testing Capacity - Vertical: 8.00" Throat Depth: 7.87"
- Feature 18:
- Power supply - single phase, AC, 110V, 50 - 60Hz, 4A
- Feature 19:
- Height: 22.04", Width: 8.07" , Depth: 31.49" , Weight: 175lbs (80kg)
- Feature 20:
- Included Accessories: Large Anvil, Small Diameter Anvil, V-shaped Anvil, 120 deg. Diamond Indentor, 1/16" Carbide Ball indentor, Storage Box
- Assembled in US:
- N
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Brochure 3:
- https://s3-us-west-2.amazonaws.com/catsy.833/starrett-hardness-testers-bulletin-592.pdf
- Brochure URL-US-EN:
- https://www.starrett.com/vdoc/Starrett Hardness Testers (Bulletin 592)
- CAN List Price:
- CA$10325.00
- CAN Price List Name:
- 133W - 2021
- Combined Dollar Sales:
- 53224.57
- Combined Unit Sales :
- 11
- Description:
- The 3831 Digital Rockwell Hardness Tester can be used directly to measure the most popular regular Rockwell
- In Sugar Catalog:
- Yes
- Item Class:
- Stand-Alone
- Product Group Sort:
- benchtop_hardness_testers
- Website-URL:
- https://www.starrett.com/details?cat-no=3831
- Show in Web Nav?:
- Yes
- Top Seller:
- Yes
- Total Inventory:
- 0
- Unit Sales 2020:
- 5
- Unit Sales 2021:
- 3
- Unit Sales 2022:
- 3
- US Price List Name:
- 133W - 2021
- US Web Temp Hold:
- Off
- Test Force Application:
- Dead Weight
- Test Force Control:
- Motorized
- Throat Depth:
- 7.8" (198mm)
- Unit Height/Width/Depth:
- 22" (560mm) x 8" (200mm) x 31" (790mm)
- Unit Weight:
- 175lbs Net / 250lbs Shipping
- Hardness Scale:
- Rockwell
- Web Price:
- $8159.00
- Fragile:
- N
- French Language Included:
- N
- Hazmat Indicator:
- N
- ICC:
- 110903 Hardness Testers
- Item Discount Code:
- B
- Item Segmentation:
- Catalog
- Long Description:
- Digital Rockwell Hardness Tester with Touchscreen
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/3831e02041cUSp1.tif
- Major Load:
- 60 Kgf, 100 Kgf, 150 Kgf
- Manufacturer's code:
- 049659
- Marked Recyclable:
- N
- Marked Returnable:
- N
- Master Pack Invoiced:
- N
- Master Pack Shippable:
- N
- Maximum Test Height:
- 8.0" (203mm)
- Minor Load:
- 10 Kgf
- Name:
- Digital Rockwell Hardness Tester with Touchscreen
- Item ID:
- 3831
- Electronic or Mechanical:
- Electronic
- Category L1:
- Handheld Testing Equip
- Category L2:
- Hardness Testers
- Sales Category:
- TOOLS.TOOLS (ELECTRONIC & NON-DISCOUNTABLE).
- Athol Inventory:
- 0
- Flat Stock Inventory:
- 0
- Mt Airy Inventory :
- 0
- Rocky Mountain Inventory:
- 0
- US Next List Price:
- $8159.00
- IBC Category 1:
- Testing, Measuring and Inspection
- IBC Category 2:
- Hardness Testing Equipment
- IBC Category 3:
- Bench Top Hardness Testers
- User Manual URL-US-EN:
- https://www.starrett.com/UM-3831
- To Delete:
- false
- To Remove:
- false
- Dollar Sales 2023:
- $22808.14
- Unit Sales 2023:
- 4
- Webber Inventory:
- 0
- Minimum Order Quantity:
- 0
- Discontinued:
- false
- 01 Attribute :
- Major Load
- 01 Spec:
- 60 Kgf, 100 Kgf, 150 Kgf
- 02 Attribute:
- Maximum Test Height
- 02 Spec:
- 8.0" (203mm)
- 03 Attribute:
- Minor Load
- 03 Spec:
- 10 Kgf
- 04 Attribute:
- Results Display
- 04 Spec:
- Digital
- 05 Attribute:
- Test Force Application
- 05 Spec:
- Dead Weight
- 06 Attribute:
- Test Force Control
- 06 Spec:
- Motorized
- 07 Attribute:
- Throat Depth
- 07 Spec:
- 7.8" (198mm)
- 08 Attribute:
- Unit Height/Width/Depth
- 08 Spec:
- 22" (560mm) x 8" (200mm) x 31" (790mm)
- 09 Attribute:
- Unit Weight
- 09 Spec:
- 175lbs Net / 250lbs Shipping
- 10 Attribute:
- Hardness Scale
- 10 Spec:
- Rockwell
