The Starrett 714.1 Series Electronic Interchangeable Anvil Micrometer with Standard Inch Graduations on Shell and Thimble features a 500-600mm and 19.680-23.620" measuring range, and 0.01mm resolution. 500-600mm Range, .0.001mm Res., Friction Thimble, Lock Nut.
714.1MEJFLZ Electronic Interchangeable Anvil Micrometer
$1,684.00
- SKU:
- 714.1MEJFLZ
- UPC:
- 049659728071
- Country of Origin :
- United States
- EAN:
- 0049659728071
- EDP:
- 72807
- Effective List Date:
- 2022-12-31
- Effective Web Date:
- 2022-07-01
- Exists in Comport:
- N
- Superseded By:
- 714.1JFLZ
- Feature 01:
- Starrett no-glare satin chrome finish on thimble and sleeve
- Feature 02:
- Large, easy-to-read .275 (7mm) high contrast LCD digital readout
- Feature 03:
- Extremely hard and stable one-piece spindle
- Feature 04:
- Auto Off after 20 minutes of nonuse
- Feature 05:
- Inch/millimeter conversion on English versions
- Feature 06:
- Smooth friction thimble for uniform pressure
- Feature 07:
- Measurement HOLD button
- Feature 08:
- Zero at any position
- Feature 09:
- Retain and return to true zero reading
- Feature 10:
- Spindle lock
- Feature 11:
- Data Output
- Feature 12:
- Resolution: .00005" (0.001mm)
- Feature 13:
- Accuracy +/-.0001 (+/-.002mm)
- Feature 14:
- PRESET button to install any reading at any position
- Feature 15:
- Ability to install minimum and maximum limits
- Description:
- The Starrett 714.1 Series Electronic Interchangeable Anvil Micrometer with Standard Inch Graduations
- Flat Stock Inventory:
- 0
- In Sugar Catalog:
- Yes
- Item Class:
- Stand-Alone
- Max. Range (in):
- 23.62
- Max. Range (mm):
- 600
- Min. Range (in):
- 19.68
- Min. Range (mm):
- 500
- Mt Airy Inventory :
- 0
- Website-URL:
- https://www.starrett.com/metrology/product-detail/714.1MEJFLZ
- Rocky Mountain Inventory:
- 0
- Show in Web Nav?:
- Yes
- To Delete:
- false
- To Remove:
- false
- Total Inventory:
- 3
- Unit Sales 2020:
- 1
- Unit Sales 2021:
- 2
- Unit Sales 2022:
- 0
- US Price List Name:
- 133W - 2021
- US Web Temp Hold:
- Off
- Fragile:
- N
- French Language Included:
- N
- Hazmat Indicator:
- N
- ICC:
- 110109 Special Fuction Microme
- Item Segmentation:
- Catalog
- Lock Nut Type:
- Knurled Ring Type
- Long Description:
- ECO-19808
- Made in America:
- Yes
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/714MEJFLZcUSp1.tif
- Manufacturer's code:
- 049659
- Marked Recyclable:
- N
- Marked Returnable:
- N
- Master Pack Invoiced:
- N
- Master Pack Shippable:
- N
- Micrometer Type:
- Electronic Interchangeable Anvil Outside Micrometer
- Name:
- MICROMETER, ELECTRONIC
- Next Catalog:
- No
- Item ID:
- 714.1MEJFLZ
- Other Document 1 URL-US-EN:
- https://www.starrett.com/vdoc/Starrett DataSure 4.0 (Bulletin 591)
- Other Document 2 URL-US-EN:
- https://www.starrett.com/vdoc/DataSure 4.0 Whitepaper
- Other Document 3 URL-US-EN:
- https://www.starrett.com/vdoc/DS 4.0 at Roush Yates Engines
- Placeholder Photo:
- https://s3-us-west-2.amazonaws.com/catsy.833/714.1AAFLZe72788cUsp1.tif
- PMRA Regulated:
- N
- Product made to order status:
- MTO
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/714MEJFLZcUSp1.tif
- Product Photo 02:
- https://s3-us-west-2.amazonaws.com/catsy.833/714.1AAFLZe72788cUSa1.tif
- Product Title:
- 714.1MEJFLZ Electronic Interchangeable Anvil Micrometer
- Range (in):
- 19.680 - 23.620"
- Range (mm):
- 500-600mm
- Refrigerant Indicator:
- N
- Resolution (in):
- .0001
- Resolution (mm):
- 0.001mm
- RoHS (EU):
- N
- SDS Indicator:
- N
- Series Title:
- 714.1 Electronic Digital Interchangeable Anvil Micrometers
- Shelf Pack Invoiced:
- N
- Shelf Pack Shippable:
- N
- Short Description:
- Digital Interchangeable Anvil Micrometer, Friction Thimble, SPC Output, 0.001mm, 500-600mm Range
- SPC Output:
- Yes
- Spindle Type:
- Flat
- Status:
- GOING DISC
- Subject to Environmental Change:
- N
- Temperature Sensitive:
- N
- Thimble Graduations:
- Metric
- Thimble Type:
- Friction
- Top 354:
- N
- Unit Pack Height (in):
- 34
- Unit Pack Invoiced:
- N
- Unit Pack Length (in):
- 21
- Unit Pack Shippable:
- N
- Unit Pack Weight (lbs):
- 23
- Unit Pack Width (in):
- 3.4
- UOM:
- Each
- UPC:
- 049659728071
- Use Placeholder Photo:
- Y
- User Manual URL-US-EN:
- https://www.starrett.com/um-733.1
- US List Price:
- $1684.00
- US Next List Price:
- $1684.00
- US Web Price:
- $1684.00
- Variable Unit:
- N
- Web Catalog-US-EN:
- Y
- Web Price:
- $1684.00
- Web Priority-US-EN:
- 2020
- Whitepaper 1 :
- https://s3-us-west-2.amazonaws.com/catsy.833/DataSure+4.pdf
- Sales Category:
- TOOLS.HARDWARE TOOLS (NON-DISCOUNTABLE).
- Dimensional Drawing PDF:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-714.1MEJFLZ-Dimensional-Drawing.pdf
- Dimensional Drawing (IMG):
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-714.1MEJFLZ-Dimensional-Drawing.tif
- Webber Inventory:
- 0
- Minimum Order Quantity:
- 0
- SDS Sheet:
- https://s3-us-west-2.amazonaws.com/catsy.833/SDS-Renata-CR2032-ASDS.pdf
- Discontinued:
- false
- Case Study:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Datasure+4.pdf
- Case Type:
- Wood case
- Category:
- Discontinued
- Cal Prop 65 Chemical:
- Lead
- Cal Prop 65 Warning:
- Y
- Cal Prop 65 Statement:
- WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
- Conflict Minerals:
- N
- Contaminated if Opened:
- N
- Athol Inventory:
- 3
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Brochure:
- https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
- Brochure URL-US-EN:
- https://www.starrett.com/vdoc/Starrett Electronic Precision Hand Tools (Bulletin 590)
- CAN List Price:
- CA$2133.00
- CAN Price List Name:
- 133W - 2021
- Combined Dollar Sales:
- 2117.97
- Combined Unit Sales :
- 3
- Product Group Sort:
- discontinued
- A0006160MSDSINDICATOR:
- N
- Orderable Online Today (US Only):
- Yes
- A000670ROHASCOMPLIANT:
- N
- A002050EANUCC13EAN13:
- 0049659728071
- Accuracy (in):
- +/-.00035"
- Accuracy (mm):
- +/-.008mm
- Anvil Type:
- Flat
- Anvil/Spindle Material:
- Steel
- Category L1:
- Micrometers
- Category L2:
- Interchangeable Anvil Micrometers
