714.1MEAAFLZ Electronic Interchangeable Anvil Micrometer

714.1MEAAFLZ Electronic Interchangeable Anvil Micrometer

$943.00
(No reviews yet) Write a Review
SKU:
714.1MEAAFLZ
UPC:
049659728019
Case Type:
Wood case
Category:
Discontinued
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Conflict Minerals:
N
Contaminated if Opened:
N
Country of Origin :
United States
EAN:
0049659728019
EDP:
72801
Effective List Date:
2022-12-31
Effective Web Date:
2022-07-01
Exists in Comport:
N
Superseded By:
714.1AAFLZ
Feature 01:
Starrett no-glare satin chrome finish on thimble and sleeve
Feature 02:
Large, easy-to-read .275 (7mm) high contrast LCD digital readout
Feature 03:
Extremely hard and stable one-piece spindle
Feature 04:
Auto Off after 20 minutes of nonuse
Feature 05:
Inch/millimeter conversion on English versions
Feature 06:
Smooth friction thimble for uniform pressure
Feature 07:
Measurement HOLD button
Feature 08:
Zero at any position
Feature 09:
Retain and return to true zero reading
Feature 10:
Spindle lock
Feature 11:
Data Output
Feature 12:
Resolution: .00005" (0.001mm)
Feature 13:
Accuracy +/-.0001 (+/-.002mm)
Feature 14:
PRESET button to install any reading at any position
Feature 15:
Ability to install minimum and maximum limits
Assembled in US:
N
Athol Inventory:
4
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada
Brochure:
https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
Brochure URL-US-EN:
https://www.starrett.com/vdoc/Starrett Electronic Precision Hand Tools (Bulletin 590)
CAN List Price:
CA$1195.00
CAN Price List Name:
133W - 2021
CAN Web Price:
CA$992.01
Combined Dollar Sales:
599.50
Combined Unit Sales :
2
Description:
The Starrett 714.1 Series Electronic Interchangeable Anvil Micrometer with Standard Inch Graduations
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Max. Range (in):
3.93
Max. Range (mm):
100
Min. Range (in):
0
Min. Range (mm):
0
Mt Airy Inventory :
0
Product Group Sort:
discontinued
Website-URL:
https://www.starrett.com/metrology/product-detail/714.1MEAAFLZ
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
4
Unit Sales 2020:
1
Unit Sales 2021:
1
Unit Sales 2022:
0
US Price List Name:
133W - 2021
US Web Temp Hold:
Off
Fragile:
N
French Language Included:
N
Hazmat Indicator:
N
ICC:
110109 Special Fuction Microme
Item Segmentation:
Catalog
Lock Nut Type:
Knurled Ring Type
Long Description:
ECO-19808
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/714.1MEAAFLZe72801cUSp1.tif
Manufacturer's code:
049659
Marked Recyclable:
N
Marked Returnable:
N
Master Pack Invoiced:
N
Master Pack Shippable:
N
Micrometer Type:
Electronic Interchangeable Anvil Outside Micrometer
Name:
MICROMETER, ELECTRONIC
Next Catalog:
No
Item ID:
714.1MEAAFLZ
Placeholder Photo:
https://s3-us-west-2.amazonaws.com/catsy.833/714.1AAFLZe72788cUsp1.tif
PMRA Regulated:
N
Product made to order status:
MTO
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/714.1MEAAFLZe72801cUSp1.tif
Product Photo 02:
https://s3-us-west-2.amazonaws.com/catsy.833/714.1MEAAFLZe72801cUSz1.tif
Product Title:
714.1MEAAFLZ Electronic Interchangeable Anvil Micrometer
Range (in):
0 - 3.930"
Range (mm):
0-100mm
Refrigerant Indicator:
N
Resolution (in):
.0001
Resolution (mm):
0.001mm
RoHS (EU):
N
SDS Indicator:
N
Series Title:
714.1 Electronic Digital Interchangeable Anvil Micrometers
Shelf Pack Invoiced:
N
Shelf Pack Shippable:
N
Short Description:
Digital Interchangeable Anvil Micrometer, Friction Thimble, SPC Output, 0.001mm, 0-100mm Range
SPC Output:
Yes
Spindle Type:
Flat
Status:
GOING DISC
A0006160MSDSINDICATOR:
N
A000670ROHASCOMPLIANT:
N
A002050EANUCC13EAN13:
0049659728019
Accuracy (in):
+/-.0001"
Accuracy (mm):
+/-.003mm
Anvil Type:
Flat
Anvil/Spindle Material:
Steel
Subject to Environmental Change:
N
Temperature Sensitive:
N
Thimble Graduations:
Metric
Thimble Type:
Friction
Top 354:
N
Unit Pack Height (in):
1.4
Unit Pack Invoiced:
N
Unit Pack Length (in):
11.3
Unit Pack Shippable:
N
Unit Pack Weight (lbs):
2.8
Unit Pack Width (in):
5.3
UOM:
Each
UPC:
049659728019
Use Placeholder Photo:
N
User Manual URL-US-EN:
https://www.starrett.com/um-733.1
US List Price:
$943.00
US Next List Price:
$943.00
US Web Price:
$943.00
Variable Unit:
N
Web Catalog-US-EN:
Y
Web Price:
$943.00
Web Priority-US-EN:
2070
Category L1:
Micrometers
Category L2:
Interchangeable Anvil Micrometers
Sales Category:
TOOLS.HARDWARE TOOLS (NON-DISCOUNTABLE).
Dimensional Drawing PDF:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-714.1MEAAFLZ-Dimensional-Drawing.pdf
Dimensional Drawing (IMG):
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-714.1MEAAFLZ-Dimensional-Drawing.tif
Webber Inventory:
0
Minimum Order Quantity:
0
SDS Sheet:
https://s3-us-west-2.amazonaws.com/catsy.833/SDS-Renata-CR2032-ASDS.pdf
Orderable Online Today (US Only):
Yes
Discontinued:
false
Adding to cart… The item has been added
The Starrett 714.1 Series Electronic Interchangeable Anvil Micrometer with Standard Inch Graduations on Shell and Thimble features a 0-100mm and 0-3.930" measuring range, and 0.001mm resolution. 0-100mm Range, 0.001mm Res., Friction Thimble, Lock Nut.
