781BXTZ-7/16-20-THD Electronic Thread Gage

781BXTZ-7/16-20-THD Electronic Thread Gage

$5,584.00
(No reviews yet) Write a Review
SKU:
781BXTZ-7/16-20-THD
UPC:
049659625646
Discontinued:
false
Trade Names:
AccuBore®
01 Spec:
7/16-20
01 Attribute:
Thread Size
02 Attribute:
Number of Contact Points
02 Spec:
3
03 Attribute:
Number of Heads
03 Spec:
1
04 Attribute:
Number of Gages
04 Spec:
1
05 Attribute:
Includes
05 Spec:
Gage, 7/16-20 head, setting ring, battery, wrench
06 Attribute:
Output
06 Spec:
Cabled and Wireless
07 Attribute:
IP Rating
07 Spec:
IP67
08 Attribute:
Power supply
08 Spec:
Battery
09 Attribute:
Battery Type
09 Spec:
CR2032 lithium Battery (Qty 1), Included
10 Attribute:
SLC Certification
10 Spec:
Optional Add-On
A002040UCC12UPCA:
049659625646
A002050EANUCC13EAN13:
0049659625646
Accessory:
HEAD-1-12-THD|HEAD2|HEAD500|78/782F|78/782|78/782H
Available for Purchase-US-EN:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Category:
Precision Measuring Tools > Precision Hand Tools > Thread Gages > Electronic Pistol Grip
Category L1:
Thread Gages
Category L2:
Electronic Pistol Grip
EDP:
62564
Electronic or Mechanical:
Electronic
Feature 01:
Single-hand operation with right- and left-hand viewing flexibility
Feature 02:
Large, easy-to-read digital display with integrated LEDs tolerances
Item Segmentation:
Catalog
Member of Set:
781BXTP-750|HEAD-7/16-20-THD|RING-7/16-20-THD
NAFTA Producer:
No
Item ID:
781BXTZ-7/16-20-THD
Number of Gages:
1
Number of Rings:
1
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/781BXTZ-716-20-THDp01cUSd0826.tif
Product Title:
781BXTZ-7/16-20-THD Electronic Thread Gage
Product Type:
Thread Gage
Resolution (in):
.00005"
Resolution (mm):
0.001mm
Short Description:
7/16-20 Electronic Pistol Grip Thread Gage, 3 Contacts Points
Show in Web Nav?:
Yes
SLC Certification:
Optional Add-On
Starrett Model No.:
781BXTZ
Substitute:
770BXTZ-7/16-20-THD
Unit Pack Height (in):
4.09
Unit Pack Length (in):
15.39
Unit Pack Width (in):
11.97
UOM:
Each
US List Price:
$5584.00
US Promo Price:
$0.00
US Web Price:
$0.00
Web Catalog-US-EN:
Y
Web Priority-US-EN:
32500011
Unit Pack Weight (lbs):
3.99
Series Title:
781BXT Electronic Pistol Grip Thread Gages
Status:
Active
Manufacturer's code:
049659
Output:
Cabled and Wireless
Athol Inventory:
0
Battery Type:
CR2032 lithium Battery (Qty 1), Included
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Item Class:
Stand-Alone
Mt Airy Inventory:
0
Parent SKU As a Regular Field:
781BXTZ
Product Group Sort:
electronic_pistol_grip
Rocky Mountain Inventory:
0
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Webber Inventory:
0
Western Link Inventory:
0
Includes:
Gage, 7/16-20 head, setting ring, battery, wrench
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/781BXTZ-716-20-THDp01cUSd0826.tif
Number of Heads:
1
Product made to order status:
MTO
Schedule B Number:
9017.30.8000
Accessories Included:
Setting Ring
Thread Size:
7/16-20
Top 354:
N
Web Price:
$0.00
Country of Origin:
United Kingdom
Dimension Type:
Inch
Available In Region:
United States|Canada

781BXT AccuBore Electronic Pistol Grip Thread Gages deliver exact +/- measurement for thread milling operations, allowing machinists to measure how much more material needs to be removed to achieve target thread diameter specification. The trigger-activated pistol grip with two-point thread contact offers convenient, single-hand operation, providing speed, control and accuracy. They feature built-in wireless technology for automated data collection. Equipped with a large, easy-to-read digital display, and a mechanically-driven parallel anvil, establishing a perfect thread alignment, resulting in more accurate readings than models with spring-driven contacts. Speed and convenience are further enhanced by the repositionable AccuBore indicator, which may be swiveled and rotated for left, right hand or even vertical viewing. The gage also features a display with integrated LEDs tolerances that quickly indicate whether a thread measurement is within a preset tolerance window. This gage includes a head and setting ring for measuring 7/16-20 thread diameter, with 3 contact points. The head can be easily interchanged with additional thread and bore heads, adding versatility to bore and thread measurement processes at a lower price point.
