The 3825 Brinell hardness tester incorporates the latest load cell and closed loop technology. The test load is applied via a closed-loop control unit with a load cell, a DC motor and an electronic measurement and control unit. The result is highly accurate Brinell hardness measurements at all test loads up to 0.5%. The common load overshoot or undershoot as known from traditional dead weight, or open-loop, systems is eliminated. The absence of mechanical weights not only eliminates friction problems but also makes the equipment less sensitive to misalignments caused by vibrations. The whole weight of the Brinell Hardness tester is 50% less than the traditional dead weights type tester. Test load selection by keyboard and LCD screen. The Brinell hardness Tester features a fully automatic test cycle, load application, holding, unloading, is performed fully automatically. This greatly improves reproducibility of test results since operator influence is eliminated. The directions for 0.102F/D2 ratios selecting according to the materials and hardness range can be showing on the screen. Equipped with a 20X optical microscope to measure the diameter of Brinell indention. Brinell Hardness Calculator (BHC) make the Brinell hardness value calculation easier and convenient.
3825 Digital Motorized Brinell Hardness Tester
$13,599.00
- SKU:
- 3825
- UPC:
- 049659020458
- Category:
- Precision Measuring Tools > Hardness Testers > Benchtop Hardness Testers
- Cal Prop 65 Warning:
- N
- Conflict Minerals:
- N
- Contaminated if Opened:
- N
- Country of Origin :
- China
- Datasheet:
- https://s3-us-west-2.amazonaws.com/catsy.833/3825-hardness-tester-bulletin-1840.pdf
- Data Sheet URL-US-EN:
- https://www.starrett.com/vdoc/3825 Hardness Tester (Bulletin 1840)
- EAN:
- 0049659020458
- EDP:
- 02045
- Exists in Comport:
- N
- Feature 01:
- Load Cell driven system provides precise control of test force application
- Feature 02:
- Direct digital reading
- Feature 03:
- Engineered to obtain highly sensitive and accurate readings
- Feature 04:
- Perfect for laboratories, workshops, tool rooms, inspection labs, etc.
- Feature 05:
- Measuring Range: 8-650HBW
- Athol Inventory:
- 0
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Brochure URL-US-EN:
- https://www.starrett.com/vdoc/Starrett Hardness Testers (Bulletin 592)
- Description:
- The 3825 Brinell hardness tester incorporates the latest load cell and closed loop technology.
- Flat Stock Inventory:
- 0
- In Sugar Catalog:
- Yes
- Item Class:
- Stand-Alone
- Mt Airy Inventory :
- 0
- Product Group Sort:
- benchtop_hardness_testers
- Webber Inventory:
- 0
- Website-URL:
- https://www.starrett.com/details?cat-no=3825
- Rocky Mountain Inventory:
- 0
- Show in Web Nav?:
- Yes
- To Delete:
- false
- To Remove:
- false
- Top Seller:
- Yes
- Total Inventory:
- 0
- US Web Temp Hold:
- Off
- Fragile:
- N
- French Language Included:
- N
- Global Product Classification:
- Brinell Hardness Tester
- Hazmat Indicator:
- N
- Item Segmentation:
- Catalog
- Long Description:
- Each
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/3825e02045cUSp1.tif
- Major Load:
- 3000kgf (29400N), 1500Kgf (14700N), 1000Kgf (9800N), 750Kgf (7355N), 500Kgf (4900N), 250Kgf
- Manufacturer's code:
- 049659
- Marked Recyclable:
- N
- Maximum Test Height:
- 9" (228mm)
- Name:
- Brinell Hardness Tester
- Item ID:
- 3825
- PMRA Regulated:
- N
- Product made to order status:
- MTA
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/3825e02045cUSp1.tif
- Product Title:
- 3825 Digital Motorized Brinell Hardness Tester
- Promo Item-US-EN:
- N
- Refrigerant Indicator:
- N
- Results Display:
- Digital
- RoHS (EU):
- N
- SDS Indicator:
- N
- Series Title:
- 3800 Hardness Testers
- Shelf Pack Invoiced:
- N
- Shelf Pack Shippable:
- N
- Short Description:
- Brinell Hardness Tester
- Status:
- Active
- A0006160MSDSINDICATOR:
- N
- A000670ROHASCOMPLIANT:
- N
- A002040UCC12UPCA:
- 049659020458
- A002050EANUCC13EAN13:
- 0049659020458
- Allow Testimonial:
- N
- Stocked Locally(Y/N)-US-EN:
- N
- Subject to Environmental Change:
- N
- Temperature Sensitive:
- N
- Throat Depth:
- 5.5" (140mm)
- Top 354:
- N
- Unit Height/Width/Depth:
- 21 ×10.5 ×29.5" (535mm x 267mm x 750mm)
- Unit Pack Height (in):
- 48
- Unit Pack Invoiced:
- N
- Unit Pack Length (in):
- 40
- Unit Pack Shippable:
- N
- Unit Pack Weight (lbs):
- 275
- Unit Pack Width (in):
- 40
- Unit Weight:
- 242lbs Net / 275lbs Shipping
- UOM:
- Each
- UPC:
- 049659020458
- User Manual URL-US-EN:
- https://www.starrett.com/UM-3825
- US List Price:
- $13599.00
- US Next List Price:
- $13599.00
- US Web Price:
- $13599.00
- Variable Unit:
- N
- Web Catalog-US-EN:
- Y
- Web Price:
- $13599.00
- Web Priority-US-EN:
- 41800030
- Hardness Scale:
- Brinell
- Electronic or Mechanical:
- Electronic
- Category L1:
- Hardness Testers
- Category L2:
- Benchtop
- Sales Category:
- TOOLS.TOOLS (ELECTRONIC & NON-DISCOUNTABLE).
- 01 Attribute :
- Major Load
- 01 Spec:
- 3000kgf (29400N), 1500Kgf (14700N), 1000Kgf (9800N), 750Kgf (7355N), 500Kgf (4900N), 250Kgf
- 02 Attribute:
- Maximum Test Height
- 02 Spec:
- 9" (228mm)
- 03 Attribute:
- Results Display
- 03 Spec:
- Digital
- 04 Attribute:
- Throat Depth
- 04 Spec:
- 5.5" (140mm)
- 05 Attribute:
- Unit Height/Width/Depth
- 05 Spec:
- 21 ×10.5 ×29.5" (535mm x 267mm x 750mm)
- 06 Attribute:
- Unit Weight
- 06 Spec:
- 242lbs Net / 275lbs Shipping
- 07 Attribute:
- Hardness Scale
- 07 Spec:
- Brinell
- Discontinued:
- false
- Current Catalog:
- 33
- Current Catalog Page:
- add
- Brochure 1:
- https://s3-us-west-2.amazonaws.com/catsy.833/starrett-hardness-testers-bulletin-592.pdf
- Western Link Inventory:
- 0
- Unit Pack Item Qty:
- 1
