W733.1MEXFL-25 Wireless Electronic Micrometer

W733.1MEXFL-25 Wireless Electronic Micrometer

$856.00
(No reviews yet) Write a Review
SKU:
W733.1MEXFL-25
UPC:
049659605822
Product made to order status:
MTA
Product Photo 01:
https://s3-us-west-2.amazonaws.com/catsy.833/Missing-Image-Sign.tif
Product Title:
W733.1MEXFL-25 Wireless Electronic Micrometer
Promo Item-US-EN:
N
Range (in):
0-1"
Range (mm):
0-25mm
Resolution (in):
.00005"
Resolution (mm):
0.001mm
Series Title:
733.1 Electronic Digital Micrometers
Short Description:
Wireless Outside Micrometer, Friction Thimble, Carbide Anvil, 0.001mm Res., 0-25mm Range
SPC Output:
No
Spindle Type:
Flat
Status:
Active
Accuracy (in):
+/-.0001"
Accuracy (mm):
+/-.003mm
Allow Testimonial:
N
Anvil Type:
Flat
Anvil/Spindle Material:
Carbide
Stocked Locally(Y/N)-US-EN:
N
Thimble Graduations:
English
Thimble Type:
Friction
Top 354:
N
Unit Pack Height (in):
1.4
Unit Pack Invoiced:
N
Unit Pack Length (in):
6.4
Unit Pack Shippable:
N
Unit Pack Weight (lbs):
0.95
Unit Pack Width (in):
3.3
UOM:
Each
UPC:
049659605822
Use Placeholder Photo:
Y
User Manual URL-US-EN:
https://www.starrett.com/UM-W733.1
US List Price:
$856.00
US Web Price:
$856.00
Web Catalog-US-EN:
Y
Web Priority-US-EN:
12200301
Whitepaper 1 :
https://s3-us-west-2.amazonaws.com/catsy.833/DataSure+4.pdf
Wireless:
Yes
A002040UCC12UPCA:
049659605822
A002050EANUCC13EAN13:
0049659605822
Case Study:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Datasure+4.pdf
Case Type:
Plastic
Category:
Precision Measuring Tools > Precision Hand Tools > Micrometers > Electronic Outside Micrometers
Cal Prop 65 Chemical:
Lead
Cal Prop 65 Warning:
Y
Cal Prop 65 Statement:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to: www.P65Warnings.ca.gov
Country of Origin :
China
Display Type:
LCD
EAN:
0049659605822
EDP:
60582
Effective List Date:
2022-12-31
Effective Web Date:
2022-07-01
Accessory:
PT64036
Feature 01:
Wireless operating distance up to 9 meters (30 feet)
Feature 02:
Rechargeable battery port
Feature 03:
IP67 protection against coolants, water, chips, dust and dirt (ranges 0-4"/0-100mm only)
Feature 04:
Starrett no-glare satin chrome finish on thimble and sleeve
Feature 05:
Micro-lapped carbide measuring faces
Feature 06:
Large, easy-to-read .275 (7mm) high contrast LCD digital readout
Feature 07:
Balanced and tapered frame
Feature 08:
Extremely hard and stable one-piece spindle
Feature 09:
Auto Off after 20 minutes of nonuse
Feature 10:
Inch/millimeter conversion on English versions
Feature 11:
Smooth friction thimble for uniform pressure
Feature 12:
Measurement HOLD button
Feature 13:
Zero at any position
Feature 14:
Retain and return to true zero reading
Feature 15:
Spindle lock
Feature 16:
Ability to install minimum and maximum limits
Feature 17:
Resolution: .00005" (0.001mm)
Feature 18:
Accuracy +/-.0001 (=+/-.002mm)
Feature 19:
PRESET button to install any reading at any position
Feature 20:
Ability to install minimum and maximum limits
Assembled in US:
N
Athol Inventory:
2
Available for Purchase-US-EN:
Y
Available In Region :
United States|Canada
Brochure:
https://s3-us-west-2.amazonaws.com/catsy.833/starrett-datasure-4-0-bulletin-591.pdf
Brochure 2:
https://s3-us-west-2.amazonaws.com/catsy.833/starrett-electronic-precision-hand-tools-bulletin-590.pdf
Brochure URL-US-EN:
https://www.starrett.com/vdoc/Starrett DataSure 4.0 (Bulletin 591)
CAN List Price:
CA$1083.00
CAN Price List Name:
133W - 2021
CAN Web Price:
CA$899.13
Combined Dollar Sales:
2512.50
Combined Unit Sales :
6
In Sugar Catalog:
Yes
Item Class:
Stand-Alone
Max. Range (in):
1
Max. Range (mm):
25
Min. Range (in):
0
Min. Range (mm):
0
Parent SKU As a Regular Field:
733.1
Product Group Sort:
pim_icc_num_110102
Website-URL:
https://www.starrett.com/details?cat-no=W733.1MEXFL-25
Secondary Category:
Precision Measuring Tools > Precision Hand Tools > Wireless
Show in Web Nav?:
Yes
Total Inventory:
2
Unit Sales 2020:
1
Unit Sales 2021:
5
Unit Sales 2022:
0
US Price List Name:
133W - 2021
US Web Temp Hold:
Off
Web Price:
$856.00
Starrett Model No.:
733.1
Type:
Micrometer - Outside
ICC:
110102 Electronic Outside Micr
Item Segmentation:
Catalog
Lock Nut Type:
Lever
Long Description:
ELECTRONIC MICROMETER 25mm, WIRELESS
Main Image:
https://s3-us-west-2.amazonaws.com/catsy.833/Missing-Image-Sign.tif
Manufacturer's code:
049659
Micrometer Type:
Outside
Name:
ELECTRONIC MICROMETER 25mm, WIRELESS
Item ID:
W733.1MEXFL-25
Other Document 1 URL-US-EN:
https://www.starrett.com/vdoc/DataSure 4.0 Whitepaper
Other Document 2 URL-US-EN:
https://www.starrett.com/vdoc/DS 4.0 at Roush Yates Engines
Electronic or Mechanical:
Electronic
Category L1:
Micrometers
Category L2:
Electronic Outside Micrometers
Sales Category:
TOOLS.HARDWARE TOOLS (NON-DISCOUNTABLE).
Flat Stock Inventory:
0
Mt Airy Inventory :
0
Rocky Mountain Inventory:
0
US Next List Price:
$856.00
IBC Category 1:
Testing, Measuring and Inspection
IBC Category 2:
Dimensional Measurement Tools
IBC Category 3:
Micrometers
To Delete:
false
To Remove:
false
Webber Inventory:
0
Minimum Order Quantity:
0
Orderable Online Today (US Only):
Yes
Discontinued:
false
Current Catalog Page:
new since print
01 Attribute :
Micrometer Type
01 Spec:
Outside
02 Attribute:
Range (mm)
02 Spec:
0-25mm
03 Attribute:
Resolution (mm)
03 Spec:
0.001mm
04 Attribute:
Accuracy (mm)
04 Spec:
+/-.003mm
05 Attribute:
SPC Output
05 Spec:
Yes
06 Attribute:
Wireless
06 Spec:
No
07 Attribute:
Anvil Type
07 Spec:
Flat
08 Attribute:
Spindle Type
08 Spec:
Flat
09 Attribute:
Anvil/Spindle Material
09 Spec:
Carbide
10 Attribute:
Lock Nut Type
10 Spec:
Lever
11 Attribute:
Thimble Type
11 Spec:
Friction
12 Attribute:
Thimble Graduations
12 Spec:
Metric
13 Attribute:
Display Type
13 Spec:
LCD
14 Attribute:
Case Type
14 Spec:
Plastic
Catalog URL-US-EN:
https://s3-us-west-2.amazonaws.com/catsy.833/Starrett+Band+Saw+Blades+Catalog+60.pdf
Adding to cart… The item has been added
The Starrett 733.1 Electronic Micrometer with Output is a full-featured precision measuring tool built with customary Starrett quality and workmanship. It includes output capability for data transmission. The 733.1 series includes a large, easy-to-read, high-contrast LCD digital readout for clear readings. With its automatic OFF functionality, smooth friction thimble for uniform pressure, and balanced frame design, Starrett products provide comfortable and accurate measuring. Its no-glare satin chrome finish minimizes annoying surface glare under bright lights indoors. Starrett electronic micrometers guarantee a precise measurement at every position each and every time.
