709AZ Dial Test Indicator with Dovetail Mount

709AZ Dial Test Indicator with Dovetail Mount

$361.00
(No reviews yet) Write a Review
SKU:
709AZ
UPC:
049659642148
Category:
Precision Measuring Tools > Precision Hand Tools > Indicators & Gages > Test Indicators
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Contact Ball Material:
Carbide
Contact Point Ball Diameter (in):
.078" (2mm)
Contact Point Ball Diameter (mm):
2mm (.078")
Contact Point Length (in):
13/16"
Contact Point Length (mm):
20mm
Country of Origin :
United States
Dial Color:
White
Dial Reading:
0-15-0
EAN:
0049659642148
EDP:
64214
Feature 01:
These precision test indicators offer an easy to read angled head and the flexibility of three dovetail mounts
Feature 02:
Three dovetail positioning mounts work with existing test indicator accessories
Feature 03:
Precision gear-driven design with smooth, jeweled movement
Feature 04:
Contact point reverses automatically, always maintaining clockwise hand rotation
Feature 05:
Contacts are frictionally adjustable and replaceable
Feature 06:
Revolution count hand for easy reading
Feature 07:
Meet or exceed ISO accuracy specification
Feature 08:
Inch reading indicators are available with easy-to-read, shaded white, red, or black dials - millimeter reading indicators with yellow dials
Feature 09:
Angled head for better reading position
Feature 10:
Narrow body for inreach ability
Feature 11:
Satin chrome finish for durability
Feature 12:
Large 1-3/8" (35mm) dial diameter
Feature 13:
Include long carbide contacts 13/16" (20mm)
Athol Inventory:
1
Attachments:
Without Attachments
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada
Description:
DIAL TEST INDICATOR SET, 0-15-0, .0005"
Flat Stock Inventory:
0
Item Class:
Stand-Alone
Max. Range (in):
0.03
Min. Range (in):
0
Mt Airy Inventory :
0
Parent SKU As a Regular Field:
708
Product Group Sort:
icc110501
Webber Inventory:
0
Website-URL:
https://www.starrett.com/details?cat-no=709AZ
Rocky Mountain Inventory:
0
Show in Web Nav?:
Yes
To Delete:
false
To Remove:
false
Total Inventory:
1
US Web Temp Hold:
Off
Global Product Classification:
DIAL TEST INDICATOR SET, 0-15-0, .0005"
Graduations (in):
.0005"
Item Segmentation:
Catalog
Long Description:
Each
Made in America:
Yes
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/709AZcUSp1.tif
Manufacturer's code:
049659
NAFTA Producer:
Yes
Name:
DIAL TEST INDICATOR SET, 0-15-0, .0005"
Item ID:
709AZ
POA Flag:
N
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/709AZcUSp1.tif
Product Photo 02:
https://s3-us-west-2.amazonaws.com/catsy.833/709AZcUSp1.tif
Product Photo 03:
https://s3-us-west-2.amazonaws.com/catsy.833/709AZcUSp4.tif
Product Title:
709AZ Dial Test Indicator with Dovetail Mount
Range (in):
.030"
SDS Indicator:
N
Series Title:
708, 708M, 709, 709M Dial Test Indicators with Dovetail Mounts with Case
Shelf Pack Item Qty:
1
Shelf Pack Pricing Quantity:
1
Short Description:
Dial Test Indicator with Dovetail, .030" Range, 0-15-0 Dial Face, .0005" Graduations
Status:
Active
A0006160MSDSINDICATOR:
N
A002040UCC12UPCA:
049659642148
A002050EANUCC13EAN13:
0049659642148
Style:
Dovetail Mount
Tariff Code for entry into Mexico:
Yes
Top 354:
N
Unit Pack Height (in):
1.3
Unit Pack Height (mm):
58.42
Unit Pack Item Qty:
1
Unit Pack Length (in):
5.4
Unit Pack Length (mm):
193.04
Unit Pack Weight (kg):
0.4989512
Unit Pack Weight (lbs):
0.2
Unit Pack Width (in):
3
Unit Pack Width (mm):
134.62
UOM:
Each
UPC:
049659642148
Use Placeholder Photo:
N
US List Price:
$361.00
US Next List Price:
$361.00
US Web Price:
$361.00
Web Catalog-US-EN:
Y
Web Price:
$361.00
Web Priority-US-EN:
21600175
Electronic or Mechanical:
Mechanical
Starrett Model No.:
709
Dial Diameter (In):
1-3/8"
Category L1:
Indicators & Gages
Category L2:
Test Indicators
01 Attribute :
Range (in)
01 Spec:
.030"
02 Attribute:
Graduations (in)
02 Spec:
.0005"
03 Attribute:
Dial Reading
03 Spec:
0-15-0
04 Attribute:
Attachments
04 Spec:
Without Attachments
05 Attribute:
Contact Ball Material
05 Spec:
Carbide
06 Attribute:
Contact Point Ball Diameter (in)
06 Spec:
.078" (2mm)
07 Attribute:
Contact Point Ball Diameter (mm)
07 Spec:
2mm (.078")
08 Attribute:
Contact Point Length (in)
08 Spec:
13/16"
09 Attribute:
Contact Point Length (mm)
09 Spec:
20mm
10 Attribute:
Style
10 Spec:
Dovetail Mount
11 Attribute:
Dial Color
11 Spec:
White
12 Attribute:
Dial Diameter (In)
12 Spec:
1-3/8"
Discontinued:
false
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Current Catalog Page:
135
Catalog Section Page:
3
Catalog:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Precision-Hand-Tools.pdf
Catalog Section:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett-Catalog-33-Section-05-Dial-and-Electronic-Indicators-and-Gages.pdf
SLC Certification:
Optional Add-On
Western Link Inventory:
0
Orderable Online Today (US Only):
Yes
Adding to cart… The item has been added
The Starrett 709 Dial Test Indicator with Dovetail Mount offers an easy to read angled head and the flexibility of three dovetail mounts. White Dial, .030" Range, .0005" Grad, without Attachments.
