714.1MEDFLZ Electronic Interchangeable Anvil Micrometer

714.1MEDFLZ Electronic Interchangeable Anvil Micrometer

$1,454.00
(No reviews yet) Write a Review
SKU:
714.1MEDFLZ
UPC:
049659728033
Discontinued:
false
A0006160MSDSINDICATOR:
N
A000670ROHASCOMPLIANT:
N
A002040UCC12UPCA:
049659728033
A002050EANUCC13EAN13:
0049659728033
Available for Purchase-US-EN:
N
Category:
Discontinued
Category L1:
Micrometers
Category L2:
Special Fuction Micrometers
Item Segmentation:
Catalog
Item ID:
714.1MEDFLZ
PMRA Regulated:
N
Show in Web Nav?:
Yes
Superseded By:
714.1DFLZ
UOM:
Each
US Promo Price:
$0.00
US Web Price:
$1454.00
Web Catalog-US-EN:
Y
Whitepaper 1:
https://s3-us-west-2.amazonaws.com/catsy.833/Data-Collection-in-Manufacturing.pdf
COO Detail:
Made in the USA with US and Global Content
Global Product Classification:
MICROMETER, ELECTRONIC
Hazmat Indicator:
N
Manufacturer's code:
049659
Output:
Cabled Only
Assembled in US:
N
Athol Inventory:
0
Available In Region:
United States|Canada
Battery Type:
CR2032 lithium Battery (Qty 2), Included
Cal Prop 65 Chemical:
Lead
Conflict Minerals:
N
Contaminated if Opened:
N
Exists in Comport:
N
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Mt Airy Inventory:
0
Product Group Sort:
discontinued
Rocky Mountain Inventory:
0
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Webber Inventory:
0
Website-URL:
https://www.starrett.com/metrology/product-detail/714.1MEDFLZ
Western Link Inventory:
0
Fragile:
N
French Language Included:
N
Long Description:
ECO-19808
Made in America:
Yes
Marked Recyclable:
N
Next Catalog:
No
Product made to order status:
MTO
Refrigerant Indicator:
N
Schedule B Number:
9017.30.4000
Shelf Pack Invoiced:
N
Shelf Pack Shippable:
N
Sales Category:
TOOLS.HARDWARE TOOLS (NON-DISCOUNTABLE).
Subject to Environmental Change:
N
Temperature Sensitive:
N
Top 354:
N
Unit Pack Invoiced:
N
Unit Pack Shippable:
N
Use Placeholder Photo:
Y
Variable Unit:
N
Web Price:
$1454.00
Country of Origin:
United States
Dimensional Drawing PDF:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-714.1MEDFLZ-Dimensional-Drawing.pdf
Dimensional Drawing (IMG):
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-714.1MEDFLZ-Dimensional-Drawing.tif
Accuracy (in):
+/-.00035"
Accuracy (mm):
+/-.008mm
Anvil Type:
Flat
Brochure 1:
https://s3.us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Case Study:
https://s3.us-west-2.amazonaws.com/catsy.833/Data-Collection-at-Roush-Yates.pdf
EAN:
0049659728033
EDP:
72803
Feature 01:
Starrett no-glare satin chrome finish on thimble and sleeve
Feature 02:
Large, easy-to-read .275 (7mm) high contrast LCD digital readout
Feature 03:
Extremely hard and stable one-piece spindle
Feature 04:
Auto Off after 20 minutes of nonuse
Feature 05:
Inch/millimeter conversion on English versions
Feature 06:
Smooth friction thimble for uniform pressure
Feature 07:
Measurement HOLD button
Feature 08:
Zero at any position
Feature 09:
Retain and return to true zero reading
Feature 10:
Spindle lock
Feature 11:
Data Output
Feature 12:
Resolution: .00005" (0.001mm)
Feature 13:
Accuracy +/-.0001 (+/-.002mm)
Feature 14:
PRESET button to install any reading at any position
Feature 15:
Ability to install minimum and maximum limits
Lock Nut Type:
Knurled Ring Type
Micrometer Type:
Electronic Interchangeable Anvil Outside Micrometer
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/Missing-Image-Sign.tif
Product Title:
714.1MEDFLZ Electronic Interchangeable Anvil Micrometer
Range (in):
5.900 - 11.810"
Range (mm):
150-300mm
SDS Sheet:
https://s3.us-west-2.amazonaws.com/catsy.833/SDS-Renata-CR2032-ASDS.pdf
Short Description:
Digital Interchangeable Anvil Micrometer, Friction Thimble, SPC Output, 0.001mm, 150-300mm Range
SLC Certification:
Optional Add-On
Thimble Graduations:
Metric
Thimble Type:
Friction
Unit Pack Height (in):
25.8
Unit Pack Length (in):
16.5
Unit Pack Width (in):
3.5
US List Price:
$1454.00
Web Priority-US-EN:
99999999
Unit Pack Weight (lbs):
14
User Manual URL-US-EN:
https://www.starrett.com/UM-733.1
RoHS (EU):
N
SDS Indicator:
N
Series Title:
714.1 Electronic Digital Interchangeable Anvil Micrometers
Status:
GOING DISC
Brochure URL-US-EN:
https://www.starrett.com/vdoc/Starrett Electronic Precision Hand Tools (Bulletin 590)
Cal Prop 65 Warning:
Y
Case Type:
Wood case
Max. Range (in):
11.81
Max. Range (mm):
300
Min. Range (in):
5.9
Min. Range (mm):
150
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/Missing-Image-Sign.tif
Spindle Type:
Flat
Anvil/Spindle Material:
Steel
The Starrett 714.1 Series Electronic Interchangeable Anvil Micrometer with Standard Inch Graduations on Shell and Thimble features a 300-400mm and 11.810-15.740" measuring range, and 0.001mm resolution. 300-400mm Range, 0.001mm Res., Friction Thimble, Lock Nut. [Discontinued 10/2022]
