796.1MXRL-100 Electronic Micrometer without Output - Metric Only

796.1MXRL-100 Electronic Micrometer without Output - Metric Only

$572.00
(No reviews yet) Write a Review
SKU:
796.1MXRL-100
UPC:
049659011234
Discontinued:
false
A002040UCC12UPCA:
049659011234
A002050EANUCC13EAN13:
0049659011234
Available for Purchase-US-EN:
N
Catalog Section Page:
6
Category:
Discontinued
Category L1:
Micrometers
Category L2:
Electronic Outside Micrometers
Item Segmentation:
Catalog
NAFTA Producer:
No
Item ID:
796.1MXRL-100
Show in Web Nav?:
Yes
Superseded By:
733.1MEXFLZ-100
UOM:
Each
US Promo Price:
$0.00
US Web Price:
$572.00
Web Catalog-US-EN:
Y
COO Detail:
Made in the USA with US and Global Content
Global Product Classification:
ELECT. MIC., OUTSIDE IP67 75-100mm (NON-OUTPUT)
Manufacturer's code:
049659
Athol Inventory:
0
Available In Region:
United States|Canada
Cal Prop 65 Chemical:
Lead
Current Catalog:
33
Current Catalog Page:
24
Flat Stock Inventory:
0
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Mt Airy Inventory:
0
Product Group Sort:
discontinued
Rocky Mountain Inventory:
0
To Delete:
false
To Remove:
false
Total Inventory:
0
US Web Temp Hold:
Off
Webber Inventory:
0
Website-URL:
https://www.starrett.com/metrology/product-detail/796.1MXRL-100
Western Link Inventory:
0
Long Description:
ECO-19808
Made in America:
Yes
Next Catalog:
No
Product In Case Photo:
https://s3-us-west-2.amazonaws.com/catsy.833/796.1MXRL-100e01123cUSz1.tif
Product made to order status:
MTO
Published Locations:
Catalog 33
Schedule B Number:
9017.30.4000
Sales Category:
TOOLS.TOOLS (DISCOUNTABLE).
Tariff Code for entry into Mexico:
No
Top 354:
N
Unit Pack Invoiced:
N
Unit Pack Shippable:
N
Use Placeholder Photo:
N
Web Price:
$572.00
Country of Origin:
United States
Dimensional Drawing PDF:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-796.1MXRL-100-Dimensional-Drawing.pdf
Dimensional Drawing (IMG):
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-796.1MXRL-100-Dimensional-Drawing.tif
Accuracy (in):
+/-.0001"
Accuracy (mm):
+/-.003mm
Anvil Type:
Flat
Brochure 1:
https://s3.us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Catalog:
https://s3.us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-01-Micrometers.pdf
EAN:
0049659011234
EDP:
01123
Feature 01:
IP67 protection against coolants, water, chips, dust and dirt often found in machine shop environments
Feature 02:
Balanced frame for comfortable and accurate measuring
Feature 03:
Large, easy-to-read, high-contrast LCD digital readout
Feature 04:
Starrett No-glare satin chrome finish on thimble and sleeve minimizes annoying surface glare under bright lights indoors or filters out UV light
Feature 05:
No-glare black wrinkle finish on frame
Feature 06:
Hard and stable one-piece thimble with rachet lock permits one-hand operation of micrometer and uniform contact pressure
Feature 07:
Inch/millimeter metric conversion provides simple, universal, standardized unit of measurement at any position
Feature 08:
Ring-type knurled lock nut for quick and sure locking
Feature 09:
Micro-lapped carbide measuring faces
Lock Nut Type:
Lever
Micrometer Type:
Outside
Product Photo 01:
https://s3.us-west-2.amazonaws.com/catsy.833/796.1MXRL-100e01123cUSp1.tif
Product Title:
796.1MXRL-100 Electronic Micrometer without Output - Metric Only
Range (mm):
75-100mm
SDS Sheet:
https://s3.us-west-2.amazonaws.com/catsy.833/SDS-Renata-CR2032-ASDS.pdf
Short Description:
IP67 Outside Micrometer, Ratchet Thimble, Carbide Anvil, 0.001mm Res., 75-100mm Range
SLC Certification:
Optional Add-On
Thimble Graduations:
Metric
Thimble Type:
Ratchet
Unit Pack Height (in):
1.8
Unit Pack Length (in):
10
Unit Pack Width (in):
5.1
US List Price:
$572.00
Web Priority-US-EN:
99999999
Unit Pack Weight (lbs):
1.75
Series Title:
796, 796M IP67 Electronic Digital Micrometer (without Output)
Status:
GOING DISC
Cal Prop 65 Warning:
Y
Display Type:
LCD
Main Image:
https://s3.us-west-2.amazonaws.com/catsy.833/796.1MXRL-100e01123cUSp1.tif
Spindle Type:
Flat
Anvil/Spindle Material:
Carbide
The Starrett 796.1 Electronic Micrometers provide an IP67 level of protection against coolant, water, chips, dirt, dust, and other contaminants in hostile shop environments. The 796.1 Electronic micrometers are built with customary Starrett quality and workmanship. 0-100mm Range, With Ratchet Stop, With Carbide Faces, Without Output. [Discontinued 10/2022]
