The Starrett 733.1 Electronic Micrometer with Output is a full-featured precision measuring tool built with customary Starrett quality and workmanship. It includes output capability for data transmission. The 733.1 series includes a large, easy-to-read, high-contrast LCD digital readout for clear readings. With its automatic OFF functionality, smooth friction thimble for uniform pressure, and balanced frame design, Starrett products provide comfortable and accurate measuring. Its no-glare satin chrome finish minimizes annoying surface glare under bright lights indoors. Starrett electronic micrometers guarantee a precise measurement at every position each and every time.
733.1MEXFLZ-100 Electronic Micrometer
$527.00
- SKU:
- 733.1MEXFLZ-100
- UPC:
- 049659712803
- Product made to order status:
- MTO
- Product Photo 01:
- https://s3-us-west-2.amazonaws.com/catsy.833/733.1MEXFLZ-100e71280cUSp1.tif
- Product Title:
- 733.1MEXFLZ-100 Electronic Micrometer
- Range (in):
- 2.950-3.930"
- Range (mm):
- 75-100mm
- Resolution (in):
- .00005"
- Resolution (mm):
- 0.001mm
- Series Title:
- 733.1 Electronic Digital Micrometers
- Short Description:
- LCD Outside Micrometer, Friction Thimble, Carbide Anvil, SPC Output, 0.001mm Res., 75-100mm Range
- SPC Output:
- Yes
- Spindle Type:
- Flat
- Status:
- Active
- Accuracy (in):
- +/-.00015"
- Accuracy (mm):
- +/-.004mm
- Anvil Type:
- Flat
- Anvil/Spindle Material:
- Carbide
- Thimble Graduations:
- Metric
- Thimble Type:
- Friction
- Top 354:
- N
- Unit Pack Height (in):
- 2.2
- Unit Pack Invoiced:
- N
- Unit Pack Length (in):
- 13.3
- Unit Pack Shippable:
- N
- Unit Pack Weight (lbs):
- 3.15
- Unit Pack Width (in):
- 8.6
- UOM:
- Each
- UPC:
- 049659712803
- Use Placeholder Photo:
- N
- US List Price:
- $527.00
- US Web Price:
- $527.00
- Web Catalog-US-EN:
- Y
- Web Priority-US-EN:
- 12200315
- Whitepaper 1 :
- https://s3-us-west-2.amazonaws.com/catsy.833/DataSure+4.pdf
- Wireless:
- No
- A002040UCC12UPCA:
- 049659712803
- A002050EANUCC13EAN13:
- 0049659712803
- Case Study:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Datasure+4.pdf
- Case Type:
- Plastic
- Category:
- Precision Measuring Tools > Precision Hand Tools > Micrometers > Electronic Outside Micrometers
- Cal Prop 65 Chemical:
- Lead
- Cal Prop 65 Warning:
- Y
- Cal Prop 65 Statement:
- WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
- Country of Origin :
- United States
- Display Type:
- LCD
- EAN:
- 0049659712803
- EDP:
- 71280
- Effective List Date:
- 2022-12-31
- Effective Web Date:
- 2022-07-01
- Feature 01:
- IP67 protection against coolants, water, chips, dust and dirt (ranges 0-4"/0-100mm only)
- Feature 02:
- Starrett no-glare satin chrome finish on thimble and sleeve
- Feature 03:
- Micro-lapped carbide measuring faces
- Feature 04:
- Large, easy-to-read .275 (7mm) high contrast LCD digital readout
- Feature 05:
- Balanced and tapered frame
- Feature 06:
- Extremely hard and stable one-piece spindle
- Feature 07:
- Auto Off after 20 minutes of nonuse
- Feature 08:
- Inch/millimeter conversion on English versions
- Feature 09:
- Smooth friction thimble for uniform pressure
- Feature 10:
- Measurement HOLD button
- Feature 11:
- Zero at any position
- Feature 12:
- Retain and return to true zero reading
- Feature 13:
- Spindle lock
- Feature 14:
- Data Output
- Feature 15:
- Resolution: .00005" (0.001mm)
- Feature 16:
- Accuracy +/-.0001 (=+/-.002mm)
- Feature 17:
- PRESET button to install any reading at any position
- Feature 18:
- Ability to install minimum and maximum limits
- Assembled in US:
- N
- Available for Purchase-US-EN:
- Y
- Available In Region :
- United States|Canada
- Brochure:
- https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
- Brochure URL-US-EN:
- https://www.starrett.com/vdoc/Starrett Electronic Precision Hand Tools (Bulletin 590)
- CAN List Price:
- CA$668.00
- CAN Price List Name:
- 133W - 2021
- CAN Web Price:
- CA$554.70
- Combined Dollar Sales:
- 1956.71
- Combined Unit Sales :
- 7
- Description:
- The Starrett 733.1 Electronic Micrometer with Output is a full-featured precision measuring tool
- In Sugar Catalog:
- Yes
- Item Class:
- Stand-Alone
- Max. Range (in):
- 3.93
- Max. Range (mm):
- 100
- Min. Range (in):
- 2.95
- Min. Range (mm):
- 75
- Parent SKU As a Regular Field:
- 733.1
- Product Group Sort:
- pim_icc_num_110102
- Website-URL:
- https://www.starrett.com/details?cat-no=733.1MEXFLZ-100
- Show in Web Nav?:
- Yes
- Total Inventory:
- 0
- Unit Sales 2020:
- 1
- Unit Sales 2021:
- 0
- Unit Sales 2022:
- 6
- US Price List Name:
- 133W - 2021
- US Web Temp Hold:
- Off
- Web Price:
- $527.00
- Starrett Model No.:
- 733.1
- Type:
- Micrometer - Outside
- ICC:
- 110102 Electronic Outside Micr
- Item Segmentation:
- Catalog
- Lock Nut Type:
- Lever
- Long Description:
- ELECTRONIC MICROMETER 100MM
- Main Image:
- https://s3-us-west-2.amazonaws.com/catsy.833/733.1MEXFLZ-100e71280cUSp1.tif
- Manufacturer's code:
- 049659
- Micrometer Type:
- Outside
- Name:
- ELECTRONIC MICROMETER 100MM
- Item ID:
- 733.1MEXFLZ-100
- Other Document 1 URL-US-EN:
- https://www.starrett.com/vdoc/Starrett DataSure 4.0 (Bulletin 591)
- Other Document 2 URL-US-EN:
- https://www.starrett.com/vdoc/DataSure 4.0 Whitepaper
- Other Document 3 URL-US-EN:
- https://www.starrett.com/vdoc/DS 4.0 at Roush Yates Engines
- Product Photo 02:
- https://s3-us-west-2.amazonaws.com/catsy.833/733.1MEXFLZ-100e71280cUSz1.tif
- Electronic or Mechanical:
- Electronic
- Category L1:
- Micrometers
- Category L2:
- Electronic Outside Micrometers
- Sales Category:
- TOOLS.HARDWARE TOOLS (NON-DISCOUNTABLE).
- Athol Inventory:
- 0
- Flat Stock Inventory:
- 0
- Mt Airy Inventory :
- 0
- Rocky Mountain Inventory:
- 0
- US Next List Price:
- $527.00
- IBC Category 1:
- Testing, Measuring and Inspection
- IBC Category 2:
- Dimensional Measurement Tools
- IBC Category 3:
- Micrometers
- User Manual URL-US-EN:
- https://www.starrett.com/um-733.1
- To Delete:
- false
- To Remove:
- false
- Made in America:
- Yes
- Webber Inventory:
- 0
- Minimum Order Quantity:
- 0
- SDS Sheet:
- https://s3-us-west-2.amazonaws.com/catsy.833/SDS-Renata-CR2032-ASDS.pdf
- Discontinued:
- false
- Current Catalog Page:
- new since print
- 01 Attribute :
- Micrometer Type
- 01 Spec:
- Outside
- 02 Attribute:
- Range (mm)
- 02 Spec:
- 50-75mm
- 03 Attribute:
- Resolution (mm)
- 03 Spec:
- 0.001mm
- 04 Attribute:
- Accuracy (mm)
- 04 Spec:
- +/-.003mm
- 05 Attribute:
- SPC Output
- 05 Spec:
- No
- 06 Attribute:
- Wireless
- 06 Spec:
- Yes
- 07 Attribute:
- Anvil Type
- 07 Spec:
- Flat
- 08 Attribute:
- Spindle Type
- 08 Spec:
- Flat
- 09 Attribute:
- Anvil/Spindle Material
- 09 Spec:
- Carbide
- 10 Attribute:
- Lock Nut Type
- 10 Spec:
- Lever
- 11 Attribute:
- Thimble Type
- 11 Spec:
- Friction
- 12 Attribute:
- Thimble Graduations
- 12 Spec:
- English
- 13 Attribute:
- Display Type
- 13 Spec:
- LCD
- 14 Attribute:
- Case Type
- 14 Spec:
- Plastic
- Catalog URL-US-EN:
- https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Band+Saw+Blades+Catalog+60.pdf
