776D Gage-Chek Multi-Axis, Measured Value Display

(No reviews yet) Write a Review

Write a Review

Close ×

776D Gage-Chek Multi-Axis, Measured Value Display

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name Required

Email Required

Review Subject Required

Comments Required

SKU:

776D

UPC:

049659687620

Catalog URL-US-EN:

https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf

Category:

Precision Measuring Tools > Gage Amplifiers

Current Catalog:

33

Current Catalog Page:

235

EAN:

0049659687620

EDP:

68762

Accessory:

719|PT99530|PT62514|PT62515|776-12|776-12R|776-30|719|PT05713|PT05727|776-1Z|776-2Z|776-7|776-8|776-9|PT05414|PT05415|715-1Z|715-2Z|715-6|715-7|715-8|715-9

Feature 01:

Large (6") color flat-panel LCD screen built into a compact ergonomically designed case with an adjustable tilt base

Feature 02:

Supports 4 input channels. These can be mathematically combined to display dimensions such as flatness, volume or runout

Feature 03:

Screens include individual readings with the capacity to display four lines simultaneously, bar and dial position style displays, graphs and SPC data

Feature 04:

Supports Starrett 776 Series LVTD probes

Feature 05:

Measurements can be taken by the operator or in a semi-automated manner

Feature 06:

Large comfortable buttons allow easy selection of measurement functions, display screen changes, data entry, and zeroing the screen

Feature 07:

Speaker and external jack outputs can be adjusted to compensate for noisy work environments.

Feature 08:

Earphones can be plugged into speaker jack for silent operation

Feature 09:

Two 3" x 1/2" keys placed over the screen can be programmed as hot keys for frequently used functions

Feature 10:

Optional foot switch available

Feature 11:

Display Digit Size: .45"

Feature 12:

Enclosure (WxHxD): 11.5"x7.5"x2.75"

Feature 13:

Base Width (WxHxD): 10"x2"x .5"

Feature 14:

Enclosure Weight: 3.5 lbs.

Feature 15:

Base Weight: 7 lbs.

Feature 16:

External Connections: Foot switch,

Feature 17:

Remote Keypad, Touch Probe,

Feature 18:

RS-232C Serial Port, Parallel Port

Feature 19:

Outputs: 2 Relay Outputs

Athol Inventory:

10

Available for Purchase-US-EN:

Y

Flat Stock Inventory:

0

Item Class:

Stand-Alone

Product Group Sort:

icc110901

Webber Inventory:

0

Website-URL:

https://www.starrett.com/details?cat-no=776D

Rocky Mountain Inventory:

0

Show in Web Nav?:

Yes

To Delete:

false

To Remove:

false

Total Inventory:

10

US Web Temp Hold:

Off

Global Product Classification:

GAGE CHEK, 140-ST

Item Segmentation:

Catalog

Long Description:

Each

Made in America:

Yes

Main Image:

https://s3.us-west-2.amazonaws.com/catsy.833/776cUSp2.tif

Manufacturer's code:

049659

NAFTA Producer:

Yes

Item ID:

776D

Product Photo 01:

https://s3.us-west-2.amazonaws.com/catsy.833/776cUSp2.tif

Product Photo 02:

https://s3.us-west-2.amazonaws.com/catsy.833/776DcUSp2.tif

Product Title:

776D Gage-Chek Multi-Axis, Measured Value Display

Series Title:

776 Gage-Chek and Accessories

Short Description:

Gage-Chek Multi-Axis, Measured Value Display

Status:

DISC

A002040UCC12UPCA:

049659687620

A002050EANUCC13EAN13:

0049659687620

Tariff Code for entry into Mexico:

Yes

Top 354:

N

Unit Pack Height (in):

9.3

Unit Pack Height (mm):

198.12

Unit Pack Item Qty:

1

Unit Pack Length (in):

14.2

Unit Pack Length (mm):

447.04

Unit Pack Weight (kg):

6.7131616

Unit Pack Weight (lbs):

14.2

Unit Pack Width (in):

13.3

Unit Pack Width (mm):

312.42

UOM:

Each

Use Placeholder Photo:

Y

US List Price:

$5756.00

US Web Price:

$5756.00

Web Catalog-US-EN:

Y

Web Price:

$5756.00

Web Priority-US-EN:

44001045

Component Type:

Gage Amplifier

Electronic or Mechanical:

Electronic

Starrett Model No.:

776

Input Type:

LVDT

Number of Inputs:

4

Discontinued:

false

Catalog Section Page:

5

Catalog:

https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf

Catalog Section:

https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-09-Gage-Amps-Hardness-and-Surface-Testers.pdf

Western Link Inventory:

0

Display Type:

6" Color LCD, .45" digit size

Operating Temperature:

32º - 115 °F

Type:

Gage Amplifier

Weight (lbs):

Enclosure: 3.5 lb; Base: 7 lb

Size (In):

11.5 x 7.5 x 2.75" (Enclosure)

01 Spec:

776

02 Attribute:

Type

02 Spec:

Gage Amplifier

03 Attribute:

Input Type

03 Spec:

LVDT

04 Attribute:

Number of Inputs

04 Spec:

4

05 Attribute:

Display Type

05 Spec:

6" Color LCD, .45" digit size

06 Attribute:

Output

06 Spec:

2 Relay Outputs

07 Attribute:

Input Frequency

07 Spec:

43 Hz - 63 Hz

08 Attribute:

Input Voltage Range

08 Spec:

85 VAC - 264 VAC

09 Attribute:

Resolution Down To

09 Spec:

.000004"/.0001mm

10 Attribute:

Operating Temperature

10 Spec:

32º - 115 °F

11 Attribute:

External Connections

11 Spec:

Foot Switch, Remote Keypad, Touch Probe, RS232C Serial Port, Parallel Port

12 Attribute:

Size (In)

12 Spec:

11.5 x 7.5 x 2.75" (Enclosure)

13 Attribute:

Base Dimensions (In)

13 Spec:

10 x 2 x 7.5"

14 Attribute:

Weight (lbs)

14 Spec:

Enclosure: 3.5 lb; Base: 7 lb

Category L1:

Data Collection Systems

Category L2:

Gage Amplifiers

US Promo Price:

$0.00

01 Attribute:

Starrett Model No.

COO Detail:

Made in the USA with US and Global Content

Schedule B Number:

9017-30-8000

Product made to order status:

MTO

Available In Region:

United States|Canada

Mt Airy Inventory:

0

Product Type:

Gage Check

Country of Origin:

United States

Blades per Pack (pcs):

1

Published Locations:

PMT Cat 33 - Precision Hand Tools Catalog

Superseded By:

GXS-4-FB-DM

Market:

USA/CANADA
