786MEP-75 Electronic Blade-Type Micrometer

(No reviews yet) Write a Review

Write a Review

Close ×

786MEP-75 Electronic Blade-Type Micrometer

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name Required

Email Required

Review Subject Required

Comments Required

SKU:

786MEP-75

UPC:

049659661279

Category:

Discontinued

Cal Prop 65 Chemical:

Lead

Cal Prop 65 Warning:

Y

Cal Prop 65 Statement:

WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov

Country of Origin :

United States

EAN:

0049659661279

EDP:

66127

Superseded By:

786.1MEP-75

Feature 01:

Balanced frame and thimble design ensure easy handling and better readability

Feature 02:

Output capability for data transmission

Feature 03:

Advanced sleeve design with staggered lines and distinct figures for precise and easy readability

Feature 04:

Conventional inch or millimeter graduations standard

Feature 05:

Quick and easy adjustment

Feature 06:

Large, easy-to-read, high-contrast LCD digital readout

Feature 07:

Starrett No-glare satin chrome finish on thimble and sleeve minimizes annoying surface glare under bright lights indoors or filters out UV light

Feature 08:

No-glare black wrinkle finish on frame

Feature 09:

Hard and stable one-piece friction thimble permits one-hand operation of micrometer and uniform contact pressure

Feature 10:

Rigid steel frame ribbed for strength and stability

Feature 11:

Ability to zero tool at any position as well as retain and return to the true zero reading of the micrometer

Feature 12:

One 3-volt battery included for extended usage

Feature 13:

Measurement HOLD button

Feature 14:

Automatic OFF

Feature 15:

RS232 data output port

Feature 16:

Inch/millimeter metric conversion provides simple, universal, standardized unit of measurement at any position

Feature 17:

PRESET button to install any reading at any position

Feature 18:

Ability to install minimum and maximum limits

Feature 19:

Speeder for quicker adjustment on all sizes

Feature 20:

ME model turns on in millimeter mode after battery installation

Athol Inventory:

2

Available for Purchase-US-EN:

Y

Available In Region :

United States|Canada

Description:

ELECTRONIC BLADE MICROMETER, 50-75mm

Flat Stock Inventory:

0

Item Class:

Stand-Alone

Max. Range (in):

2.95

Max. Range (mm):

75

Min. Range (in):

1.968

Min. Range (mm):

50

Mt Airy Inventory :

0

Product Group Sort:

discontinued

Webber Inventory:

0

Rocky Mountain Inventory:

0

Show in Web Nav?:

Yes

To Delete:

false

To Remove:

false

Total Inventory:

2

US Web Temp Hold:

Off

Global Product Classification:

ELECTRONIC BLADE MICROMETER, 50-75mm

Graduations (in):

.001"

Intended Use :

786MEP-75 DISCONTINUED PER ECO# 18218 7-14-20 REPLACED BY 786.1MEP-75{LineFeed}REPLACED WITH: 786.1MEP-75{LineFeed}

Item Segmentation:

Staging

Long Description:

786MEP-75 DISCONTINUED PER ECO# 18218 7-14-20 REPLACED BY 786.1MEP-75{LineFeed}REPLACED WITH: 786.1MEP-75{LineFeed}

Made in America:

Yes

Main Image:

https://s3-us-west-2.amazonaws.com/catsy.833/786MEP-75e66127cUSp1.tif

Manufacturer's code:

049659

Micrometer Type:

Electronic Blade-Type Micrometers

NAFTA Producer:

Yes

Name:

ELECTRONIC BLADE MICROMETER, 50-75mm

Item ID:

786MEP-75

POA Flag:

N

Product Photo 01:

https://s3-us-west-2.amazonaws.com/catsy.833/786MEP-75e66127cUSp1.tif

Product Title:

786MEP-75 Electronic Blade-Type Micrometer

Promo Item-US-EN:

Y

Range (in):

1.968-2.950"

Range (mm):

50-75mm

Resolution (in):

.00005"

Resolution (mm):

0.001mm

Series Title:

786, 786M Electronic Digital Blade Type Micrometers with Non-Rotating Spindle (with Output)

Shelf Pack Item Qty:

1

Shelf Pack Pricing Quantity:

1

Short Description:

Digital Blade Type Micrometer, Speeder Thimble, 0.8mm Blade Anvil, SPC Output, 0.001mm, 50-75mm Range

SPC Output:

Yes

Spindle Type:

0.8mm Blade

Status:

GOING DISC

Orderable Online Today (US Only):

Yes

A002050EANUCC13EAN13:

0049659661279

Accuracy (in):

+/-.0001"

Accuracy (mm):

+/-.002mm

Anvil Type:

0.8mm Blade

Anvil/Spindle Material:

Steel

Tariff Code for entry into Mexico:

Yes

Thimble Graduations:

Metric

Thimble Type:

Speeder

Top 354:

N

Unit Pack Height (in):

1.4

Unit Pack Height (mm):

35.56

Unit Pack Item Qty:

1

Unit Pack Length (in):

11.4

Unit Pack Length (mm):

287.02

Unit Pack Weight (kg):

0.7257472

Unit Pack Weight (lbs):

1.5

Unit Pack Width (in):

5.4

Unit Pack Width (mm):

134.62

UOM:

Each

UPC:

049659661279

Use Placeholder Photo:

N

US List Price:

$1834.00

US Web Price:

$573.89

Web Catalog-US-EN:

Y

Web Price:

$1834.00

Web Priority-US-EN:

25

Category L1:

Micrometers

Category L2:

Blade Micrometers

Discontinued:

false

Western Link Inventory:

0
