575AP Screw Thread Micrometer

575AP Screw Thread Micrometer

$447.00
(No reviews yet) Write a Review
SKU:
575AP
UPC:
049659561593
Category:
Precision Measuring Tools > Precision Hand Tools > Micrometers > Screw Thread
Cal Prop 65 Chemical:
Lead
Accessory:
3206
Athol Inventory:
0
Available for Purchase-US-EN:
Y
Flat Stock Inventory:
0
Item Class:
Stand-Alone
Parent SKU As a Regular Field:
575
Product Group Sort:
screw_thread
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=575AP
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Global Product Classification:
SCREW THREAD MICROMETER, 0-1", 7-9 TPI
Item Segmentation:
Catalog
Long Description:
Each
Made in America:
Yes
Manufacturer's code:
049659
NAFTA Producer:
Yes
Item ID:
575AP
POA Flag:
N
Shelf Pack Item Qty:
1
Shelf Pack Pricing Quantity:
1
A0006160MSDSINDICATOR:
N
A002040UCC12UPCA:
049659561593
A002050EANUCC13EAN13:
0049659561593
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (mm):
25.4
Unit Pack Length (mm):
134.62
Unit Pack Weight (kg):
0.1814368
Unit Pack Width (mm):
60.96
UOM:
Each
Use Placeholder Photo:
N
US Web Price:
$447.00
Web Catalog-US-EN:
Y
Web Price:
$447.00
Starrett Model No.:
575
Discontinued:
false
Current Catalog:
33
Current Catalog Page:
58
Catalog Section Page:
40
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-01-Micrometers.pdf
Western Link Inventory:
0
Category L1:
Micrometers
Category L2:
Screw Thread Micrometers
US Promo Price:
$0.00
01 Attribute:
Micrometer Type
COO Detail:
Made in the USA with US and Global Content
Schedule B Number:
9017.30.4000
Product made to order status:
MTO
Available In Region:
United States|Canada
Mt Airy Inventory:
0
Country of Origin:
United States
01 Spec:
Mechanical Screw Thread Micrometer
02 Attribute:
Electronic or Mechanical
02 Spec:
Mechanical
03 Attribute:
Range (in)
03 Spec:
0-1"
04 Attribute:
Graduations (in)
04 Spec:
.001"
05 Attribute:
Thimble Graduations
05 Spec:
English
06 Attribute:
Case Type
06 Spec:
None
07 Attribute:
Anvil/Spindle Material
07 Spec:
Steel
08 Attribute:
Anvil Type
08 Spec:
Double V-anvil
09 Attribute:
Spindle Type
09 Spec:
Pointed
10 Attribute:
Threads per Inch
10 Spec:
7-9
11 Attribute:
Spindle Material
11 Spec:
Steel
12 Attribute:
Micrometer Application
12 Spec:
Screw Thread Measurement
Anvil Type:
Double V-anvil
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Catalog:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
EAN:
0049659561593
EDP:
56159
Electronic or Mechanical:
Mechanical
Feature 01:
No glare Starrett satin chrome finish
Feature 02:
Advanced sleeve design with staggered lines and distinct figures for precise, easy readability
Feature 03:
Balanced frame design for comfortable, accurate measuring
Feature 04:
Tapered frame for narrow slots and tight places
Feature 05:
Furnished with fixed, non-rotating anvil
Feature 06:
One-piece frame of drop forged steel
Feature 07:
Extremely hard and stable one-piece spindle
Feature 08:
Quick and easy adjustment
Feature 09:
Design allows 50% to 75% contact with the thread to be measured, insuring contact with the pitch diameter at all times
Feature 10:
For measuring American Unified National series and Unified J series screw threads
Feature 11:
Series 585 micrometers come with a one-inch standard at no extra cost
Feature 12:
Decimal equivalents on inch tool
Graduations (in):
.001"
Micrometer Type:
Mechanical Screw Thread Micrometer
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/575APcUSp1.tif
Product Photo 02:
https://s3.us-west-2.amazonaws.com/catsy.833/575APc56159cUSa1.tif
Product Title:
575AP Screw Thread Micrometer
Product Type:
Micrometer
Range (in):
0-1"
Short Description:
Screw Thread Micrometer, Double V-Anvil, 0-1" Range
Thimble Graduations:
English
Threads per Inch:
7-9
Unit Pack Height (in):
0.9
Unit Pack Item Qty:
1
Unit Pack Length (in):
5.1
Unit Pack Width (in):
2.8
US List Price:
$447.00
Web Priority-US-EN:
18200020
Unit Pack Weight (lbs):
0.45
SDS Indicator:
N
Series Title:
575,575M Screw Thread Micrometers for Measuring Pitch Diameter
Status:
Active
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Cal Prop 65 Warning:
Y
Case Type:
None
Max. Range (in):
1
Min. Range (in):
0
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/575APcUSp1.tif
Micrometer Application:
Screw Thread Measurement
Spindle Material:
Steel
Spindle Type:
Pointed
Anvil/Spindle Material:
Steel
The Starrett 575 micrometers have a pointed spindle and a double V-anvil, both shaped to contact the screw thread. The micrometer reading therefore gives the pitch diameter. 0-1" Range, .001" Grad, 7-9 TPI.
