The Starrett 653 Individual Component is a bench-type comparator gage that is ruggedly built for in-process and final inspection work. The dial indicator can be adjusted vertically and locked in any position. A sliding ring with locking screw below the beam permits swinging the indicator to either side. The ring also acts as a safety device, preventing the beam from accidentally dropping. There is a fine adjustment on the beam for final indicator setting. The hand lifting lever on the indicator raises the spindle and releases it to contact the work. Left hand lever furnished unless otherwise specified. Maximum vertical capacity is 9-1/4" (235mm). Throat depth is 5" (125mm). Vertical indicator fine adjustment of up to 1/2" (12.7mm). Post diameter is 1-1/2". 653G Series have a Starrett Grade A, Crystal Pink Granite base, measuring 8" x 12" x 2" (200 x 300 x 50mm). Base is finished to an overall tolerance of .0001" (0.0025mm). Comparator with Granite Base, without Indicator.
653G Granite Comparator Stand without Indicator
$1,160.00
- SKU:
- 653G
- UPC:
- 049659566468
- Category:
- Precision Measuring Tools > Precision Hand Tools > Indicators & Gages > Holders
- Cal Prop 65 Chemical:
- Lead
- Athol Inventory:
- 10
- Available for Purchase-US-EN:
- Y
- Flat Stock Inventory:
- 0
- Item Class:
- Stand-Alone
- Product Group Sort:
- icc110506
- Webber Inventory:
- 0
- Website-URL:
- https://www.starrett.com/details?cat-no=653G
- Rocky Mountain Inventory:
- 0
- Show in Web Nav?:
- Yes
- To Delete:
- false
- To Remove:
- false
- Total Inventory:
- 10
- US Web Temp Hold:
- Off
- Global Product Classification:
- GRANITE COMPARATOR STAND W/O INDICATOR
- Item Segmentation:
- Catalog
- Long Description:
- Each
- Made in America:
- Yes
- Manufacturer's code:
- 049659
- NAFTA Producer:
- Yes
- Item ID:
- 653G
- Type:
- Granite Base Stand
- POA Flag:
- N
- Shelf Pack Item Qty:
- 1
- Shelf Pack Pricing Quantity:
- 1
- A002040UCC12UPCA:
- 049659566468
- A002050EANUCC13EAN13:
- 0049659566468
- Tariff Code for entry into Mexico:
- Yes
- Top 354:
- N
- Unit Pack Height (mm):
- 414.02
- Unit Pack Length (mm):
- 368.3
- Unit Pack Weight (kg):
- 14.061352
- Unit Pack Width (mm):
- 254
- UOM:
- Each
- Use Placeholder Photo:
- N
- US Web Price:
- $1160.00
- Web Catalog-US-EN:
- Y
- Web Price:
- $1160.00
- Discontinued:
- false
- Current Catalog Page:
- 184
- Catalog Section Page:
- 52
- Catalog Section:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-05-Dial-and-Electronic-Indicators-and-Gages.pdf
- Western Link Inventory:
- 0
- Category L1:
- Indicators & Gages
- Category L2:
- Holders
- Current Catalog:
- 33
- US Promo Price:
- $0.00
- 01 Attribute:
- Type
- COO Detail:
- Made in the USA with US and Global Content
- Schedule B Number:
- 9017.30.8000
- Product made to order status:
- MTO
- Available In Region:
- United States|Canada
- Mt Airy Inventory:
- 0
- Country of Origin:
- United States
- Dimensional Drawing PDF:
- https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-653G-Dimensional-Drawing.pdf
- Dimensional Drawing (IMG):
- https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-653G-Dimensional-Drawing.tif
- 01 Spec:
- Granite Base Stand
- Cal Prop 65 Statement:
- WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
- Catalog:
- https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- EAN:
- 0049659566468
- EDP:
- 56646
- Electronic or Mechanical:
- Mechanical
- Feature 01:
- Ruggedly built for in-process and final inspection work
- Feature 02:
- Can be adjusted vertically and locked in any position
- Feature 03:
- A sliding ring with locking screw below the beam permits swinging the indicator to either side
- Feature 04:
- Ring also acts as a safety device, preventing the beam from accidentally dropping
- Feature 05:
- Includes a fine adjustment on the beam for final indicator setting
- Feature 06:
- Comparator with granite base, without indicator
- Orderable Online Today (US Only):
- Yes
- Product Photo 01:
- https://s3.us-west-2.amazonaws.com/catsy.833/653GcUSp2.tif
- Product Photo 02:
- https://s3.us-west-2.amazonaws.com/catsy.833/653GJcUSp2.tif
- Product Photo 03:
- https://s3.us-west-2.amazonaws.com/catsy.833/653GJcUSa1.tif
- Product Title:
- 653G Granite Comparator Stand without Indicator
- Product Type:
- Comparator Stand
- Short Description:
- Comparator Stand with Granite Base, Grade A, Crystal Pink Granite base, 8" x 12" x 2" (200 x 300 x 50mm)
- Unit Pack Height (in):
- 16.3
- Unit Pack Item Qty:
- 1
- Unit Pack Length (in):
- 14.5
- Unit Pack Width (in):
- 10
- US List Price:
- $1160.00
- Web Priority-US-EN:
- 23600005
- YouTube Video Code 01-US-EN:
- G4GRAWjq5tc
- Unit Pack Weight (lbs):
- 31
- Series Title:
- 653, 653M Dial Comparator Stands
- Status:
- Active
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
- Cal Prop 65 Warning:
- Y
- Main Image:
- https://s3.us-west-2.amazonaws.com/catsy.833/653GcUSp2.tif
- 02 Attribute:
- Base Size (in)
- 02 Spec:
- 8" x 12" x 2"
- 03 Attribute:
- Base Size (mm)
- 03 Spec:
- 200 x 300 x 50mm
- 04 Attribute:
- Capacity (in)
- 04 Spec:
- 9-1/4" Vertical
- 05 Attribute:
- Capacity (mm)
- 05 Spec:
- 235mm Vertical
- 06 Attribute:
- Throat Depth (in)
- 06 Spec:
- 5"
- 07 Attribute:
- Throat Depth (mm)
- 07 Spec:
- 125mm
- Base Size (in):
- 8" x 12" x 2"
- base_size_mm:
- 200 x 300 x 50mm
- Capacity (in):
- 9-1/4" Vertical
- Capacity (mm):
- 235mm Vertical
- Related:
- 653|3671|3672|3673
- Throat Depth (in):
- 5"
- Throat Depth (mm):
- 125mm
- Up-Sell:
- 653GJ
